FYK SERIES Single Phase Filters
Product Information
The FYK SERIES is a line of single-phase filters designed for
various applications such as datacom equipment, test and
measurement equipment, and fitness machines. These filters are used
to reduce electromagnetic interference (EMI) and ensure the smooth
operation of electronic devices.
Key Features:
- Rated Voltage: 125/250VAC
- Rated Currents: 1 to 10A
- Operating Frequency: 50/60Hz
- Hipot Rating (Line-to-line): 1450VDC
- Hipot Rating (Line-to-ground): 2250VDC
- Operating Temperature: Suitable for standard operating
conditions - Safety Compliance: Meets relevant safety standards
The FYK SERIES filters are equipped with optional ground chokes
and resistors to further enhance their performance. The ground
choke has a resistance of 1M ohm and a minimum power rating of
1/4W.
The filters come in different models with varying rated
currents, inductance, capacitance, and output connections. Refer to
the Filter Selection Table below for more details.
Product Usage Instructions
To use the FYK SERIES single-phase filters, follow these
steps:
- Ensure that the power supply is disconnected before
installation. - Select the appropriate filter model based on the desired rated
current for your application. Refer to the Filter Selection Table
for guidance. - Connect the filter to the power line by attaching the fast-on
terminal or optional lead-wire to the appropriate input and output
connections. - If using the optional ground choke and resistor, connect them
as instructed in the user manual or schematic diagram. - Double-check all connections to ensure they are secure and
properly aligned. - Once the filter is installed, reconnect the power supply and
verify that the equipment operates smoothly without any noticeable
EMI interference.
For further information on installation, safety precautions, and
maintenance, please refer to the complete user manual provided with
the product.
FYK SERIES (Single Phase Filters)
LOAD
Features
gThe FYK series is general purpose single phase Àlter. gThe rated current can be offered from 1 to 10 amps. gThe compact size for easy installation and space saving. gVarious output selections such as fast-on terminal, and lead wire. gLow leakage current version upon requested. gAll parts are approved by UL ,CSA ,VDE and CE gApplications comprising Electrical and electronic equipment, household equipment, Medical equipment,
Datacom equipment, Test and measurement equipment, Fitness machine.
Technical SpeciÀcation
Typical electrical schematic
Rated voltage Rated currents Operating frequency Hipot rating(Line-to-line) Hipot rating(Line-to-ground) Operating temperature Safety compliance
125/250VAC 1 to 10A 50/60Hz 1450VDC 2250VDC
-25~+85ÝC UL,CSA,VDE,CE
LINE
$:
3
$9
–
$:
(
*With optional ground choke and resister. R: 1M ohm,1/4W min.
Filter Selection Table
Part No.
FYK01T1 FYK03T1 FYK06T1 FYK10T1
Rated Current (A) 1 3 6 10
Inductance L(mH) 3.7 1.8 0.7 0.3
Capacitance CX(F)
0.1 0.1 0.1 0.1
Capacitance CY(pF) 3300 3300 3300 3300
Output connections
Fast-on terminal (optional lead-wire)
Physical Dimensions: (mm)
F<.7
Ø
(
0$;
0$;
F<.7/HDGZLUH
0$; Ø
UL 1015 18AWG (BLUE)
(
UL 1015 18AWG(GRN/YEL)
UL 1015 18AWG(BROWN)
UL 1015 18AWG (BLUE)
UL 1015 18AWG(BROWN)
0$;
Typical Àlter attenuation &RPPRQPRGH1RUPDOPRGH
YK01
.
0
0
0
YK03
.
0
YK06
.
0
0
0
YK10
.
0
0$;
0
0
0
0
