Puraero Pa-250-af-bl Commercial Axial Air Mover With Gfci And Daisy Chain Capability Owner's Manual

PA-250-AF-BL Commercial Axial Air Mover with GFCI and Daisy Chain Capability

Product Information:

This product is an air mover designed to provide high air volume
for various applications. It operates at 115V with a 1/3HP motor
and a power cycle of 60Hz. The maximum air volume it can produce is
4000CFM. The unit weighs 33 lbs and has dimensions of 21.7×14.4×22
inches. It offers 2 speed options and comes with a 25ft/14AWG
cord.

Product Usage Instructions:

1. Before using the air mover, read and understand all the
   warnings and instructions provided in the owner’s manual.
2. Ensure that the unit is connected to a power source that
   matches the specified voltage (115V).
3. Check if the switch is in the ON position. If not, turn it
   on.
4. If the unit does not run, check for any power issues such as a
   tripped circuit breaker. Plug the unit in and perform a continuity
   check using a volt/amp meter to identify any faulty or broken
   wires. Repair or replace them accordingly.
5. If the air mover makes a loud scraping noise, it may be due to
   severe jolting causing the blower wheel to rub against the housing.
   Remove the motor and replace any damaged motor mounts or blower
   wheel.
6. If the unit vibrates excessively, it may be due to a severe
   jolt that has bent the motor shaft or a damaged air mover blade.
   Replace the motor or blade if necessary. Additionally, clean the
   air mover blade to remove any dirt build-up.
7. If the blower wheel does not turn, it could indicate failing
   motor bearings, an internal electrical fault in the motor, or
   obstructions in the intake or exhaust grills. Replace the motor if
   necessary and remove any obstructions. Also, ensure that the duct
   length is within the recommended maximum.

Assembly:

The following parts are required for assembly:

PURAERO’S WARRANTY POLICY:

PURAERO offers a limited warranty on parts and labor for a
period of one year from the original purchase date. The warranty
covers defects in material and workmanship. Please refer to the
warranty conditions for more details.

CM

C

US

READ AND SAVE THESE INSTRUCTIONS
OWNERS MANUAL

READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USING THIS AIR MOVER!

VOLTS POWER CYCLE MAX AIR VOLUME AMPS WEIGHT SIZE L/W/H SPEED CORD LENGTH

115V 1/3HP 60Hz 4000CFM 2.7AMPS 33 Ibs 21.7″x14.4″x22″ 2 SPEEDS 25ft/14AWG

Page 2

Problem

Cause

Solution

Unit will not run.

1. No power to nuit. 2. Switch not on. 3. Switch is faulty. 4. Faulty/broken cord or motor wire

1. Plug unit in. Check circuit breaker. 2. Place in “ON” position. 3. Replace switch. 4. Perform continuity check, using volt/amp meter. Repair/replace faulty broken wire.

Unit runs but air mover makes loud scraping noise.

1. Unit has been severely jolted causing blower wheel to rub against housing. 2. Unit has been severely jolted causing housing to deform.

1. Remove motor and replace damaged motor mounts. 2. Replace blower wheel.

Unit runs but vibrates excessively.

1. Severe jolt has bent motor shaft causing unit to be out of balance. 2. Air mover blade damaged. 3. Dirt build up on one side of air mover blade.

1. Remove and replace motor. 2. Replace blade if necessary. 3. Clean air mover blade.

Unit runs but blower wheel does not turn.

1. Motor bearings are failing or motor has developed an internal electrical fault. 2. Intake grill and/or exhaust grill is obstructed. 3. Excessive duct length.

1. Replace motor. 2. Remove obstruction. 3. Reduce duct length to recommended maximum

Page 3

ASSEMBLY

6

9

10

20 12

14 1

1

1

1

19 17 18

15 16

1

13 11

19

11

1

21 19

1
2

7

5

8

43

19
2

ITEM

PART

NUMBER NUMBER

DESCRIPTION

1

AF250-01 SCREW

2

AF250-02 WIRE GRILLS

3

AF250-03 NUT

4

AF250-04 FLAT WASHER

5

AF250-05 FAN BLADE

6

AF250-06 BLADE BACKING WASHER

7

AF250-07 AC MOTOR

8

AF250-08 RIVET

9

AF250-09 MULTI FOOR FAN SHELL

10

AF250-10 RIVET

QTY
10 2 1 1 1 1 1 4 1 12

ITEM

PART

NUMBER NUMBER

DESCRIPTION

QTY

11

AF250-11 RUBBER FOOT

12

12

AF250-12 POWER CORD

1

13

AF250-13 CAPACITOR

6

14

AF250-14 NUT, HEX

1

15

AF250-15 GASKET, SWITCH PLATE

1

16

AF250-16 SWITCH PLATE

1

17

AF250-17 ON/OFF ROCKER SWITCH, BLK 1

18

AF250-18 STRAIN RELIEF-LQ TIGHT

1

19

AF250-19 BUCKLE

2

20

AF250-20 BUCKLE

2

PURAERO’S WARRANTY POLICY
1-Year Warranty Subject to the conditions stated below. PURAERO offers a limited warranty on parts and labor on the following equipment, parts and accessories to be free from defects in material and workmanship for a period of one year to the original purchaser.
Wear items exempt from warranty consideration include but may not be limited to: power cords, transport wheels, castors, handle grips, filters, screens. Subject to the conditions and exceptions stated in this warranty. PURAERO warrants the PURAERO products to be free from defects in material and workmanship. Under normal use and service. for the periods listed under the warranty policy to the original purchaser. At any time during the warranty period, original owner will be liable for transportation costs to repair facility. PURAERO will furnish replacement parts for the PURAERO products to the original purchaser. Such parts will be fumished and charged including transportation costs, to the original owner. Replacement parts that have become defective through wear or abuse are not included in this warranty. This warranty does not apply to damage or defect caused by accident, misuse, negligence, fire or to any PURAERO product which has been serviced or repaired by other than an authorized PURAERO Service Distributor or PURAERO factory personnel. This warranty is void if products are used for any purpose other than that which was intended. There are no other warranties expressed or implied. In no event shall PURAERO be liable for incidental or consequential damages or any damage to person or property.(Please note some states do not allow the exclusion or limitations for incidental and consequential damages.)
