H1 LED Headlight Bulb
Product Information:
- Power: 110W
- Luminous Flux: 18000LM
- Color Temperature: 6500K (White)
- Light Source Model: CSP 3570 55mil
- Operating Voltage: 12V
- Operating Temperature: -40°C to +120°C
- Longevity: 100,000 Hours
- Housing Material: Aviation Aluminum
- Color Rendering Index: 90
- Waterproof Level: IP68
Product Usage Instructions:
H1/H3/H4/H7
- Installation: Position the light source at the 9 o’clock
position and secure it in place. - Adjustment: Rotate the light source to the 3 o’clock position
for optimal lighting angle. - Alignment: Align the light source at the 5 and 7 o’clock
positions for proper beam orientation.
9005/9006/H11
- Installation: Position the light source at the 2 o’clock
position and secure it in place. - Adjustment: Rotate the light source to the 9 o’clock position
for optimal lighting angle. - Alignment: Align the light source at the 3 and 4 o’clock
positions for proper beam orientation. - Additional Alignment: Align the light source at the 6 and 8
o’clock positions for further beam adjustment.
Manual version: V 22.01
Power Luminous Flux Color Temperature Light Source Model Operating Voltage Operating Temperature Longevity Housing Material Color Rendering Index Waterproof Level
110W 18000LM 6500K White CSP 3570 55mil 12V – 4 0~ + 1 2 0 100000 Hours Aviation Aluminum 90 IP68
H1/H3/H4/H7
1
3
9 O’CLOCK
3 O’CLOCK
5
7
9005/9006/H11
2
1
2
9 O’CLOCK
3 O’CLOCK
4
3
4
6
5
6
8
7
Manual version – V 22.01
