WC01051 Evolution Wheelchair
Product Information
The CareCo Evolution Wheelchair (Product Code: WC01051) is a
mobility aid that is designed to assist users in moving around
comfortably. It comes with various parts, including a backrest
cover, armrest, seat cover, footrest pedals, front wheel, push
handle, rear wheel brake, backrest lock, storage bag, detachable
large wheels, and small rear wheels. The wheelchair is easy to set
up and use, and it also comes with special features.
List of Parts
The following is a list of parts included with the CareCo
Evolution Wheelchair:
- Backrest Cover
- Armrest
- Seat Cover
- Footrest Pedals
- Front Wheel
- Push Handle
- Rear Wheel Brake
- Backrest Lock
- Storage Bag
- Detachable Large Wheels
- Small Rear Wheels
Specification
The specifications of the CareCo Evolution Wheelchair are not
provided in the user manual. Please refer to the product sticker
for more information.
Special Features
The CareCo Evolution Wheelchair comes with special features that
are not mentioned in the user manual. Please refer to the product
sticker for more information.
Warranty
The CareCo Evolution Wheelchair comes with a comprehensive
twelve-month warranty from the date of delivery. The warranty
covers the wheelchair for repairs or replacement during this
period. For more information, please refer to the warranty
conditions provided by the manufacturer.
Product Usage Instructions
Set up upon arrival
Follow the steps below to set up the CareCo Evolution Wheelchair
upon arrival:
Step 1
Lift up the backrest until you hear the click sound from the
backrest lock.
Step 2
Push both of the seat frames from the top. Make sure not to
leave your fingers in between the seat and armrest to prevent
injury.
Step 3
To install the detachable large wheel, press the button in the
center of the large wheel, and push it into the Pin-Socket. To take
it out, reverse the process.
Step 4
If you plan to wash the seat and backrest cover by washing
machine, kindly put them into the protection net before doing
so.
Step 5
Insert the footrests sideways as shown in the photo below.
Step 6
Grab the lock handlebar and flip the direction to be aligned
with the armrest direction.
Step 7
Loosen up the nuts to adjust the length of the footrest.
OWNERS HANDBOOK
Product Code WC01051
Your CareCo Evolution Wheelchair
1 2
3
4 5
List of Parts
1. Backrest Cover 2. Armrest 3. Seat Cover 4. Footrest Pedals 5. Front Wheel
Your CareCo Evolution Wheelchair
6 7 8 9 10
11
List of Parts
6. Push Handle 7. Rear Wheel Brake 8. Backrest Lock 9. Storage Bag 10. Detachable Large Wheels 11. Small Rear Wheels
Specification
Max User Weight: 110kg / 242lbs Seat Width: 45.5cm / 17.9″ Seat Depth: 40cm / 15.7″ Seat Height: 47.5cm/18.7″ Total Weight (With Rear Wheels): 17.5kg /38.5lbs Travel Weight (W/O Rear Wheels and Footrests): 10.4kg/22.9lbs Folded Size(LxWxH): 78cm x 32.5cm x 68cm/ 30.7″ x 12.8″ x 26.7″ Open Size(LxWxH): 103cm x 67cm x 92cm/ 40.5″ x 26.3″ x 36.2″ Tyre Type: PU Tyre Wheel Size: Front Wheels 6″| Small Rear Wheels 7″/ Large Rear Wheels 22″ Seat and Backrest Cover: Detachable and Washable Backrest: Foldable Footrest: Detachable and Height Adjustable Armrest: Raisable and Detachable
Set up upon arrival
Step 1 Lift up the backrest until you hear the click sound from backrest lock.
backrest lock
Set up upon arrival
Step 2 Push both of the seat frame from top.
WARNING Do not leave your fingers in between seat and armrest to prevent unnecessary injury.
Set up upon arrival
Step 3 To install the detachable large wheel, press the button in the center of large wheel, and push into the Pin-Socket. To take out, just reverse the process.
Step 4 If you plan to wash the seat and backrest cover by washing machine, kindly put into the protection net before doing so.
Set up upon arrival
Step 5 Insert the footrests side ways as the photos below.
Step 6 Grab the lock handle bar and flip the direction to be aligned as the armrest direction.
Set up upon arrival
Step 7 Loosen up the nuts to adjust the length of footrest.
Special Features
· Detachable Large Rear Wheels
Special Features
· Light Travel Mode
· Raisable Armrest · Detachable Footrest · Foldable Backrest
Warranty
There is a comprehensive twelve-month warranty from the date on which your new wheelchair is delivered. The warranty covers the wheelchair for repairs or replacement during this period. For more detail, please see the following warranty conditions.
· Any work or replacement part installation must be carried out by an authorised CareCo dealer / service agent.
· To apply the warranty should your wheelchair require attention please contact CareCo.
· Should any part of the wheelchair require repair or full or part replacement, as a result of a manufacturing or material defect within the warranty period, parts will be supplied free of charge. Note: The guarantee is not transferable.
· Any repaired or replaced parts will be covered by the balance of the warranty period on the wheelchair.
· Parts replaced after the original warranty has expired will be covered by a three-month warranty.
· Consumable items supplied will not generally be covered during the normal warranty period unless such items require repair or replacement clearly as a direct result of a manufacturing or material defect. Such items include (among others): upholstery and tyres.
· Under normal circumstances, no responsibility will be accepted where the wheelchair has required assistance as a direct result of: a. the wheelchair part not having been maintained in accordance with the manufacturers recommendations b. failure to use the manufacturer’s specified parts c. the wheelchair or part having been damaged due to neglect, accident or improper use d. the wheelchair or part having been altered from the manufacturer’s specification or repairs having been attempted before the dealer is notified
The manufacturer reserves the right to alter without notice any weights, measurements or other technical data shown in this manual. All figures, measurements and capacities shown in this manual are approximate and do not constitute specifications.
