S221200003 Stumpjumper Mountain Bike

Product Information: Chain Guide & Chain Cover Mounts

The Chain Guide & Chain Cover Mounts are specialized bicycle
components manufactured by Specialized Bicycle Components. The
product includes a chain guide mount bracket, inner and outer
plate, mounting nut, O-ring, frame mounting bolts, mounting bolt,
spacers, front bracket, chain cover bolts, and chainstay bracket.
The product is compatible with Vado and Como models.

Technical Guide

Part Name	Part Number	Quantity	Specification	Tool	Torque (Nm)	Torque (in-lbf)
Chain Guide – Mount Bracket	TERO S221200003	1	CHG MY22 TERO X CHAINGUIDE	N/A	N/A	N/A
Chain Cover – Frame Bracket	Part of Kit VADO S219900052 / Part of Kit COMO S219900060	1 / 1	M5 mm x 10 mm x 0.8 mm P	N/A	N/A	N/A
Chain Cover – Cover	Part of Kit VADO S219900052 / Part of Kit COMO S219900060	1 / 1	M5 mm x 10 mm x 0.8 mm P	N/A	N/A	N/A
Chain Cover – Chainstay Bracket	Part of Kit VADO S219900052 / Part of Kit COMO S219900060	1 / 1	M5 mm x 10 mm x 0.8 mm P	3 mm hex	N/A	N/A

Note: The technical guide also includes information on tools and
torque required for each part.

Product Usage Instructions: Chain Guide & Chain Cover
Mounts

Insert the chain guide mount bracket onto the bike frame,
following the assembly process order.
Attach the inner and outer plate onto the chain guide mount
bracket, ensuring that the assembly direction is correct.
Apply grease on the mounting nut and insert it into the chain
guide mount bracket.
Place the O-ring on the mounting bolt and insert it into the
chain guide mount bracket.
Insert the spacers onto the mounting bolt and tighten the bolt
to the specified torque using a 5mm hex tool.
Attach the front bracket onto the bike frame using the M5 x
10mm x 0.8mm P bolts and a 3mm hex tool.
Attach the chain cover onto the bike frame using the M5 x 10mm
x 0.8mm P bolts and a 3mm hex tool.

Product Information: Spider and Crank Assembly

The Spider and Crank Assembly is a specialized bicycle component
manufactured by Specialized Bicycle Components. The product
includes a chain ring, chain ring bolts, spider, spider groove nut,
crank DS, crank NDS, O-ring, chainwheel protector, and Brose cap
puller. The product is compatible with Vado, Como, and Tero
models.

Technical Guide

Part Name	Part Number	Quantity	Specification	Tool	Torque (Nm)	Torque (in-lbf)
Chain Ring	S211400005 / S211400003	1	Praxis 48t – 104 mm BCD / Chain Ring 36t or 40t (TERO EQ)	N/A	N/A	N/A
Chain Ring Bolts	S211600026 / S166800011 / S211600027 / S211600028	4	M8 x 6.5 mm x 0.75 mm P	5 mm hex	N/A	N/A
Spider	S211600026	1	104 mm BCD	N/A	10	89
Spider Groove Nut	S166800011	1	Levo ISIS Groove Nut	ParkTool BBT-18 or Shimano TL-UN96	N/A	N/A
Crank DS / Crank NDS	S211600027 / S211600028 / S221600011 / S211200010 / S175300006	1 / 1	Brose Praxis 170 mm Alloy / O-Ring, 23.5 mm ID x 2.4 mm OD, Drive Side / Vado Chain Guard, 48t, Praxis 1	8 mm hex / Grease / Phillips Head Screwdriver	50 / 40 / 40	443 / 354 / 354
O-Ring	S211200010	1	23.5 mm ID x 2.4 mm OD, Drive Side	N/A	N/A	N/A
Brose Cap Puller	S175300006	1	N/A	N/A	N/A	N/A

Note: The technical guide also includes information on tools and
torque required for each part.

Product Usage Instructions: Spider and Crank Assembly

Attach the spider onto the bike frame using the specified
torque.
Attach the chain ring onto the spider using the chain ring
bolts and a 5mm hex tool.
Insert the spider groove nut into the crank DS and tighten it
using the specified tool.
Insert the crank DS and crank NDS onto the bike frame, ensuring
that the assembly direction is correct.
Apply grease on the O-ring and insert it onto the drive side
crank arm.
Attach the chainwheel protector onto the bike frame.
Use the Brose cap puller to remove the Brose cap, if
necessary.

View Fullscreen

TECHNICAL GUIDE
SCHEMATIC – SMALL PARTS

SCHEMATICS – SMALL PARTS
INDEX
CHAIN GUIDE & CHAIN COVER MOUNTS …………………………………….3 CHAIN COVER MOUNTS ……………………………………………………….4 S P I D E R A N D C R A N K A S S E M B LY ( VA D O / C O M O ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 S P I D E R A N D C R A N K A S S E M B LY ( T E R O ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 MOTOR COVERS ………………………………………………………………. 7 M OTO R M O UN T I N G B O LTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 MOTOR CONNECTORS …………………………………………………………9 HEADSET ……………………………………………………………………. 10 STEM – FLOW STEM …………………………………………………………. 11 ST E M – ST E A LT H ST E M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 INTEGRATED HANDLEBAR – COMO ………………………………………… 13 INTEGRATED HANDLEBAR – COMO – MASTERMIND TCU ………………… 14 ICR – HEADTUBE PORTS……………………………………………………. 15 ICR – DOWNTUBE GUIDE …………………………………………………… 16 BATTERY LOCK AND CONNECTORS ………………………………………… 17 BATTERY LOCK AND HOOK …………………………………………………. 18 LOCK MECHANISIM – EXPLODED ………………………………………….. 19 KICKSTAND ………………………………………………………………….. 20 REAR RACK ………………………………………………………………….. 21 REAR FENDERS……………………………………………………………… 22 FRONT RACK ………………………………………………………………… 23 FRONT FENDER……………………………………………………………… 24 FRONT LIGHT ……………………………………………………………….. 25 GARMIN RADAR……………………………………………………………… 26 SEATPOST …………………………………………………………………… 27 SPEED SENSOR – ROUTING………………………………………………… 28 SPEED SENSOR – DROPOUT ……………………………………………….. 29 D E R A I L L E U R H A N G E R & C H A I N STAY G UA R D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 0 E R R O R C O D E S & FACTO RY R E S E T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1 SERVICE PARTS …………………………………………………………….. 32 TORQUE SPECIFICATIONS & GUIDE TUBE LENGHTHS …………………… 33

SYMBOLS LEGEND
A

PART NUMBER

ASSEMBLY PROCESS ORDER

INSERT PATH

ASSEMBLY DIRECTION

GREASE

BLUE THREADLOCKER

TORQUE REQUIRED

VIDEO GUIDE AVAILABLE

TECHNICAL GUIDE

SPECIALIZED BICYCLE COMPONENTS
15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229 0000177255_SC_R1, 09/21

We may occasionally issue updates and addendums to this document. Please periodically check www.specialized.com or contact Rider Care to make sure you have the latest information. Info: www.specialized.com

CHAIN GUIDE & CHAIN COVER MOUNTS

GA H BH C ED

J
L
F
K 1

# PART NAME
A Chain Guide – Mount Bracket B Chain Guide – Inner Plate C Chain Guide – Outer Plate D Mounting Nut E O-Ring F Frame Mounting Bolts G Mouting Bolt H Spacers

PART NUMBER
TERO S221200003

QTY

SPEC

1 CHG MY22 TERO X CHAINGUIDE 1 1 1 M8 x 1.0 mm P 1 O-RING 9 mm ID x 1.5 mm W 2 M5 x 10 mm 0.8 mm P 1 M8 x 1.0 mm P, SLOT 3 8.2 mm ID X 12 mm OD x 1 mm W

TOOL
N/A N/A N/A 5 mm hex N/A T25 Torx N/A N/A

TORQUE

Nm in-lbf

N/A

4.5

N/A

4.5

N/A

# PART NAME
I Chain Cover – Frame Bracket J Chain Cover – Front Bracket (Vado) K Chain Cover – Bolts L Chain Cover – Frame Bracket M Chain Cover – Front Bracket (Como) K Chain Cover – Bolts

PART NUMBER QTY

SPEC

PART OF KIT VADO S219900052
PART OF KIT COMO S219900060

1 1 3 M5 mm x 10 mm x 0.8 mm P 1 1 3 M5 mm x 10 mm x 0.8 mm P

TECHNICAL GUIDE

TOOL
N/A N/A 3 mm hex N/A N/A 3 mm hex

TORQUE

Nm in-lbf

N/A

4.5

N/A

4.5

PAGE 3

CHAIN COVER MOUNTS
C
A

# PART NAME
A Chain Cover – Cover B Chain Cover – Chainstay Bracket C Chain Cover – Bolts A Chain Cover – Cover B Chain Cover – Chainstay Bracket C Chain Cover – Bolts

PART NUMBER QTY

SPEC

PART OF KIT VADO S219900052
PART OF KIT COMO S219900060

1 1 3 M5 mm x 10 mm x 0.8 mm P 1 1 3 M5 mm x 10 mm x 0.8 mm P

TECHNICAL GUIDE

TOOL
N/A N/A 3 mm hex N/A N/A 3 mm hex

TORQUE

in-lbf

N/A

4.5

N/A

4.5

C
C C
COMMENT
PAGE 4

SPIDER AND CRANK ASSEMBLY (VADO / COMO)
G A

B C D E
F

# PART NAME
A Chain Ring 48 t B Chain Ring Bolts C Spider D Spider Groove Nut E Crank DS E Crank NDS F O-Ring G Chainwheel Protector H Brose Cap Puller
TECHNICAL GUIDE

PART NUMBER
S211400005
S211600026 S166800011 S211600027 S211600028 S221600011 S211200010 S175300006

QTY

SPEC

1 Praxis 48 t – 104 mm BCD 4 M8 x 6.5 mm x 0.75 mm p 1 Spider,104 mm BCD 1 Levo ISIS Groove Nut 1 Brose Praxis 170 mm Alloy 1 Brose Praxis 170 mm Alloy 1 O-Ring, 23.5 mm ID x 2.4 mm OD, Drive Side 1 Vado Chain Guard, 48t, Praxis 1

TOOL
N/A 5 mm hex N/A ParkTool BBT-18 or Shimano TL-UN96 8 mm hex 8 mm hex Grease Phillips Head Screwdriver N/A

TORQUE

Nm in-lbf

N/A

443

354

N/A

D1 H2

COMMENT

PAGE 5

SPIDER AND CRANK ASSEMBLY (TERO)

G : EQ MODEL ONLY A

B C D E
F

# PART NAME
A Chain Ring 36 t B Chain Ring Bolts A Chain Ring 40 t (TERO EQ) B Chain Ring Bolts (TERO EQ) H Chainring Protector (TERO EQ) C Spider D Spider Groove Nut E Crank DS E Crank NDS F O-Ring G Brose Cap Puller
TECHNICAL GUIDE

PART NUMBER
S211400003
S211400004
S211200008 S195100001 S166800011 S211600027 S211600028 S221600011 S175300006

QTY
1 4 1 4 1 1 1 1 1 1 1

SPEC
Praxis 36 t – 104 mm BCD M8 x 6.5 mm x 0.75 mm p Praxis 40 t – 104 mm BCD M8 x 6.5 mm x 0.75 mm p MSC VADO CHAIN GUARD, 40T, PRAXIS SPIDER,104 mm BCD Levo ISIS Groove Nut Brose Praxis 170 mm Alloy Brose Praxis 170 mm Alloy O-RING, 23.5 mm ID x 2.4 mm OD, Drive Side

TOOL
N/A 5 mm hex N/A 5 mm hex Phillips Head Screwdriver N/A ParkTool BBT-18 or Shimano TL-UN96 8 mm hex 8 mm hex Grease N/A

TORQUE

Nm in-lbf

N/A

443

354

N/A

COMMENT

PAGE 6

MOTOR COVERS

C
B A

# PART NAME
A DS Motor Cover Assembly B NDS Motor Cover C Custom Motor Cover Nut

PART NUMBER
Part Of Motor Cover Kit S219900056

QTY

SPEC

1 With moulded thru bolts 1 2 M4 x 8 mm x 0.7 mm P

TOOL
N/A N/A T20 Torx

TORQUE

in-lbf

N/A

0.8

TECHNICAL GUIDE

COMMENT
PAGE 7

MOTOR MOUNTING BOLTS

B C
A

# PART NAME
A Mounting Bolt B Mounting Bolt Washer C Serated Nut

PART NUMBER
S210500017

QTY

SPEC

1 M8 x 50 mm x 1.25 p Steel Black 1 M8 x 8.4 mm ID x 16 OD X1.6 mm 3 M8 x 1.25 p serated

TOOL
5 mm hex key N/A
13 mm Socket Wrench

TORQUE

in-lbf

203

N/A

203

TECHNICAL GUIDE

COMMENT
PAGE 8

MOTOR CONNECTORS

NYOGEL 760G

BATTERY HMI/DISPLAY E-BIKE FRONT REAR SPEED LIGHT LIGHT SENSOR

BLIND PLUG
plug without pins to seal
unused motor ports

BROSE SPECIALIZED DESIGNATION CONFIGURATION

Battery

E-Bike

Blind Plug

Speed Sensor

Rear Light

Rear light

Front Light

Front light

Display (HMI)

# PART NAME
A Blind Plug B Motor

PART NUMBER QTY

SPEC

S216800024 S216800027

1 1 Specialized Drive Side Loader

It is also recommended that Nyogel 760G (special electrical contact grease) be applied to all ports at the motor. CAUTION: Make sure all ports not used are sealed with a blind plug.

TOOL
N/A N/A

TORQUE

in-lbf

N/A

COMMENT

TECHNICAL GUIDE

PAGE 9

HEADSET

HS S 01

HS S 02

# PART NAME PART NUMBER QTY BIKE

SPEC

A Micro Spacer B Compresion Ring C Upper Bearing D Lower Bearing E Crown Race F Cone Spacer G Micro Spacer H Compresion Ring I Upper Bearing J Lower Bearing K Crown Race

HS-S-01 HS-S-02

H2249 Alloy Compression Ring 49 ALLOY COMPRESSION RING

1 Vado 3.0 / 4.0 / 5.0 MR121 Upper 1.125″ Campy 45° Cartridge Bearing

MR127 Lower 1.5 In” Campy 36/45° Cartridge Bearing

H6083 Alloy Split Style Crown Race

1 Tero 4.0 / 5.0 / 1 VADO S

H2216 Cone Spacer 52.2 mm Sand Black

1 Headset for tapered H2249 Alloy Compression Ring

1 1.5″ steerer fork – MR121 Upper 1.125″ Campy 45° Cartridge Bearing

1 for Tero 4.0 and 5.0 MR127 Lower 1.5 In” Campy 36/45° Cartridge Bearing

1 models

H6083 Alloy Split Style Crown Race

TECHNICAL GUIDE

HS S 02 1

HS S 03

# PART NAME PART NUMBER QTY

BIKE

SPEC

L Cone Spacer M Micro Spacer N Compresion Ring O Upper Bearing P Lower Bearing Q Crown Race R Micro Spacer S Compresion Ring T Upper Bearing U Lower Bearing V Crown Race

HS-S-02-1 HS-S-03

H2216 Cone Spacer 52.2 mm Sand Black

1 Tero 3.0 1

H2433 Alloy Compression Ring MR121 Upper 1.125″ Campy 45° Cartridge Bearing

MR127 Lower 1.5 In” Campy 36/45° Cartridge Bearing

H6165 Alloy Split Style Crown Race

H2564 Nylon Compression Ring

1 Como 3.0 / 4.0 / 5.0 MR121 Upper 1.125″ Campy 45° Cartridge Bearing

MR127 Lower 1.5 In” Campy 36/45° Cartridge Bearing

H6091 Alloy Split Style Crown Race

PAGE 10

STEM – FLOW STEM
A A D C
B B B B E F

# PART NAME
A Flow-Set Stem Faceplate Bolts & Washers B Flow-Set Stem Steerer Bolts & Washers C Flow-Set Stem Top Cap Bolt D Flow-Set Stem E Flow-Set Stem Spacers F Flow-Set Stem Cone Spacer G MasterMind TCD H MasterMind TCD Mount Bracket I MasterMind TCD Security Screw
TECHNICAL GUIDE

PART NUMBER QTY

SPEC

4 60 mm S154800016 2

75 mm S154800017 1 1

S204800004

3 1

S216800041

1 MasterMind TCD with Remote

48119-1405

1 1 M2.5 x 5 mm x 0.45 p S Steel

TOOL
4 mm hex key 4 mm hex key 5 mm hex key
N/A N/A N/A N/A N/A Phillips Head Screwdriver

TORQUE

in-lbf

N/A

G I J H
COMMENT
PAGE 11

STEM – STEALTH STEM

A G
D

C I
C J

I
B H

# PART NAME
A Stealth Stem Faceplate Bolts & Washers B Stealth Stem Steerer Bolts & Washers C Stealth Stem Top Cap and Bolt D Stealth Stem E Stealth Stem Spacers F Stealth Cone Spacer G MasterMind TCD H MasterMind TCD Mount Screw and Nut I MasterMind TCD Mount Bracket (Stealth Stem) J MasterMind TCD Security Screw (Stealth Stem)
TECHNICAL GUIDE

PART NUMBER
S194800003
Part of HS S216800041 S219900057

QTY

SPEC

4 2 1 1 3 1
MasterMind TCD with remote 1 Nut: M3 S Steel Bolt: M3 x 11 x 0.75 p 1 Dovetail Mount and Twistlock Mount 1 M2.5 x 5 mm x 0.45 p S Steel

TOOL
4 mm hex key 4 mm hex key 5 mm hex key
N/A N/A N/A N/A 2.5 N/A Phillips Head Screwdriver

TORQUE

in-lbf

N/A

COMMENT
PAGE 12

INTEGRATED HANDLEBAR – COMO

F E

A
B C G

# PART NAME
A Integrated Handlebar B Handlebar Locking Clamp C Handlebar Clamp Bolts D Steerer Locking Clamp Cover E Top Cap F Top Cap Bolt G Stem Spacer
TECHNICAL GUIDE

PART NUMBER QTY

SPEC

S210800013
PART OF KIT S219900014 S212500002

1 Intergrated Handlebar 1 Locking Cap, 28.6 mm 4 M5 x 16 mm x 0.8mm P 1 1 TOP CAP, COMO SL INTEGRATED BAR 1 1

TOOL
N/A N/A TX 25 N/A N/A 5 mm HEX N/A

TORQUE

in-lbf

N/A

6.2

N/A

COMMENT
Also supplied in S219900014 Use blue threadlock
Align display mount holes with the front wheel. Use blue threadlock

PAGE 13

INTEGRATED HANDLEBAR – COMO – MASTERMIND TCU
G
D E
F B C
G
B
E
A

# PART NAME
A MM TCD Handlebar Mount B MM TCD Handlebar Mount Screws C MM TCD Twistlock Mount Base D MM TCD Twistlock Mount Top E MM TCD Twistlock Mount Screw and Nut F MM TCD Twistlock Mount Security Screw G MasterMind TCD with Remote
TECHNICAL GUIDE

PART NUMBER QTY

SPEC

S219900014 S220800009 S219900057 S216800041

1 2 M3 x 18 mm 0.5 mm p 1 1 1 Nut: M3 S Steel | Bolt: M3 x 11mm x 0.75 mm p 1 M2.5 x 5 mm x 0.45 p S Steel
MasterMind TCD with remote

TOOL
N/A 3 mm HEX
N/A N/A 2.5 mm hex key Phillips Head Screwdriver N/A

TORQUE

in-lbf

N/A

COMMENT
Use to cover the dicplay mount when no TCD is fitted Use threadlock. Do not over-torque. Use the upper part of the Stealth Stem MM TCD mount

PAGE 14

ICR – HEADTUBE PORTS
1
A

C A

B
DRIVE SIDE

# PART NAME
A ICR Port Inversal 2 Cable Port B ICR Port Screw C ICR Port Universal Base

PART NUMBER QTY

SPEC

PART OF KIT S216500008

2 2 M3 x 18 mm x 0.5 mm p 2

TECHNICAL GUIDE

TOOL
N/A T10 Torx
N/A

TORQUE

in-lbf

N/A

0.8

N/A

B
NON-DRIVE SIDE
COMMENT

PAGE 15

ICR – DOWNTUBE GUIDE

ENVIOLO

DROPPER BRAKE

4 mm

5 mm

HMI 3.5 mm

3.5 mm 4 mm HORN SHIFT
ENVIOLO

4 mm LIGHT

# PART NAME A ICR Downtube Guide

PART NUMBER QTY

SPEC

PART OF KIT S216500008

1 2 x 3.5 / 3 X 4.0mm / 1 x 5.0 mm Self Adhesive

TORQUE

TOOL

in-lbf

N/A

TECHNICAL GUIDE

COMMENT
PAGE 16

BATTERY LOCK AND CONNECTORS

# PART NAME A Lower Battery Lock Mechanisim B Motor / Battery Cable C Motor / Battery Cable Bolts D Radar Y Splitter Cable E Radar Splitter Cable Bolt F Lock Replacement Cylinder
TECHNICAL GUIDE

PART NUMBER S216800036 S216800034
S216800033 S219900051

QTY

SPEC

1 1 2 M3 x 8 mm x 0.5 mm p / 304 S Steel 1 Y-Splitter 3 Cables 1 M4 x 16 mm x 0.7 mm p 1

TOOL
N/A N/A 2 mm hex key N/A 3 mm hex key

TORQUE

in-lbf

N/A

8.8

N/A

COMMENT
PAGE 17

BATTERY LOCK AND HOOK
F B

CA H

G ED

G IL

# PART NAME

PART NUMBER QTY

SPEC

A Battery Charge Port Cover B Battery Cover Mount Bracket C Battery Charge Port Cover Screws D Battery Lever E Battery Lever Bolt F Battery Charger Magnetic Flap G Downtube Battery Seal H Battery Mount Lower I Battery Mount Screws

S216800035
S219900053 S216800036

1 1 3 M2 x x 10 mm x 0.45 mm p 1 1 M4 x 25 mm x 0.7 mm p 1 Avialable Separately S216800051 1 1 Battery lock 3 M4 x 18 mm x 0.7 mm p

TECHNICAL GUIDE

TOOL
N/A N/A 1.5 mm hey Key N/A 3 mm hex key N/A N/A N/A T20 Torx

TORQUE

Nm in-lbf

N/A

1.5

13.2

N/A

26.5

N/A

# PART NAME
J Battery Mount Upper K Battery Mount Screws L Battery Mount Screws Kit

PART NUMBER QTY

SPEC

S216800040 S210500015

1 BATTERY HOOK 3 M4 x 18 mm x 0.7 mm p 3 M4 x 18 mm x 0.7 mm p

TOOL
N/A T20 Torx T20 Torx

TORQUE

Nm in-lbf

N/A

3.3

PAGE 18

KICKSTAND

C A

# PART NAME
A Kickstand (TERO) B Kickstand Bolts C Kickstand (VADO) D Kickstand Bolts E Kickstand Mouting Plate F Kickstand Plug (Not shown)

PART NUMBER
S219900050
S179900045 S219900062 S219900005

QTY

SPEC

1 Tero 2 M6 x 14 mm x 1.0mm S Steel / 1mm Washer S Steel 1 Vado / Como 2 M6 x 14 mm x 1.0mm S Steel / 1mm Washer S Steel 1 MY22 Como Kickstand Hardware Kit 2

TECHNICAL GUIDE

TOOL
N/A M5 hex key
N/A M5 hex key
N/A N/A

TORQUE

in-lbf

N/A

COMMENT
Place the kickstand plate between the kickstand mount and the inside of the chainstay Plugs for unused kickstand mount on non-EQ models

PAGE 19

REAR RACK

B A
C

# PART NAME

PART NUMBER QTY

SPEC

TOOL

A Rear Rack 700c (TERO) B Rear Rack 650b (VADO / COMO) C Mouting Bolts

S211700003 S211700001

1 SPL48 – 700c – 27 kg 1 SPL47 – 650b – 27 kg 2 M5 mm x 5 mm

N/A N/A 5 mm hex

The rear rack is combined with the rear fender and is attached with bolts to mounting tabs at the dropouts to support the vertical rack stays.

TORQUE

in-lbf

N/A

TECHNICAL GUIDE

COMMENT
PAGE 20

REAR FENDERS
A B

# PART NAME

PART NUMBER QTY

SPEC

Vado /Como Fender Front 650B (Suntour Fork)

S212200008

Use with Suntour Fork / 65C width

Vado /Como Fender Front 650B (SRAM Fork)

S212200007

Use with SRAM Fork / 65C width

Vado /Como Fender Rear 650B (STD) A
Vado /Como Fender Rear 650B (Garmin)

S212200009 S212200010

Use with Vado 3.0 & 4.0 models / 65C width Use with Vado 5.0 models equipped with Garmin Radar / 65C width

Tero Fender Front 700C

S212200005

OE spec on Tero 4.0 EQ models / 65C width

Tero Fender Rear 700C

S212200006

OE spec on Tero 4.0 EQ models / 65C width

B Mouting Bolt Chainstay Bridge C Mouting Bolt Seatstay bridge

1 M5 mm x 5 mm (Included with kit) Part of individual Kits
1

TECHNICAL GUIDE

TOOL
N/A N/A N/A N/A N/A N/A 4 mm hex 4 mm hex

TORQUE

in-lbf

N/A

COMMENT
PAGE 21

FRONT RACK
B

C
B
AB

# PART NAME

PART NUMBER QTY

SPEC

A Headset Cover B Headset Cover Bolt

See Details

1 Various Colour Models 1 Custom Screw M5 x 5 mm x 0.8 mm p

# PART NAME
A Headset Cover

PART NUMBER
S229900001 S229900002 S229900003 S229900004 S229900005

QTY

SPEC

1 MSC MY22 COMO HEADTUBE COVER, LIMESTONE / BLACK REFLECTIVE 1 MSC MY22 COMO HEADTUBE COVER, SAND / BLACK REFLECTIVE 1 MSC MY22 VADO/TERO HEADTUBE COVER, CAST BLACK / SILVER REFLECTIVE 1 MSC MY22 VADO/TERO HEADTUBE COVER, OAK GREEN METALLIC / SMOKE 1 MSC MY22 VADO/TERO HEADTUBE COVER, RED ONYX / SMOKE

TECHNICAL GUIDE

TOOL
N/A 2.5 mm HEX

TORQUE

in-lbf

N/A

8.8

COMMENT

# PART NAME
A Headset Cover

PART NUMBER
S229900006 S229900007 S229900008 S229900009 S229900010

QTY

SPEC

1 MSC MY22 VADO/TERO HEADTUBE COVER, RED TINT / SILVER REFLECTIVE 1 MSC MY22 VADO/TERO HEADTUBE COVER, REDWOOD / BLACK 1 MSC MY22 VADO/TERO HEADTUBE COVER, SMOKE / BLACK REFLECTIVE 1 MSC MY22 VADO/TERO HEADTUBE COVER, WHITE MOUNTAINS / BLACK REFLECTIVE 1 MSC MY22 VADO/TERO HEADTUBE COVER, WHITE MOUNTAINS / GUNMETAL

PAGE 22

FRONT FENDER
B

# PART NAME

PART NUMBER QTY

SPEC

Vado /Como Fender Front 650B (Suntour Fork) Vado /Como Fender Front 650B (SRAM Fork) Vado /Como Fender Rear 650B (STD) A Vado /Como Fender Rear 650B (Garmin) Tero Fender Front 700C Tero Fender Rear 700C B Mouting Bolt Fork Arch C Mouting Bolt Fork

S212200008 S212200007 S212200009 S212200010 S212200005 S212200006
Part of Fender Kit

1 Use with Suntour Fork / 65C width 1 Use with SRAM Fork / 65C width 1 Use with Vado 3.0 & 4.0 models / 65C width 1 Use with Vado 5.0 models equipped with Garmin Radar / 65C width 1 OE spec on Tero 4.0 EQ models / 65C width 1 OE spec on Tero 4.0 EQ models / 65C width 2 2

TECHNICAL GUIDE

TORQUE

TOOL

in-lbf

4 mm hex

COMMENT
PAGE 23

FRONT LIGHT
2
B

2 B2 2

B4 3
2
B
1

TECHNICAL GUIDE

PAGE 24

GARMIN RADAR

# PART NAME A Garmin Radar Mount B Garmin Radar Mount Bolts C Garmin Radar Rack Mount Bolt D Integrated Rear Light E Integrated Rear Light Cable
TECHNICAL GUIDE

PART NUMBER QTY

SPEC

S211700002
S225800006 S216800037

1 2 M4 x 5 mm x 0.7 mm p 2 M3 x 14 mm x 0.5 mm p 1 LGT REAR, SPANNIGA COMMUTER GLOW R581001, INTEGRATED RACK MOUNT, W/O WIRE 1 ELE MY22 VADO/TERO REAR LIGHT CABLE, 12V, 2 WIRES

TOOL
3 mm hex 2 mm hex

TORQUE

in-lbf

COMMENT
PAGE 25

SEATPOST

# PART NAME

PART NUMBER QTY

SPEC

TORQUE

TOOL

in-lbf

D Seatpost Clamp (VADO / TERO)

S184700003

1 34.9 mm with bolt

4 mm hex

6.2

E Seatpost Clamp (COMO)

S214700006

1 42.9 mm with bolt

4 mm hex

6.2

F Seat Tube Shim (COMO ONLY Not Shown)

S174900001

1 30.9mm to 34.9mm shim COMO ONLY

N/A

MINIMUM INSERTION (A) The seatpost must be inserted into the frame deep enough so the minimum insertion/maximum extension (min/max) mark (C) on the seatpost is not visible. The frame requires a minimum of 80 mm of insertion (A).
MAXIMUM INSERTION (B) The seat tube is reamed to a specified maximum insertion depth for each frame size. This ream depth limits the insertion depth of the seatpost. If the desired seat height cannot be achieved within the minimum and maximum insertion requirements, the seatpost should be replaced with a shorter or longer one.

VADO MIN INSERTION (mm) MAX INSERTION (mm) COMO MIN INSERTION MAX INSERTION TERO MIN INSERTION MAX INSERTION

TECHNICAL GUIDE

COMMENT

for suspension posts on COMO 4.0 and 5.0 models
S 80 200 S 80 mm 220 mm S 80 200

M 80 260 M 80 mm 240 mm M 80 260

L 80 260 L 80 mm 250 mm L 80 260

XL 80 260
XL 80 260
PAGE 26

SPEED SENSOR – ROUTING

Speed sensor

# PART NAME
A Speed Sensor Cable B Speed Sensor Cable Holder C Spees Sensor Cable Holder Screw

PART NUMBER QTY

SPEC

S216800025 S216800038

1 Speed Sensor Cable 1 5 mm Cable Bat 1 M4 x 8 mm x 0.7 mm p,

TORQUE

TOOL

in-lbf

N/A

3 mm

COMMENT

WARNING! Dirt and/or metal debris may accumulate on the speed sensor magnet. Too much accumulation may result in interruptions in motor support and/or inaccurate speed readings. Regularly check your speed sensor magnet for an accumulation of dirt and/or metal debris, and clean accordingly. The frequency of the cleaning depends on your riding conditions, ride frequency, and/or brake pad material. Removing metal debris may require the use of a magnet stronger than the speed sensor magnet.

TECHNICAL GUIDE

PAGE 27

SPEED SENSOR – DROPOUT

A DE

# PART NAME

PART NUMBER QTY

SPEC

TORQUE

TOOL

in-lbf

COMMENT

A Speed Sensor Cable

S216800025

1 Speed Sensor Cable

N/A

B Speed Sensor Centerlock Mag Holder

S199900012

Cassette lock ring tool

354

C Speed Sensor 6 Bolt Mag Holder

S216800039

1 Use Rotor Bolts

as per manufacturer specs

6.2

55 Use the brake rotor mounting bolts

D Speed Sensor Cable Holder E Spees Sensor Cable Holder Screw

S216800038

1 5 mm Cable Bat 1 M4 x 8 mm x 0.7 mm p,

N/A

3 mm

WARNING! Dirt and/or metal debris may accumulate on the speed sensor magnet. Too much accumulation may result in interruptions in motor support and/or inaccurate speed readings. Regularly check your speed sensor magnet for an accumulation of dirt and/or metal debris, and clean accordingly. The frequency of the cleaning depends on your riding conditions, ride frequency and/or brake pad material. Removing metal debris may require the use of a magnet stronger than the speed sensor magnet.

When assembling the rear brake disc, the speed sensor magnet must be installed on the rotor. Four of the six bolts are standard rotor bolts. The remaining two bolts (M5 x 0.8 pitch x 15 mm length, with a countersunk flat head) attach the speed sensor magnet to the rotor.

TECHNICAL GUIDE

PAGE 28

DERAILLEUR HANGER & CHAINSTAY GUARD

D2 A

# PART NAME
A Amazinger Derailler Hanger 2.1 B Chainstay protector

PART NUMBER QTY

S172600003

S216900004

SPEC

TOOL
8 mm hex N/A

TORQUE

in-lbf

221

N/A

COMMENT
Use threadlock Align the hole on the protector with the chain guard mouting bolt on the DS chainstay

TECHNICAL GUIDE

PAGE 29

ERROR CODES & FACTORY RESET

+ x1
20
SEC

+ x2
45
SEC

MasterMind TCU equipped models have a built-in diagnostic system to automatically check and identify the functionality of the system. If the system detects an error, the MasterMind TCU will show the error on the display. In some cases, the error message can be dismissed by pushing any button on the remote. Depending on the type of error message, the system may be switched off automatically. If you receive an error message, please restart the system. If the error message continues to display, please contact your Authorized Specialized Retailer for further instructions. In any case, the bicycle can be ridden without motor support with the system turned off.
Mission Control supports the rider with User Actions for errors and diagnostic reports which can be shared with retailers who can give further advice based on the bicycle serial number.

MASTERMIND TCU RESET PROCESS:
Standard Reset Standard reset is the first troubleshooting step if an odd bike or display behavior occurs, such as failing to connect to MC after a previously successful connection. Standard reset restores the default Tune settings, including Acceleration Response and Shuttle. Dual press and hold the (+) and (-) buttons for 20 seconds. Release the buttons when the MasterMind TCU reboots. Factory Reset A factory reset should be performed before a new or used bicycle is handed over to a new rider. Factory Reset restores the system to factory settings, also clearing and resetting previous BLE pairings. Press and hold the (+) and (-) buttons for 45 seconds. During this process, the MasterMind TCU will reboot twice. Release the buttons when the MasterMind TCU reboots for the second time.

TECHNICAL GUIDE

PAGE 30

SERVICE PARTS
VADO / COMO / TERO
PART NAME Battery Battery Charge Port Cover Battery Charge Port Door Battery Downtube Rim Battery latch mounting hardware Battery Lock Cylinder Battery lower Mount with Lock Battery upper Mount Battery Wedge Belt Drive Cable – Battery to Radar Cable – Motor to Battery Cable – Motor to Display Cable Motor Display Chain Cover (Como) Chain Cover (Vado Tero) Chain Cover (Vado Tero) Chain Guide (Non EQ) Chainring (Tero EQ) Chainring (Tero) Chainring (Vado Como) Chainring Guard 48 t Chainring Guard 48 t Chainring Guard 48 t (Tero EQ) Chainring Mount Screws Cranks Cranks Derailleuer Hanger Dropout Cover (IGH) Fender Front 700C Fender Front 650B (SRAM) Fender Front 650B (Suntour) Fender Front 700C Fender Rear 650B Fender Rear 650B ( Garmin) Frame lock kit
Garmin Radar Mount
Handlebar (Como)
TECHNICAL GUIDE

BIKE Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero
Vado / Como / Tero Vado / Como / Tero Tero Como Como Vado / Tero EQ Vado Tero Tero non EQ Tero EQ Tero Vado / Como Vado / Como / Tero Vado / Como / Tero Tero EQ Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero
Vado / Como Tero (EQ) Vado / Como Vado / Como Tero (EQ) Vado / Como Vado / Como Vado / Como / Tero
Vado / Como
Como

NUMBER 98921-5634 S216800035 S216800051 S219900053 S210500017 S219900051 S216800036 S216800040 S226800013 S219900009 S216800033 S216800034 S194200010 S194200010 S219900060 S216900004 S219900052 S221200003 S211400004 S211400003 S211400005 S211200010 S179900050 S211200008 S220500002 S211600027 S211600028 S172600003 S219900054 S212200006 S212200007 S212200008 S212200005 S212200009 S212200010 S210500016
S211700002
S210800013

PART SPECIFICATION Specialized U2-710 Battery (Service-AM) Single pack (SBC-20) ELE MY22 VADO/TERO CHARGE PORT COVER W/ LATCH ELE MY22 VADO TERO CHARGE DOOR MSC MY22 VADO/TERO DOWNTUBE BATTERY COVER BLT MY22 VADO/TERO BATTERY LATCH MOUNTING HARDWARE MSC MY22 VADO/TERO BATTERY LOCK CYLINDER(5599 06 95) ELE MY22 VADO/TERO LOWER BATTERY MOUNT W/ LOCK HARDWARE ELE MY22 VADO/TERO UPPER BATTERY MOUNT W/HARDWARE ELE SUB, BATTERY WEDGE, M1 & U2, REV 2 MSC MY21 COMO SL BELT, CDX, 122T ELE MY22 VADO 5 & S, 3 CABLE Y SPLITTER FOR RADAR ELE MY22 VADO/TERO BATTERY TO MOTOR CABLE ELE MY19 LEVO FSR, CABLE FOR MOTOR TT-DISPLAY,BROSE MOTOR HMI ELE MY19 LEVO FSR, CABLE FOR MOTOR TT-DISPLAY,BROSE MOTOR HMI MSC MY22 COMO CHAIN COVER CSP MY22 VADO/TERO CHAINSTAY PROTECTOR, CO-MOLDED MSC MY22 VADO/TERO CHAIN COVER CHG MY22 TERO HT CHAIN GUIDE, FRAME MOUNTED, 38-32T, W/ MOUNTING BOLTS CHR VADO, PRAXIS 40T, 104BCD, SINGLE WAVE STYLE 10/11 SPEED, W/ BOLTS CHR MY22 TERO, PRAXIS, 36T, 104BCD, STL, W/ BOLTS CHR VADO, PRAXIS 48T, 104BCD, SINGLE WAVE STYLE 10/11 SPEED, W/ BOLTS CHG VADO CHAIN GUARD, 48T, PRAXIS MSC MY17 VADO 48T PLASTIC BASH GUARD CHG VADO CHAIN GUARD, 40T, PRAXIS BLT MY17-MY21 VADO/COMO FOR 40T & 48T PLASTIC CRK MY22 VADO/TERO FORGED ALLOY, PRAXIS, DRIVESIDE, 170MM CRK MY22 VADO/TERO FORGED ALLOY, PRAXIS, NON DRIVESIDE, 170MM HGR MY17 DER HANGER AMAZINGER 2.1 MSC MY22 VADO/TERO DROPOUT COVER FND MY22 TERO REAR FENDER SET FND MY22 VADO 650B FRONT FENDER SET FOR SRAM FORK FND MY22 VADO 650B FRONT FENDER SET FOR SUNTOUR FORK FND MY22 TERO FRONT FENDER SET FND MY22 VADO 650B REAR FENDER SET FND MY22 VADO 650B REAR FENDER SET WITH HOLE FOR GARMIN RADAR BLT MY22 VADO/TERO FRAME LOCK HARDWARE KIT
CRR MY22 VADO GARMIN RADAR BRACKET WITH HARDWARE
BAR MY22 COMO HANDLEBAR, 680MM

PART DESCRIPTION Smaller 530Wh (SBC-19) battery not carried as a Service or AM part Charge port cover with latch Charge port magnetic cover Single cover for all frames & sizes & capacity batteries For Vado Como Tero Battery lock cylinder used on all bikes Lower battery mount with lock Battery mount Battery rubber wedge/pin at the top of the battery that holds top of battery in the frame. Carbon Belt for IGH equipped Models Y-Splitter for Garmin Radar equipped models For Vado 3.0 4.0 For Como 3.0 4.0 all Tero Models Motor-to-Display cable, all models Display-to-Motor cable (shared part with Gen. 2 Levo & original TCD-w System for Vado/Como) Chain cover for all models Chain cover for all models Chain guard for Vado and Tero 4.0 EQ Frame mounted chain guide for non-EQ models 40T chainring equipped on Tero 4.0 EQ models 36T chainring equipped on most models Stock chainring for all non-IGH models Same as S179900050 Does not include the mounting bolts (S220500002) Same as S211200010 Does not include the mounting bolts (S220500002) 40T chainring equipped on Tero 4.0 EQ models Screws for mounting plastic chainring guard to Praxis Chainring Single length for all models & sizes Single length for all models & sizes R. Derailleur hanger for all Non-IGH Models DS & NDS sliding drop-out cover kit for IGH equipped models OE spec on Tero 4.0 EQ models 65C width Vado 5.0 models equipped with Sram fork 65C width Vado 3.0 & 4.0 models equipped with SR Suntour fork 65C width OE spec on Tero 4.0 EQ models 65C width Vado 3.0 & 4.0 models 65C width Vado 5.0 models equipped with Garmin Radar 65C width For Vado Como Tero Bracket to mount Garmin Radar on rear Fender – bolts to underside of rear rack for Vado / Como 5.0 OE spec only on Tero 4.0 EQ models Different than Como SL handlebar with Externally routed cables
PAGE 31

TORQUE SPECIFICATIONS & GUIDE TUBE LENGHTHS

Handlebar (Tero) Handlebar (Vado) Handlebar Clamp Handlebar Top Cap
Headset (Como)
Headset (Tero)
Headset (Tero)
Headset (Vado)
Headset Cone Spacer Headset Stem Spacer Headset Stem Spacer Headset Stem Spacer Headtube Cover Headtube Cover Headtube Cover Headtube Cover Headtube Cover Headtube Cover Headtube Cover Headtube Cover Headtube Cover Headtube Cover HUB (Non IGH) ICR Routing Kit Kickstand (Tero)
Kickstand (Vado Como)
Kickstand Blind Plugs
Kickstand Plate
Master mind TCD Handlebar Mount Mastermind TCD MasterMind TCD Mount MasterMind TCD Stealth Stem Mount Motor Motor Motor Motor Motor Bolts

Vado Como Como
Como
Tero 4.0 5.0
Tero 3.0
Vado
Vado / Tero Como Vado / Tero Vado / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Tero
Vado / Como
Tero
Vado / Como / Tero
Vado / Como / Tero Como Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero

S210800011 S210800012 S220800005 S219900014
S212500025
S212500021
S212500022
S212500020
S154800020 S212500002 S154800007 S154800008 S229900001 S229900002 S229900003 S229900004 S229900005 S229900006 S229900007 S229900008 S229900009 S229900010 S202100001 S216500008 S219900050
S179900045
S219900005
S219900062
48119-1405 S216800041 S220800007 S219900057 S216800027 S216800028 S216800029 S226800003 S210500015

BAR MY22 TERO JD-MTB445A,LOW RISE,31.8MM,BACK SWEEP 8DEG,RISE 27MM,UP SWEEP 6DEG, 750MM

Handlebar equipped on all models (size Small use narrower 720mm width)

BAR MY22 VADO JD-MTB556A,31.8MM,BACK SWEEP 15DEG,RISE 46MM,UP SWEEP 5DEG, 680MM

Handlebar equipped on all Vado models

BAR MY21 COMO SL, HANDLEBAR CLAMP ASSEMBLY, W/ BOLTS

Clamp & bolts to secure handlebar to fork steerer (shared part with Como SL)

MSC MY21 COMO SL TOP CAP, DISPLAY MOUNT, HANDLEBAR COVER KIT

Baseplate to attach TCDw mount

HDS COMPLETE, INTEGRATED, 1-1/8″ UPPER BRG (45X45), 1.5″ LOWER BRG (36X45), 20MM TALL CONE TOP COVER, W/ CROWN RACE FOR 1.5″ TAPERED STEERER (HS-S-03)

Headset for all Como models

HDS COMPLETE, INTEGRATED, 1-1/8″ UPPER (45X45), 1.5″ LOWER (36X45), 52MM TOP COVER (H2216), W/ CROWN RACE FOR 1.5″ TAPERED STEERER (HS-S-02)

Headset for tapered 1.5″ steerer fork – for Tero 4.0 and 5.0 models

HDS COMPLETE, INTEGRATED, 1-1/8″ UPPER (45X45), 1.5″ LOWER (36X45), 52MM TOP COVER (H2216), W/CROWN RACE FOR 1-1/8″ STRAIGHT STEERER (HS-S-02-1)

Headset for 1-1/8″ straight steerer fork – for Tero 3.0 models

HDS COMPLETE, INTEGRATED, 1-1/8″ UPPER (45X45), 1.5″ LOWER (36X45), W/ SPLIT CROWN RACE (NO TOP COVER) (HS-S-01)

Headset assembly for all models – Does not include FlowSet compatible top cover

STM MY15 SIRRUS/VITA FLOW-SET STEM CONE SPACER 52MM OD 15MM HEIGHT

52mm OD headset top cover

HDS SUB, 20MM HEADSET SPACER FOR COMO SL

Headset spacer

STM MY15 TURBO / SIRRUS / VITA FLOW-SET STEM SPACER 10MM

10 mm FlowSet steerer spacer

STM MY15 TURBO / SIRRUS / VITA FLOW-SET STEM SPACER 5MM

5 mm FlowSet steerer spacer

MSC MY22 COMO HEADTUBE COVER, LIMESTONE / BLACK REFLECTIVE

MSC MY22 COMO HEADTUBE COVER, SAND / BLACK REFLECTIVE

MSC MY22 VADO/TERO HEADTUBE COVER, CAST BLACK / SILVER REFLECTIVE

MSC MY22 VADO/TERO HEADTUBE COVER, OAK GREEN METALLIC / SMOKE

MSC MY22 VADO/TERO HEADTUBE COVER, RED ONYX / SMOKE

MSC MY22 VADO/TERO HEADTUBE COVER, RED TINT / SILVER REFLECTIVE

MSC MY22 VADO/TERO HEADTUBE COVER, REDWOOD / BLACK

MSC MY22 VADO/TERO HEADTUBE COVER, SMOKE / BLACK REFLECTIVE

MSC MY22 VADO/TERO HEADTUBE COVER, WHITE MOUNTAINS / BLACK REFLECTIVE

MSC MY22 VADO/TERO HEADTUBE COVER, WHITE MOUNTAINS / GUNMETAL

FHB BEAR PAWLS, TA, SHIMANO 10-SPD, STEEL, 3 PAWL (HFH-0001) (BMB-00412O1A / BEB-51412P1A)

FHB for rear wheel of non-IGH Vado 4.0 & 5.0 Como 4.0 5.0

CBG MY22 VADO/TERO CABLE ROUTING KIT

Cable guide kits for all models

MSC MY22 TERO HT KICKSTAND, CHAINSTAY MOUNT, 362MM, W/BOLTS

OE spec on Tero 4.0 EQ models

MSC MY17 VADO SPECIALIZED REAR 40MM, BLACK, W/ THREADS IN KICKSTAND, W/O BOLTS, W/ PLASTIC FOOT, BLACK

Kickstand used on all models

MSC KICKSTAND PLUG FOR LEVO HT, CREO SL E5 AND VADO SL (2 PIECES)

Plugs for unused Kickstand mount on non-EQ models

MSC MY22 COMO KICKSTAND HARDWARE KIT

Plate that sits on inside of NDS chainstay to protect the speed sensor cable from the brake rotor. Plate sits between the frame and the kickstand. Used on non-IGH Models

TURBO CONNECT DISPLAY MTB MOUNT

31.8mm handlebar mount for MasterMind TCD-w

ELE TCD-W 2, WIRED DISPLAY WITH REMOTE

MasterMind TCD

BAR SUB, TCD-W 2 HANDLEBAR MOUNT BASEPLATE, FOR MY22 COMO, PLASTIC, W/O BOLT

Baseplate mount for mono-bar assembly for TCD-w 2 display

MSC TCD-W 2, STEALTH STEM MOUNT

Contains adapter to mount TCD-w 2 display to the baseplate – includes the bolt & nut

ELE MY22 SPECIALIZED DRIVE C MAG HORIZONTAL, 25KMH

2.0E – 50 Nm Max Torque (E57028) Vado 3.0 models | Tero 3.0 models

ELE MY22 SPECIALIZED DRIVE S MAG HORIZONTAL, 25KMH

2.2 – 90 Nm Max Torque (E06855) Vado 5.0 models | Tero 5.0 models

ELE MY22 SPECIALIZED DRIVE T MAG HORIZONTAL, 25KMH

2.0 – 70 Nm Max Torque (E57026) Vado 4.0 models | Tero 4.0 models

ELE MY22 SPECIALIZED DRIVE T MAG HORIZONTAL, 28MPH (USA SPEC)

2.0 – 70 Nm Max Torque (G23959) USA Spec Vado 4.0 models

BLT MY22 VADO/TERO MOTOR MOUNTING HARDWARE KIT

For Vado Como Tero

TECHNICAL GUIDE

PAGE 32

Motor Covers Motor Port Blind Plugs
Rear Light (Rack Integrated)
Rear light Cable Rear Rack Rim (Como) Rim (Tero) Rim (Vado) Seat Collar (Como) Seat Collar (Vado Tero) Seatpost (Como) Seatpost (Vado Tero) Seatpost Dropper (Tero) Seatpost Dropper (Tero) Seatpost Dropper Cable Barrel (Knarp) Seatpost Dropper Lever Seatpost Shim Sliding Dropout Bolts Sliding Dropout DS Sliding Dropout NDS Speed Sensor Cable Speed Sensor Holder Speed Sensor Magnet 6-Bolt Speed Sensor Magnet 6-Bolt Speed Sensor Magnet Centerlock Spider (IGH) Spider (Non IGH) Spider Nut Stem 60 mm Stem 70 mm Stem FlowSet 60 mm Stem FlowSet 75 mm Stem Stealth 60 mm Stem Stealth 60 mm
Thru Axle – Rear
Wheel Front (SRAM)
Wheel Front (Suntour)
Wheel Rear Wheel Rear (Enviolo City) Wheel Rear (Enviolo HD) Wheel Rear (Non IGH)
TECHNICAL GUIDE

Vado / Como / Tero Como
Vado / Como / Tero
Vado / Como / Tero Vado / Como / Tero Como Tero Vado Como Vado / Tero Como Vado / Tero Tero Tero Tero Tero Como Vado / Como Vado / Como Vado / Como Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero Vado / Como Vado / Como / Tero Vado / Como / Tero Tero Non EQ Tero Non EQ Vado Vado Vado 4.0 Tero 4.0 EQ Vado 4.0 Tero 4.0 EQ
Vado / Como / Tero
Vado / Como / Tero
Vado / Como / Tero
Como Vado / Como / Tero Vado / Como / Tero Vado / Como / Tero

S219900056 S216800024
S225800006
S216800037 S211700003e S213700010 S213700011 S213700010 S214700006 S184700003 S214900010 S214900008 S214900001 S214900002 S144900006 S184200069 S174900001 S216000003 S216000004 S216000005 S216800025 S216800038 S194200016 S216800039 S199900012 S211600026 S195100001 S166800011 S214800003 S214800004 S154800016 S154800017 S194800002 S194800003
S170200003
S215500024
S215500023
S225500003 S225500001 S225500002 S215500022

MSC MY22 VADO/TERO MOTOR COVER KIT ELE EBIKE BROSE MOTOR LIGHT SOCKETS BLIND PLUGS
LGT REAR, SPANNIGA COMMUTER GLOW R581001, INTEGRATED RACK MOUNT, W/O WIRE
ELE MY22 VADO/TERO REAR LIGHT CABLE, 12V, 2 WIRES CRR MY22 VADO REAR RACK W/ HARDWARE RIM TURBO, 650B, FRONT & REAR, ALLOY, 32H, DISC, 30MM INTERNAL (SD30)- BLACK W/ TURBO DCL RIM TURBO, 29, FRONT & REAR, ALLOY, 32H, DISC, 25MM INTERNAL (SHL28 OS) – BLACK RIM TURBO, 650B, FRONT & REAR, ALLOY, 32H, DISC, 30MM INTERNAL (SD30)- BLACK W/ TURBO DCL STC 42.9MM, KCNC, SPL-SC02-429-02, EXTRUDED, 7075-T73, BLACK ZINC BOLT, BOLT CLAMP TYPE STC MY18 EPIC SEAT COLLAR 34.9 MM WITH TI BOLT STP 34.9MM, 500MM LENGTH, OFFSET 5MM, JD-SP20T.1,FORGED,6061-T6 TUBE & HEAD,2-BOLT CLAMP STP SEATPOST ALLOY, 30.9 MM, OFFSET 0MM, 400MM, 2 BOLT CLAMP STP JD-SBC02, 30.9,OFFSET 0MM,360MM,TRAVEL 100MM,W/O REMOTE LEVER STP JD-SBC02, 30.9,OFFSET 0MM,400MM,TRAVEL 120MM,W/O REMOTE LEVER SUB MY14/15 COMMAND POST CPIR MY15 XCP ACTIVATION BARREL 5.7OD SILVER SUB REMOTE LEVER SPL-SRL-MY17-BK-OE MY17 CP SRL LE STP SEATPOST SHIM 34.9OD – 30.9ID DRO MY22 VADO/TERO DROPOUT SLIDER HARDWARE KIT DRO MY22 VADO/TERO DROPOUT SLIDER, DRIVESIDE, W/ HARDWARE DRO MY22 VADO/TERO DROPOUT SLIDER, NON DRIVESIDE, W/ HARDWARE ELE LEVO FSR SPEED SENSOR CABLE ELE MY22 VADO/TERO SPEED SENSOR HOLDER SUB MY19 LEVO FSR SPEEDSENSOR-MAGNET KIT ELE MY22 VADO/TERO SPEED SENSOR MAGNET, 6BOLT MSC SPEED SENSOR MAG HOLDER,CENTERLOCK,ASSY,LOCK RING CRK MY22 VADO PRAXIS SPIDER, 104BCD, VERSION C, IGH CRK MY19 LEVO FSR SPIDER,104BCD,PA TRAIL FSR D2 ELE MY16 LEVO ISIS GROOVE NUT STM SBC-2.3-R6,6061-T6,31.8MM,6DEG,SCM435,ZINC FINISH BOLT,THREAD LOCK PATCH,SB. BLK, 60mm STM SBC-2.3-R6,6061-T6,31.8MM,6DEG,SCM435,ZINC FINISH BOLT,THREAD LOCK PATCH,SB. BLK, 70mm STM MY15 SIRRUS/VITA FLOW-SET STEM 31.8 20 DEG RISE 60MM BLACK STM MY15 SIRRUS/VITA FLOW-SET STEM 31.8 20 DEG RISE 75MM BLACK STM MY20 VADO DA-264,31.8MM, L 60MM, 14 DEG STM MY20 VADO DA-264,31.8MM, L 75MM, 14 DEG

DS & NDS motor cover kit, includes bolts Light socket blind plugs (1 pcs per part #) Rear light integrated into the rear rack. Does NOT include the light wire, that is available separately as S216800037. Rear light wire for Spanniga integrated rear rack light Rear rack w/mount for Spanniga integrated tail-light Front & Rear rims for all models Front & Rear rim for all models Front & Rear rim for Vado Seatpost binder/clamp for all Como models 34.9 mm seatpost collar for Vado Stock rigid post on MY22 Como 3.0 models Suspension seatposts not stocked as a service part Rigid seatpost OE on Vado Tero 3.0 models Tero 4.0 and 5.0 Size S Tero 40. and 5.0 Size M/L/XL Knarp for dropper-post cable Lever for dropper-post 30.9mm to 34.9mm shim for suspension posts on 4.0 and 5.0 models Bolts & washers for slider dropouts-IGH models DS Slider dropouts-IGH models NDS Slider dropouts-IGH models Speed sensor cable, all models (shared part with G2 & G3 Levo) Speed sensor holder with bolt 6-bolt speed sensor magnet for Rear Derailleur equipped models 6-bolt speed sensor magnet for IGH rear hubs Centerlock speed sensor magnet – for non IGH models IGH equipped models Rear derailleur equipped models (Non IGH) Spider lock-ring for all models Use with either Park Tool BBt-18 or Shimano TL-UN96 Non EQ Tero Sizes S / M Non EQ Tero Sizes L / XL Vado Sizes S / M Vado Sizes L / XL Vado Sizes S / M | EQ Tero Sizes S / M Vado Sizes L / XL | EQ Tero Sizes L / XL

AXL THROUGH AXLE, JD JD-QR43, 7075-T73 AXLE W/C6801 WASHER, REAR, 148MM SPACING, 172MM LENGTH, 12MM Non-IGH models

WHL TURBO, 650B, FRONT, ALLOY, TA, 15X110MM, DISC, 6-BOLT, 32H

Front wheel for Sram fork equipped models

WHL TURBO, 650B, FRONT, ALLOY, TA, 15X100MM, DISC, 6-BOLT, 32H

Front wheel for SR Suntour Fork equipped models

WHL TURBO, 650B, REAR, ALLOY, IGH BOLT-ON, 10X135MM, DISC, 6-BOLT, 32H – EVIOLO TR WHL TURBO, 650B, REAR, ALLOY, 10X135MM BOLT-ON, DISC, 6-BOLT, 32H – ENVIOLO CT WHL TURBO, 650B, REAR, ALLOY, IGH BOLT-ON, 10X135MM, DISC, 6-BOLT, 32H – ENVIOLO HD WHL TURBO, 650B, REAR, ALLOY, TA, 12X148MM, DISC, 6-BOLT, 32H, SHIMANO 11-SPD FHB

Enviolo Trekking rear hub – 4.0 IGH Models Rear wheel with Enviolo City rear hub – 3.0 IGH Models Rear wheel with Enviolo Heavy Duty rear hub – 5.0 IGH Models Rear wheel for non-IGH models Como 4.0 & 5.0 non-IGH Models

PAGE 33

LOCATION
SEAT COLLAR SEATPOST RAIL CLAMP BOLTS STEM @ STEERER TUBE STEM @ HANDLEBAR STEM @ STEERER TUBE*** STEM @ HANDLEBAR *** STEM TOP CAP BOLT *** CRANK BOLTS CHAINRING BOLTS WATER BOTTLE CAGE BOLT 12 mm REAR AXLE * ENVIOLO AXLE NUTS ** DERAILLEUR HANGER * HEAD TUBE ICR GUIDE SCREW MOTOR MOUNT NUTS MOTOR MOUNTING BOLT MOTOR COVER CUSTOM NUT REAR DROP OUT COVER BOLT ADJUSTABLE DROPOUT MOUNTING BOLTS ADJUSTABLE DROPOUT ADJUSTMENT BOLTS DROPOUT COUPLER BOLTS BATTERY LATCH BOLT BATTERY (SEAL) MOUNTING BOLTS SPEED SENSOR MOUNTING BOLT SPEED SENSOR MAGNET BOLTS (6 BOLT VERSION) SPEED SENSOR MAGNET (CENTERLOCK VERSION) REMOTE SET SCREW CHAIN GUARD MOUNT BOLT (@MOTOR/CHAINSTAY) CHAIN GUARD BOLTS KICKSTAND BOLTS (IGH) KICKSTAND BOLTS (NON IGH) FRONT FENDER MOUNT BOLTS REAR FENDER BOLTS REAR RACK BOLTS
TECHNICAL GUIDE

TOOL
4 mm HEX 5 mm HEX 4 mm HEX 4 mm HEX 4 mm HEX 4 mm HEX 5 mm HEX 8 mm HEX 5 mm HEX 3 mm HEX 6 mm HEX 15 mm WRENCH 4 mm HEX T10 TORX 13 mm SOCKET WRENCH 5 mm HEX T20 TORX 2.5 mm HEX T30 TORX 3 mm HEX T25 TORX 3 mm HEX T20 TORX 3 mm HEX T25 TORX CASSETTE LOCK RING TOOL 2 mm HEX 3 mm HEX 3 mm HEX T30 Torx 5 mm HEX 4 mm HEX 4 mm HEX 5 mm HEX

TORQUE

in-lbf

6.2

5.2

443

2.8

133

30 – 40 265 – 354

6.2

0.8

203

8.8
