PGE APPROVED STREET LIGHTING EQUIPMENT FOR NEW INSTALLATIONS
OUTDOOR LIGHTING SERVICES
Updated 3/3/23
PGE CU 1366 Outdoor Street Lighting
PGE makes no representations of warranties regarding street lighting equipment, whether included or not included on this list of approve street lighting equipment. Inclusion on this list is not an endorsement of the equipment nor does it mean that the listed equipment is appropriate for requirements applicable to all street lighting applications. If equipment is not included in this list, it does not reflect whether or no such equipment is appropriate for street light owners other than PGE.
If you have additional questions about this list of street lighting equipment, please contact PGE’s Outdoor Lighting Services Department or your assigned Project Manager.
FIXTURES
| Manufacturer | Lum Code | Wattage | Lumens | Manufacturer Product Code |
| LEOTEK – GRAY | ||||
| CU 1365 | Roadway | 29W LED | 3470 | GCJ1-20H-MV-WW-2R-GY-450-PCR7-RWG-WL-FDC-PGE |
| CU 1366 | Roadway | 45W LED | 5020 | GCJ2-20H-MV-WW-2R-GY-700-PCR7-RWG-WL-FDC-PGE |
| CU 1369 | Roadway | 88W LED | 10230 | GCM2-40H-MV-WW-2R-GY-700-PCR7-RWG-WL-FDC-PGE |
| CU 1803 | Roadway | 160W LED | 18700 | GCL-80G-MV-WW-3R-GY-610-PCR7RWGWLFDCPGE |
| LEOTEK – BLACK | ||||
| CU 1375 | Roadway | 29W LED | 3470 | GCJ1-20H-MV-WW-2R-BK-450-PCR7-RWG-WL-FDC-PGE |
| CU 1376 | Roadway | 45W LED | 5020 | GCJ2-20H-MV-WW-2R-BK-700-PCR7-RWG-WL-FDC-PGE |
| CU 1378 | Roadway | 88W LED | 10230 | GCM2-40HMV-WW-2R-BK-700PCR7-RWG-WLFDC-PGE |
| LEOTEK – BRONZE | ||||
| CU 1488 | Roadway | 29W LED | 3470 | GCJ1-20H-MV-WW-2R-DB-450-PCR7-RWG-WL-FDC-PGE |
| CU 1489 | Roadway | 45W LED | 5020 | GCJ2-20H-MV-WW-2R-DB-700-PCR7-RWG-WL-FDC-PGE |
| CU 1491 | Roadway | 88W LED | 10230 | GCM2-40H-MV-WW-2R-DB-700-PCR7-RWG-WL-FDC-PGE |
| PENDANT AURORA – KING – CU 1497 | ||||
| *PGE Current Pendant Fixture | Pendant | 40W LED | 4440 | K829-P4FL-III-60(SSL)-8060-120-277-3K-WS-QD-TXT BLACK s/f KPL20-PR7 / DWG PGE-AURORA-2 |
| Pendant | 60W LED | 6427 | K829-P4FL-III-60(SSL)-8060-120-277-3K-WS-QD-TXT BLACK s/f KPL20-PR7 / DWG PGE-AURORA-2 | |
| Pendant | 75W LED | 8060 | K829-P4FL-III-60(SSL)-8060-120-277-3K-WS-QD-TXT BLACK s/f KPL20-PR7 /DWG PGE-AURORA-2 | |
| CREE XSP GRAY – Area Light Request Only | ||||
| CU 1392 | Roadway | 24W LED | 3040 | XSPSM-D-HT-3ME-5L-40K7-UL-SV-N-X1 |
| CU 1393 | Roadway | 33W LED | 4025 | XSPSM-D-HT-3ME-5L-40K7-UL-SV-N-X4 |
| CU 1395 | Roadway | 49W LED | 6050 | XSPSM-D-HT-3ME-8L-40K7-UL-SV-N-X4 |
| CU 1396 | Roadway | 67W LED | 9175 | XSPMD-D-HT-3ME-12L-40K7-UL-SV-N-X4 |
| CU 2200 | Roadway | 135W LED | 18700 | MPN XSPLG D HT 3ME 18L 40K7 UL SV N |
| CREE XSP BRONZE – Area Light Request Only | ||||
| CU 1355 | Roadway | 24W LED | 3040 | XSPSM-D-HT-3ME-5L-40K7-UL-BZ-X1 |
| CU 1356 | Roadway | 33W LED | 4025 | XSPSM-D-HT-3ME-5L-40K7-UL-BZ-X4 |
| CU 1357 | Roadway | 49W LED | 6050 | XSPSM-D-HT-3ME-8L-40K7-UL-BZ-X4 |
| CU 1358 | Roadway | 67W LED | 9175 | XSPMD-D-HT-3ME-12L-40K7-UL-BZ-X4 |
| EATON FLOOD- Bronze color | ||||
| CU 1492 | Flood | 82W LED | 11,802 | UFLD-CA2-80-740-U-66-Y-BZ-10K-PR7-U124397 |
| CU 288 | Flood | 124W LED | 19,230 | UFLD-CA2-120-740-U-66-Y-BZ-10K-PR7-U124398 |
| CU 289 | Flood | 184W LED | 25,833 | UFLD-CA2-180-740-U-66-Y-BZ-10K-PR7-U123410 |
| CU 766 | Flood | 322W LED | 46,802 | UFLD-L-CA4-320-740-U-66-Y-BZ-10K-PR7-U124664 |
| TOWN & COUNTRY – AMERICAN REVOLUTION | ||||
| CU 1442 | T&C | 30W LED | 3548 | 247CL P151 MVOLT 30K R3 BK SNC PR TL NL1X1 |
| CU 1443 | T&C | 50W LED | 5100 | 247CL P153 MVOLT 30K R3 BK SNC PR TL NL1X1 |
| LEOTEK – T&C COLONIAL * | ||||
| CU 1494 | T&C | 33W LED | 4374 | PTC-S-F-N-S-30J-MV-30K-3-BK-045-PCR7-CS-WL-JB |
| T&C | 45W LED | 5825 | ||
| ACORN – KING YARMOUTH * | ||||
| CU 1145 | Acorn | 40W LED | 3592 | K137-P4NG-III-60(SSL)-7030-120:277-K26-3K-(MOD)PR7-WS-TXT BLACK |
| Acorn | 60W LED | 5157 | ||
| Acorn | 75W LED | 6082 | ||
| ACORN – ACRYLIC | ||||
| CU 1407 | Acorn | 46W LED | 7067 | AWDE3 P30 30K MVOLT MS AL3 BK ST TBK PR7 FPD75 NL1X1 |
| ACORN – UTILITY | ||||
| CU 1520 | Acorn | 38W LED | 3262 | WFLC2P2030KASBKL3NP7ENL1X1FPD85 |
| CU 1408 | Acorn | 66W LED | 5472 | WFCL2P30ASBKLDL RFD296286 |
| **MISCELLANEOUS** | ||||
| LEOTEK SHIELD | ||||
| HSSGCJ (1 Shield for Small, 2 Shields for Medium and 4 Shields for Large fixtures) | ||||
| CREE XSP SHIELD Description | ||||
| SM | ||||
| M | ||||
| LG | ||||
| CREE BETA SHIELD | ||||
| HOLOPHANE SHIELDS – Can be used for Acorn and T&C Fixtures | ||||
| MFN: WFCL2HSSI | ||||
| KING ACORN SHIELD | ||||
| K137HSS120D3H | ||||
| PHOTO CONTROL: EXTENDED LIFE TWIST LOCK | ||||
| Ripley – RD8645 | ||||
| DTL – DLL 1271.5 J50 | ||||
| Intermactic – EK4536K | ||||
| STREETLIGHT, LED, VOLTAGE STICKER | ||||
| 120v | ||||
| 208V | ||||
| 240V | ||||
| 277V | ||||
| HANDHOLE COVER – GRAY, PLASTIC, STEEL CORE, UNIVERSAL | ||||
| TL-S | ||||
| STREETLIGHT 1324 J-BOX (Fused CU 353, Unfused CU 352) | ||||
| NEWBASIS – 13″ x 24″ x 18″ (90003478) | FCA132418T-00043 | |||
| OLDCASTLE / CARSON INDUSTRIES – 13″ x 24″ x 18″ (90003478) | 13241712 | |||
| HIGHLINE – 13″ x 24″ x 18″ (90003478) | CHA132418HE1 | |||
| ARMORCAST – 13″ x 24″ x 18″ (90003478) | A6001946TAX18 | |||
| JENSEN COMPOSITE – 13″ x 24″ 18″ (90003478) | HPC132418-PGE | |||
| STREETLIGHT 1730 J-BOX (Fused CU 855, Unfused CU 854) | ||||
| QUAZITE (HUBBELL) – 17″ x 30″ x 18″ (90003480) | A42173018A017 | |||
| NEWBASIS – 17″ x 30″ x 18″ (90003480) | FCA173018T-00043 | |||
| OLDCASTLE – 17″ x 30″ x 18″ (90003480) | 17301726 | |||
| OLDCASTLE INFRASTRUCTURE – 17″ x 30″ x 18″ (90003480) | 17301423 | |||
| HIGHLINE – 17″ x 30″ x 18″ (90003480) | CHA173018HE1 | |||
| ARMORCAST – 17″ x 30″ x 18″ (90003480) | A6001640TAX18 | |||
| JENSEN COMPOSITE – 17″ x 30″ x 18″ (90003480) | HPC173018-PGE | |||
| SREETLIGHT J-BOX | ||||
| J-BOX | Description | |||
| For Underground Conductors & Connections | Junction Box, Concrete Polymer Lid, Fiberglass Reinforced Polymer flared sides, 18″ Deep, No Floor, With Skid Resistant Cover Attached by Two Captive stainless steel 3/8-inch Penta-head Bolts, Gray Color, per PGE T&D Material Specification L26107. Covers must be marked ELECTRIC. | |||
| STREETLIGHT WIRE | ||||
| Streetlight Wire | Description | |||
| #10 CU 3-Conductor -36 (CU 635) | #10 AWG, 600 Volt, 3-Conductor, Class B Stranding, Type TC, with Sunlight-Resistant 45-mil PVC Jacket. Suitable for direct burial installations. Insulation to be black, red, and green per NEMA WC-7 for NEC appli-cations (TFN, THWN, THHN), with fillers or binding tape added to produce round outer jacket, rated 90ᵒC dry and 75ᵒC wet, 1,000 ft NR reels. Jacket to display sequential footage markings. 2 reel labels, one attached to the outside flange surface, one attached to the drum wrapping; each to detail total footage, inside or starting footage. | |||
POLES
| Manufacturer | Footings | Arm Type | Manufacturer Product Code |
| CUSTOMER OWNED | |||
| 25 Ft Aluminum with 4′ Single (UG) – CU 274 | |||
| Valmont | Anchor Base | Single | 220840705T4SBF/1MA043240 |
| Hapco | Anchor Base | Single | 21-362PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Single | RTA7L25AAS1432D |
| 25 Ft Aluminum with 4′ Davit (UG) – CU 278 | |||
| Valmont * | Anchor Base | Davit | 250075105D4 |
| Hapco | Anchor Base | Davit | 41-103PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Davit | RTA7L25AAD1432D |
| 25 Ft Aluminum with 4′ Single (OH) – CU 275 | |||
| Valmont | Anchor Base | Single | 220845705T4J/1MA0432B |
| Hapco | Anchor Base | Single | 54423PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Single | N/A |
| 30 Ft Aluminum with 6′ Single (UG) – CU 276 | |||
| Valmont | Anchor Base | Single | 270845805T4/1MA0632B |
| Hapco | Anchor Base | Single | 21-585PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Single | RTA8L30AAS1632D |
| 30 Ft Aluminum with 6′ Davit (UG) – CU 279 | |||
| Valmont * | Anchor Base | Davit | 3000-85106D4 |
| Hapco | Anchor Base | Davit | 41-176PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Davit | RTA8L30AAD1632D |
| 25 Ft Aluminum with 4′ Double Davit (UG) – CU 1906 | |||
| Valmont | Anchor Base | Double Davit | 250075204D4Z-SBF |
| 30 Ft Aluminum with 2-6′ Double Davit (UG) – CU 1258 | |||
| Valmont * | Anchor Base | Double Davit | 3000-85206D4Z |
| Hapco | Anchor Base | Double Davit | 42-158XPGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Double Davit | N/A |
| 35 Ft Aluminum with 8′ Single (UG) – CU 326 | |||
| Valmont | Anchor Base | Single | 3208-45806T4/1MA0832B45 |
| Hapco | Anchor Base | Single | 21-867PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Single | RTA8M35AAS1832D |
| 35 Ft Aluminum with 8′ Single (UG, Breakaway Anchor Base) – CU 327 | |||
| Hapco | Anchor Base | Single | RTA35C84M1801 |
| 35 Ft Aluminum with 8′ Davit (UG) – CU 280 | |||
| Valmont * | Anchor Base | Davit | 3500-86108D4 |
| Hapco | Anchor Base | Davit | 41-231PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Davit | RTA8M35AAD1832D |
| 40 Ft Aluminum with 8′ Davit (UG) – CU 335 | |||
| Valmont * | Anchor Base | Davit | 4000-87108D4 |
| Hapco | Anchor Base | Davit | 41-339PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Davit | RTA8H40AAD1832D |
| 14 Ft Fluted Decorative Cast Aluminum – Use with Acorn Fixture – CU 331 | |||
| Hadco | Anchor Base | Post-Top | P-2065-14-A |
| Amerlux Exterior LLC * | Anchor Base | Post-Top | D1305-14/BLK-PGE-GBL |
| Hapco | Anchor Base | Post-Top | 77920PGE |
| Holophane | Anchor Base | Post-Top | WDA 14 F5J 17 P07 LAB BK |
| Valmont | Anchor Base | Post-Top | 140050506UW |
| 16 Ft Decorative Cast Aluminum – CU 328 | |||
| Hadco | Anchor Base | Post-Top | P-2065-16-A |
| Amerlux Exterior LLC * | Anchor Base | Post-Top | D1305-16/BLK-PGE-GBL |
| Hapco | Anchor Base | Post-Top | 77920L24PGE |
| Holophane | Anchor Base | Post-Top | WDA 16 F5J 17 P07 LAB BK |
| Valmont | Anchor Base | Post-Top | 160050506UW |
| 16 Ft Aluminum, Spun, Natural Al Finish – CU 281 | |||
| Valmont | Anchor Base | Post-Top | 150830504T4 |
| Hapco | Anchor Base | Post-Top | 57453-005PGE |
| P&K Poles (Flagpole Inc) | Anchor Base | Post-Top | RTA5L16AA32D |
| 23 Ft Aluminum Smooth, Black – use with King Fixture – CU 1498 | |||
| Anchor Base | Post-Top | KMRE-A-23FT-TXT BLACK S/F KSB52 DWG PGE-AURORA-4 | |
| 25 Ft Composite, 1-Piece Smooth Finish – Black – CU 1500 | |||
| Shakespeare * | Anchor Base | Single | AK25-16S1BB01 |
| 30 Ft Composite, 1-Piece Smooth Finish – Black – CU 1501 | |||
| Shakespeare * | Anchor Base | Single | AK30-16S1BB01 |
| 35 Ft Composite, 1-Piece Smooth Finish – Black – CU 1502 | |||
| Shakespeare * | Anchor Base | Single | AK35-16S1BB01 |
| 35 Ft Composite, 1-Piece Smooth Finish – Gray – CU 1503 | |||
| Shakespeare * | Anchor Base | Single | AK35-16S2BB01 |
| 18 Ft Composite, 2-Piece, Smooth Finish, Top Piece Only – 14′ MH | |||
| Shakespeare – BLACK * – CU 1117 | Direct Buried | Single | BHT1801S1BJ9901 |
| Shakespeare – BRONZE * – CU 1127 | Direct Buried | Single | BHT1801S5BJ9901 |
| 18 Ft Composite, 2-Piece, Smooth Finish, Stub Piece Only | |||
| Shakespeare * | Direct Buried | Single | BHS1801N9BJ9901 |
| 20 Ft Composite, 2-Piece, Smooth Finish, Top Piece Only – 16’MH | |||
| Shakespeare – BLACK * – CU 1120 | Direct Buried | Single | BHT2001S1BJ9901 |
| Shakespeare – BRONZE * – CU 1123 | Direct Buried | Single | BHT2001S5BJ9901 |
| 20 Ft Composite, 2-Piece, Smooth Finish, Stub Piece Only | |||
| Shakespeare | Direct Buried | Single | BHS2001N1BJ9901 |
| 30 Ft Composite, 2-Piece, Smooth Finish, Top Piece Only – 25’MH | |||
| Shakespeare – BLACK * – CU 1113 | Direct Buried | Single | BHT3099S1BL9901 |
| Shakespeare – BRONZE * – CU 1111 | Direct Buried | Single | BHT3099S5BL9901 |
| Shakespeare – GRAY * – CU 1105 | Direct Buried | Single | BHT3099S2BL9901 |
| 30 Ft Composite, 2-Piece, Smooth Finish, Stub Piece Only | |||
| Shakespeare * | Direct Buried | Single | BHS3099N3BL9901 |
| 35 Ft Composite, 2-Piece, Smooth Finish, Top Piece Only – 30′ MH | |||
| Shakespeare – BLACK * | Direct Buried | Single | BXT3599S1BL9901 |
| Shakespeare – BRONZE * – CU 1114 | Direct Buried | Single | BXT3599S5BL9901 |
| Shakespeare – GRAY * – CU 1108 | Direct Buried | Single | BXT3599S2BL9901 |
| 35 Ft Composite, 2-Piece, Smooth Finish, Stub Piece Only | |||
| Shakespeare | Direct-Buried | Single | BXS3599N2BL9901 |
| * Vendor Anixter is ordering from | |||
FOOTINGS, MAST ARMS & SHROUDS
| **FOOTINGS** | |||
| Pole Footings Concrete | |||
| Precast Concrete Base | Bolt Circle | Bolt Type | Base Dimensions |
| For 16 Foot Pole 1944 Only SU (146) | 8 inch | 3/4″ -10 NC Galv Steel | 18″ Square by 48″ High |
| For all decorative and post-top anchor base poles 14 to 25 feet. SU (39083) | 11 inch | 1″- 8 NC Galv Steel | 20” Round by 48” High |
| For 25 to 35 Foot Aluminum or Fiberglass Anchor Base Poles SU (147) | 14″ Square by 60″ High | ||
| For 40 Foot Al Poles SU (39094) | 18″ Top, 24” Bottom 84” High | ||
| **MOUNTING ARMS & SHROUDS FOR HADCO ALUMINUM POLES** | |||
| Mounting Arms | |||
| SU# | Description | ||
| 90010241 | Banner Arm 5” RD TWIN BANNER ARM, 5″ POST MOUNT, 24″ ARM USE ONLY WITH HADCO 14’ AND 16’ ALUM POLES | ||
| 90010242 | BRACKET FLOWER POT SINGLE, 5″ POST MOUNT, 12″ ARM LENGTH, BLACK COLOR USE ONLY WITH HADCO 14’ AND 16’ ALUM POLES | ||
| Twin Decorative Arm for Hadco 14′ or 16′ Fluted Cast Aluminum Poles | |||
| Hadco | Amerlux Exterior LLC | ||
| PTH2520P3A (SU 39480) | 2BR50-3/GBL-PGE | ||
| Pole Shroud for 18′ Hadco Pole | |||
| SU | Hadco | ||
| 90010254 | For replacement on Hadco Westbrooke 18′ Streetlight Pole | ||
| T2 Adapter and Harness – Hadco Arm Connector | |||
| SU | King | ||
| 90011748 | T2 Adapter w/ 9 in harness. For existing Hadco arm installation only | ||
| Pole Shroud for 23′ Stress Crete Pole | |||
| SU | King | ||
| 90011696 | For replacement on 23′ Stree Crete Streetlight Pole | ||
Mast Arm for 23′ Stress Crete Pole
| Length | King |
| 4 foot Aluminum Mast Arm (SU 90011695) | KA32-S-1-4FT-TXTBLACKC/WKPL20- PR7ANDHARNESS/DWG PGE-AURORA-3 |
Mast Arms for Transmission Poles
| Length | Valmont |
| 14 foot Aluminum Mast Arm* (SU 90011224) | 1TA1432PMA |
| 12 foot Aluminum Mast Arm* (SU 90011296) | 1TA1232PMA |
| 10 foot Aluminum Mast Arm* (SU 90011297) | 1TA1032PMA |
Steel Arms for Wood Poles
| Length | Valmont | SALCO | Maclean Power Systems | WICO |
| 2 foot, cantilever, no brace (SU 2016) (CU 861) | ACSA-125-020 | WP-125-2-S | 5-125-2G | |
| 4 foot, cantilever, no brace (SU 2017) (CU 315) | ACSC 125-040 | WP-125-4-S | 5-125-4G | |
| 6 foot, cantilever, no brace (SU 2018) (CU 316) | WP-125-6-S | S-125-6G | ||
| 8 foot, single brace (SU 2019) (CU 317) | WPSG-125-8-S-PGE | S- 125-8SG-30R | ||
| 10 foot, double brace (SU 2020) (CU 318) | WPDG-125-10-S | S-125-10DG | ||
| 12 foot, double brace (SU 2021) (CU 319) | WPDG-125-12-S | 5-125-12DG | ||
| 14 foot, double brace (SU 2022) (CU 320) | WPDG-125-14-S | S-125-14DG | ||
| 18″ Double Floodlight Unit, r Pipe, 18″ Rise (SU 38078) (CU 1022) | WP2F-2-1.5-S | |||
| 14″ Single Floodlight Bracket (SU 2901) (CU 1057) | di view – 2023- | WI-1S-TL |
Arms for Composite Poles
| Length, Finish | Whatley | Salco | Valmont | Shakespeare |
| 8″ Bronze Finish Tenon-Mount (SU 39498) (CU 329) | 11-17901-130B (PWD DARK BRONZE) | OPAR-3T-0. 7- BZ | ||
| 8″ Black Finish Tenon-Mount (SU 90009810 (CU 1496) | OPAR-3T-0.7- BK | |||
| r Bronze Finish (side mount) AL or Steel (SU 2025) (CU 350) | SBS-2DDB | 1115238088475 | OPAR-0.7-PGE-BR | |
| 6 Foot AL Finish (SU 2026) (CU 751) | MA-72 | I MA0632B475 W/HARDWARE | OPAR-6 | |
| 6 Foot Bronze Finish (SU 2027) (CU 775) | MA-72DDB | IMA0632B475-BRZ | 0 PAR- 6-BRONZE | |
| 6 Foot Black Finish (SU 90003570 (CU 1231) | MA-72DBL | IMA06328475-BLK | OPAR-6-BK | |
| 8 Foot AL Finish (SU 39202) (CU 1131) | MA-96 | IMA0832B475 | OPAR-8 | |
| 8 Foot Bronze Finish (SU 39201) (CU 1132) | MA-96DDB | IMA083213475-BRZ | OPAR-8-BRONZE | |
| 8 Foot Black Finish (SU 90003577) (CU 1232) | MA-96DBI | IMA083213475-BLK | OPAR-8-BK | |
| 14″ Single Floodlight Arm , AL Finish (38076 Arm+ 38077 Adapter) (CU 1023) | SFA-2A (Arm) + FA-A (Adapter) |
