301992 Awning Adapter Ford Tourneo
Product Information:
The Thule Awning Adapter Ford Tourneo / Transit Custom Thule
4200 is a product designed for Ford Transit Custom and Tourneo
Custom vehicles. It is compatible with models L1H1 (Left-Hand Drive
and Right-Hand Drive) from the year 2013 onwards. The adapter is
specifically designed for use with the Thule 4200 awning, which has
dimensions of 2.60m (width) x 4.97m (length) x 2.36m (height).
Contents:
- M6 x 18 mm DIN 9021 A2 – 6 pieces
- M6 x 9 x 14 mm Blind rivet nut – 8 pieces
- M6 SCHNORR ZN – 8 pieces
- M6 x 16 DIN 603 A2 – 4 pieces
- M6 DIN 985 A2 – 6 pieces
- M6 x 16 mm DIN 965 – TX30 A2 – 2 pieces
- M6 x 20 DIN 7985 – TX30 A2 – 8 pieces
- M6 Nut cap – 6 pieces
- 4.2 x 16 DIN 7504N – TX20 A2 – 4 pieces
Tools Required:
- Sika Activator Anti-Corrosion P120
- TX20 and TX30 screwdriver bits
Product Usage Instructions:
- Apply Sika Activator Anti-Corrosion P120 to the installation
area. - Attach the adapter to the vehicle using the provided screws and
nuts according to the fit guide for your specific vehicle model
(LHD or RHD). - Ensure all screws are tightened to a torque of 6 Nm using a
TX30 screwdriver bit. - Install the Thule 4200 awning onto the adapter using the
provided screws and nuts. - Tighten all screws on the awning to a torque of 6 Nm using a
TX30 screwdriver bit. - Verify that the installation is secure and the awning is
properly attached.
For more information, please visit www.thule.com.
INSTALLATION
Instructions
Thule Awning Adapter Ford Tourneo / Transit Custom Thule 4200
301992, 301970
AD999-01 | 3380072600 2022-02-02
Bring your life thule.com
EN ADAPTER – USER INSTRUCTIONS
Safety
DE Adapter – Bedienungsanleitung NL Adapter – Gebruikershandleiding FR Adaptateur – Instructions d’utilisation IT Adattatore – Istruzioni per l’uso ES Adaptador – Instrucciones de uso SV Adapter – Användarmanual FI Adapteri – Käyttöohje DA Adapter – Brugervejledning NO Adapter – Brukerinstruksjoner PL Adapter – Instrukcja dla uytkownika
1 WARNINGS & INFO
4
Warnungen & Info / waarschuwingen & info / avertissements et informations / avvertimenti e informazioni / advertencias e información / varningar & info / varoitukset ja tiedot / advarsler og info / advarsler og info / ostrzeenia i informacje
2 FITGUIDE
5
Anwendungstabelle / fitting tabel / table d’application / guida di adattamento / guía de aplicación / applikationstabell / sovellus taulukko / applikationstabel / applikasjonstabell / tabela aplikacji
3 CONTENT
6
Inhalt / inhoud / contenu / contenuto / contenido / innehåll / sisältö / indhold / innhold / zawarto
4 TOOLS
6
Werkzeuge / gereedschappen / outils / strumenti / herramientas / verktyg / työkalut / værktøjer / verktøy / narzdzia
5 INSTALLATION
7
Installation / installatie / installation / installazione / instalación / installation / asennus / installation / installasjon / instalacja / indstillinger / innstillinger / ustawienia
AD999-01
3
1 WARNINGS & INFO ?
Instructions
Safety
4
AD999-01
2 FITGUIDE
BRAND
Ford
MODEL
Transit Custom L1H1 LHD Tourneo Custom L1H1 LHD Transit Custom L1H1 RHD Tourneo Custom L1H1 RHD
YEAR
2013-…
ADAPTER
301992 301970
AWNING
T 4200 – 2.60 m
x Y
X
Y
L1
4970 mm
H1
2000 mm
L2
5340 mm
H2
2360 mm
AD999-01
5
3 CONTENT
x6
M6 x 18 mm DIN 9021 A2
x8
M6 x 9 x 14 mm Blind rivet nut
x8
M6 SCHNORR ZN
x4
M6 x 16 DIN 603 A2
x6
M6 DIN 985 A2
x2
M6 x 16 mm DIN 965 – TX30 A2
x8
M6 x 20 DIN 7985 – TX30 A2
x6
M6 Nut cap
x4
4.2 x 16 DIN 7504N – TX20 A2
LHD
RHD
x1
x1
x2
x1
x1
4 TOOLS
sika
6
Activator Anti-Corrosion
Ø 3 mm Ø 3.5 mm Ø 9 mm
P120
TX20 TX30
N° 10
AD999-01
5 INSTALLATION 1
2
L1
+/- 2.17 m
AD999-01
7
Anti-Corrosion
3
x1
x1
A
ø 3 mm ø 9 mm
x8
B
x8
D
x8
8
C
x8
E
1 2
Anti-Corrosion
AD999-01
4
x8 x8
1
2
AD999-01
9
5
x1
x1
sika
P120
Activator
A
1
2
3
sika
Activator
10
AD999-01
B
1
2
x8
x8
6
x8
x1
x1
x8
LHD
TX30
AD999-01
11
A
B
6 Nm
TX30
x8
12
AD999-01
7
8
x2
x3
x3
x4
6 Nm
x6
N° 10
N° 10
TX30
x2
TX30
AD999-01
13
9
=
T 4200 – 2.60 m
1
=
10
x4
A
2
ø 3.5 mm
TX30
x4
Ø 3.5 mm
14
AD999-01
B
TX30
x4
AD999-01
15
Thule NV, Kortrijkstraat 343 BE 8930 Menen, BELGIUM
[email protected] © Thule Group 2020. All rights reserved.
www.thule.com AD999-01
