Optoma W340UST Ultra Short Throw Projector
The Optoma W340UST is a bright WXGA projector with 4000 ANSI
lumens and an ultra short throw lens that can project a 100-inch
image from less than half a meter away. It offers ultimate control
through Crestron, Extron, AMX, PJ-Link, and Telnet LAN commands.
The projector is feature-packed with four-corner adjustment, office
viewer, and optional wireless presentations.
Specifications:
- EAN: 5055387664463
- Colour: White
- DLPTM
- WXGA (1280×800)
- 4000 ANSI Lumens
- Contrast Ratio: 22,000:1
- Natural Aspect Ratio: 16:10
- Supported Aspect Ratio: 4:3,16:9
- Horizontal Scan Rate: 15.375 ~ 91.147 Hz
- Vertical Scan Rate: 24 ~ 85 Hz (120 for 3D)
- Screen Size: 2.16m ~ 2.92m (85 ~ 115 inches) diagonal
- Lamp Type: Lamp
- Lamp Life (Bright): 4000 hours
- Lamp Life (Dynamic): 12000 hours
- Lamp Life (Eco): 10000 hours
- Lamp Life (Eco+): 15000 hours
- Throw Ratio: 0.27:1
- Projection Distance: 0.49m – 0.66m
- Fixed Lens Zoom Type: Fixed
- Fixed Lens Focus Length: 3.72mm/0.146 118%
- Offset: 118%
- Inputs: 1 x HDMI 1.4a 3D support + MHL, 1 x HDMI 1.4a 3D
support, 1 x VGA (YPbPr / RGB), 1 x Composite video, 1 x Audio
3.5mm, 2 x USB-A reader / wireless - Outputs: 1 x VGA, 1 x Audio 3.5mm
- Control: 1 x RS232, 1 x RJ45
- LAN Control: Yes – optional
- Wireless: LAN Display, LAN Wireless – A (Standby)
- Computer Compatibility: 2D Compatibility, 3D Compatibility
- Remote Control: Yes
- Languages: Chinese (simplified), Spanish, Swedish, Chinese
(traditional), Turkish, Vietnamese - Operating System Compatibility: Windows 7 / 8 / 8.1 / 10,
MacOSX 10.9+, Android 4.0+, iOS 8+ - HDCast Pro, QuickCast Bundle, QuickCast starter kit, WHD200,
WUSB: Yes – optional - Power Supply: AC power cord (100 ~ 240V, 50 ~ 60Hz, 0.5A)
- Power Consumption: 200W (Bright), 275W (Dynamic), <5W
(Standby) - Dimensions (W x D x H): 343 x 383 x 112 mm
- Weight: 5.73 kg (Net), 4.87 kg (Without packing)
Product Usage Instructions:
- Place the projector on a flat surface or mount it on a ceiling
using a compatible mount. - Connect the power cord to the projector and plug it into a
power outlet. - Connect your video source (computer, DVD player, etc.) to the
projector using the appropriate cable(s). - Turn on the projector and adjust the focus and zoom to your
desired settings. - Use the remote control or LAN control to adjust other settings
such as brightness, contrast, and color. - To project wirelessly, use the optional HDCast Pro, QuickCast
Bundle, QuickCast starter kit, WHD200, or WUSB. - When done, turn off the projector and unplug it from the power
outlet.
optoma.com.tr
W340UST
Ultra short throw projector
Bright WXGA projector – 4000 ANSI lumens Ultra short throw lens – 100″ image from less than half a metre away Ultimate control – Crestron, Extron, AMX, PJ-Link and Telnet LAN commands
ffi Feature packed – Four corner adjustment, O ce
viewer, optional wireless presentations .
fi Speci cations
EAN: 5055387664463, Colour: White
ö ü ü Ekran ve g r nt ö ü ü G r nt Teknolojisi ö ü ü ü Doal Ç z n rl k ü Parlaklik (L men)
DLPTM
WXGA (1280×800) 4.000
Kontrast Orani
22.000
Doal en boy orani
16:10
Desteklenen en-boy orani
ü Keystone D zeltme (Yatay) ü Keystone D zeltme (Dikey)
4:3,16:9
° +/-4 ° +/-4
Yatay Tarama Hizi (hz)
15.375 ~ 91.147
Dikey Tarama Hizi (Hz)
ü Uniformity (Y zde)
24 ~ 85(120 for 3D) 80
Ekran boyutu
2.16m ~ 2.92m (85″ ~ 115″) diagonal
Lamba bilgisi
I ik Kaynai
Lamba
Lamba (Watt)
ö ü Lamba mr saatleri (en fazla)
240 4000 (Bright), 12000 (Dynamic), 10000 (Eco), 15000 (Eco+)
Optik Atma orani
0.27:1
ProjeksiyonMesafeMetre
0.49m – 0.66m
SabitLensZoomType
Fixed
SabitLensOdak Uzunluu
ff Doal o set
3.72mm/0.146″ 118%
balanti Balantilar
Inputs 1 x HDMI 1.4a 3D destei + MHL, 1 x HDMI 1.4a 3D destei, 1 x VGA (YPbPr / RGB), 1 x Kompozit video, 1 x Ses 3,5 mm, 2 x USB-A okuyucu / kablosuz
Outputs 1 x VGA, 1 x Ses 3,5 mm
Control 1 x RS232, 1 x RJ45
LAN Kablosuz A Genel
ü ü ü ü G r lt D zeyi Tipik (Db) ü ü ü G r lt Seviyesi Max (Db)
Bilgisayar Uyumluluu 2D Uyumluluk
3D Uyumluluk
Proj3DType
ü ü Ür n G venlii
OSDLlang’lar
Çali ma ko ullari
Uzaktan kumanda
ö Hoparl r Sayisi ö Hoparl r Watt
Kutuda
letim Sistemi Uyumluluu
stee bali kablosuz modeller
a LanControl LanDisplay LAN Kablosuz A
Güç ü G ç kaynai ü ü G ç T ketimi / Watt
(Beklemede)
ü ü G ç T ketimi / Watt (Min) ü ü G ç T ketimi / Watt (Maks)
Airlik ve boyutlar
ü Ür n Boyutlari ü Br t airlik
Net airlii
Yes – optional
26 28 FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz) Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60 Full 3D Security bar, Kensington Lock, Password protected interface 25 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian,
fi Chinese (simpli ed), Spanish, Swedish, Chinese (traditional),
Turkish, Vietnamese
° ° ° ° 5 C~40 C/41 F~104 F, max altitude 3000M/9843ft, max
humidity 85%
Lazer ve fare i levli uzaktan kumanda
1 16 AC power cord Remote control 2x AAA batteries Basic user manual Windows 7 / 8 / 8.1 / 10, MacOSX 10.9 +, Android 4.0+, iOS 8+ HDCast Pro, QuickCast Bundle, QuickCast starter kit, WHD200, WUSB
Yes Yes Yes – optional
100 ~ 240V, 50 ~ 60Hz 0.5
200 275
343 x 383 x 112 5.73 kg 4.87 kg
