94719 SB-TE-3G1-10TW1 Car Audio
Product Information
The SB-TE-3G1-10TW1 SKU# 94719 is an enclosure designed for the
2017-Up Tesla Model 3. The enclosure type is sealed and the driver
type is 10TW1-2. The nominal impedance is 2 ohms and the continuous
power handling is 300 watts (RMS method). The product comes with
hardware including screws, washers, brackets, and rubber edge trim.
JL Audio recommends high-quality amplifiers such as the XDM300/1
for power.
Product Usage Instructions
- Empty the rear seat and trunk of the vehicle.
- Lift the rear seat bottom cushion at the front edge corners on
both the driver and passenger sides to expose the release latch
underneath each side. Pull each latch towards the center of the
vehicle to release the rear seat bottom cushion. Lift and remove
the rear seat bottom cushion from the vehicle. - Carefully lift the rear door sill trim panel on each side of
the vehicle to release each panel from the mounting clips. Remove
the rear door sill panels from the vehicle. - Place a blanket over the exposed surfaces under the rear seat
bottom, then fold the rear seat backs down. - Pull the side bolster cushion out at the top to release the
clip, then lift the side bolster cushion up to remove. Repeat on
the passenger side. - Carefully unclip and remove the top pillar panel on the driver
side. Repeat on the passenger side. - Carefully unclip and remove the indicated pillar panel on the
driver side. Repeat on the passenger side. - Pull the driver side seat belt retainer panel forward to
release the mounting hooks and remove. Repeat on the passenger
side. - Remove the two indicated round panel clips from the front edge
of the parcel shelf panel. - Carefully lift up on the front of the parcel shelf panel at
each end to expose the latching mechanism underneath. Release the
latch on each end of the parcel shelf panel. Leave the parcel shelf
panel in place for now. - Disconnect the indicated harness on the driver side and then
disconnect the two indicated harnesses on the passenger side. The
parcel shelf panel should now be free to remove from the
vehicle. - Install the enclosure into the vehicle according to the
instructions provided in the installation guide. Use the included
hardware to secure the enclosure in place.
SB-TE-3G1-10TW1 INSTR_SKU# 011578
· Installation requires appropriate tools and safety equipment. Professional installation is recommended.
· If you prefer to perform your own installation, please read this installation guide completely before beginning.
· Before cutting or drilling, check for potential obstacles behind mounting surfaces.
· Mount this product securely to prevent damage or injury in severe conditions.
INSTALLATION DIFFICULTY:
4 5OUT OF
ESTIMATED TIME: 3 HOURS
INSTALLATION GUIDE for the
SB-TE-3G1-10TW1 SKU# 94719
2017-Up Tesla Model 3
Enclosure Type: Sealed Driver Type: 10TW1-2
Nominal Impedance: 2 ohms Continuous Power Handling: 300 watts (RMS method)
Continued on Next Page
INCLUDED HARDWARE 7 8 9 5
1 2 3 4 6
BOM ID Qty
1
4
2
4
3
4
4
2
5
2
6
4
7
4
8
4
9
4
–
1
SKU 154693 154694 153684 154606 154605 154695 150064 151098 151021 151240
* Not Shown
Page 2 · JL Audio, Inc., 2023
Description 1/4″-20 1-1/4″ Black-Oxide Button Head Screw 1/4″ Black-Oxide Split Lock Washer 1/4″ Black-Oxide Flat Washer Lower Bracket Upper Bracket 1/4″-20 7/8″ Black-Oxide Flanged Button Head Screw 1/4″-20 Hex Nut 1/4″ Split Lock Washer 1/4″ Flat Washer 52″ Rubber Edge Trim*
SB-TE-3G1-10TW1 INSTR_SKU# 011578
Continued on Next Page
SB-TE-3G1-10TW1 INSTR_SKU# 011578
POWER RECOMMENDATION JL Audio recommends high quality amplifiers such as the JL Audio XDM300/1. The diagram below shows the recommended crossover settings for the XDM300/1. For a detailed description of the amplifier settings, consult the owner’s manual for the amplifier. If another amplifier is being used, please reference this illustration and use similar settings on that amplifier.
CONNECTIONS
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your Stealthbox® amplifier. Other kits are available should you be using more than one amplifier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for both channels of the amplifier. JL Audio recommends using 12 AWG speaker wire for subwoofers such as our XC-BCS12-25.
Page 3 · JL Audio, Inc., 2023
Continued on Next Page
STEP 1 Empty the rear seat.
STEP 2 Empty the trunk.
Page 4 · JL Audio, Inc., 2023
STEP 3
Lift the rear seat bottom cushion at the front edge corners on both the driver and passenger sides. This will expose the release latch underneath each side. Once exposed, pull each latch towards the center of the vehicle to release the rear seat bottom cushion. Once unlatched, lift and remove the rear seat bottom cushion from the vehicle.
STEP 4
Carefully lift the rear door sill trim panel on each side of the vehicle to release each panel from the mounting clips. Remove the rear door sill panels from the vehicle.
SB-TE-3G1-10TW1 INSTR_SKU# 011578 STEP 5 Place a blanket over the exposed surfaces under the rear seat bottom, then fold the rear seat backs down.
STEP 6 Pull the side bolster cushion out at the top to release the clip, then lift the side bolster cushion up to remove. Repeat on the passenger side.
STEP 7 Carefully unclip and remove the top pillar panel on the driver side. The panel is held in place with clips. It is also secured from the backside with a safety bungee, which will need to be unclipped before removing the panel. Repeat on the passenger side.
STEP 8 Carefully unclip and remove the indicated pillar panel on the driver side. Repeat on the passenger side.
Continued on Next Page
STEP 9 Carefully pull the driver side seat belt retainer panel forward to release the mounting hooks and remove. Repeat on the passenger side.
STEP 10 Remove the two indicated round panel clips from the front edge of the parcel shelf panel.
S T E P 11 Carefully lift up on the front of the parcel shelf panel at each end to expose the latching mechanism underneath. Release the latch on each end of the parcel shelf panel. Leave the parcel shelf panel in place for now.
STEP 12 Disconnect the indicated harness on the driver side.
Page 5 · JL Audio, Inc., 2023
SB-TE-3G1-10TW1 INSTR_SKU# 011578 STEP 13 Disconnect the two indicated harnesses on the passenger side. The parcel shelf panel should now be free to remove from the vehicle.
STEP 14 Carefully place the parcel shelf panel face down onto a flat surface. Cut and remove the foam padding material from the panel in the indicated area. Note: The foam material has already been removed in this image. Do not cut through the top side of the parcel shelf panel.
STEP 15 Use a pencil or marker to mark the cutout opening on the underside of the parcel shelf as indicated. Once marked, carefully cut the opening.
STEP 16 After cutting the opening in the parcel shelf, wear protective gloves and attach the supplied 52″ Rubber Edge Trim to the perimeter of the cutout.
Continued on Next Page
Page 6 · JL Audio, Inc., 2023
STEP 17 Referring to Page 2 as a guide, create four screw assemblies by sliding a supplied 1/4″ Black-Oxide Split Lock Washer and 1/4″ BlackOxide Flat Washer over a 1/4″-20 1-1/4″ BlackOxide Button Head Hex Drive Screw. Use the four assemblies to attach the supplied left and right Lower Brackets to the sides of the enclosure. Carefully, place the top of the enclosure through the parcel shelf opening.
STEP 18 With the enclosure lifted into place, position it against the rear edge of the parcel shelf mounting hole (towards the rear of the vehicle) and hold it in place.
Use a pencil or a marker to mark the position of the side and rear edges of the left (shown) and right Lower Brackets onto the underside of the parcel shelf surface as indicated.
STEP 19 Carefully lower the Stealthbox from the opening and remove both left and right Lower Brackets from the enclosure.
Align the left Lower Bracket to the marks made in STEP 18. Use a marker to mark the two mounting holes in the left Lower Bracket to the underside of the parcel shelf.
STEP 20 Align the right Lower Bracket to the marks made in STEP 18. Use a marker to mark the two mounting holes in the right Lower Bracket to the underside of the parcel shelf.
SB-TE-3G1-10TW1 INSTR_SKU# 011578 STEP 21 Use a 1/8″ bit to to drill a starter hole in the four bracket hole marks made in STEP 19 and STEP 20.
STEP 22 Use a 1/4″ bit to enlarge the four starter holes drilled in STEP 21.
STEP 23 From inside the vehicle, place one supplied Upper Bracket on the left and one supplied Upper Bracket on the right of the parcel shelf hole as shown. Align the mounting holes of the two Upper Brackets with the holes drilled in STEP 22.
STEP 24 Referring to Page 2 as a guide, pass two 1/4″-20 7/8″ Black-Oxide Flanged Button Head Screws through the mounting holes in each Bottom Bracket, through the rear parcel shelf, and through the Upper Brackets inside the vehicle cabin. From inside the vehicle, use two 1/4″ Flat Washers, two 1/4″ Split Lock Washers, and two 1/4″-20 Hex Nuts per Upper Bracket to fully attach the bracket assemblies to the vehicle.
Continued on Next Page
STEP 25
Route the speaker cable and connect to it to the enclosure’s terminal cup. Carefully place the enclosure into the parcel shelf opening. Align each of the Lower Bracket mounting holes with the threaded inserts on each side of the enclosure. Referring to Page 2 as a guide, use the four screw assemblies created in STEP 17 to fully attach the enclosure to each Lower Bracket.
STEP 26
Close the rear seat back. Reinstall the factory panels and rear seat bottom cushion.
C O N G R AT U L AT I O N S !
SB-TE-3G1-10TW1 INSTR_SKU# 011578
You have completed the installation for this model! Enjoy your new Stealthbox®!
Page 7 · JL Audio, Inc., 2023
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of your vehicle.
Location / OEM Speaker Size
Front Doors / 8.0-inch
Rear / 4.0-inch
Suggested JL Audio Speaker Models
Coaxial Models
Component Models
C1-650x(1), C2-650x(1)
C1-650(1), C2-650(1), C3-650(1), C7-650cw(1,2)
C1-400x(1), C2-400x(1)
C7-350cm(1,2)
1 – Installation may require adaptor, 2 – Component woofer only
®
(954) 443-1100
www.jlaudio.com
All specifications are subject to change without notice. “JL Audio®” and “How we play®” are registered trademarks of JL Audio, Inc. “Ahead of the Curve” and its respective logo are trademarks of JL Audio, Inc.
Printed in USA · ©2023 JL Audio, Inc. · For more detailed information please visit us online at www.jlaudio.com.
JLA-SKU# 011578 · ver. 03.29.23 · 10369 NORTH COMMERCE PARKWAY · MIRAMAR, FLORIDA · 33025 · USA
