TC001-B Canopy Kit
Product Information
The TC001 Canopy Kit comes in five different color options,
including blue, green, orange, red, and dark red. It is designed to
be installed on a tractor ROPS (Roll-Over Protective Structure) and
comes with all necessary hardware components, including aluminum
canopy with 48×38 heat/sound foam, foam strip, L-brackets, cross
bracket, carriage bolts, nylock nuts, rubber iso-mount washers,
flat washers, U-bolts, reinforcement brackets, and installation
tools. The installation manual also includes safety recommendations
and precautions, including the use of hard hats, steel-toe shoes,
gloves, and safety glasses. The use of impact tools is not
recommended as it may void the warranty.
Product Usage Instructions
- Read the installation manual thoroughly before starting the
installation process. Familiarize yourself with the tractor ROPS
and all the steps required for installation. - Prepare the installation brackets by removing them from the
brackets box along with the related hardware. Ensure that the nuts
used are not the nyloc nuts. - Remove the canopy from the canopy box and place it facing
inside up. Attach both cross brackets to the canopy. Make sure that
the foam strip is touching the inside surface of the canopy. - Lower the installation bracket assembly on the left side of
ROPS and use a magnetic level to ensure that the vertical edge of
the installation bracket is perpendicular to the ground. Tighten
the nuts, but do not over-tighten them as you will be taking this
assembly off soon. - Lift the canopy with the cross bracket already installed and
place it over the L-brackets that are already secured to the ROPS.
Ensure that the canopy is centered over the L-brackets. - Remove the installation bracket assembly and repeat the same
process for the right side L-bracket assembly to ROPS. - Secure the canopy cross bracket to the L-bracket slots using
M8-30 carriage bolt, iso-mount washer, flat washer, and M8 nut. Do
not over-tighten to squeeze the rubber iso-mounts.
Note: The installation bracket assembly allows for easy
installation and ensures even height of both L-brackets. Two sets
of holes are provided, use the one that best fits your application.
The canopy is designed for front leaning and rear leaning 3 ROPS as
well as 2 ROPS. We recommend two people lifting the canopy and
placing it over the L-brackets.
Installation Instructions & Operator’s Manual
TC001-B CANOPY KIT, BLUE TC001-G CANOPY KIT, GREEN TC001-O CANOPY KIT, ORANGE TC001-R CANOPY KIT, RED TC001-D CANOPY KIT, DARK RED
Carefully read this installation manual thoroughly and familiarize yourself with the tractor ROPS and all the steps before starting installation of the canopy.
Pay special attention to all “Note” in this manual and any safety messages in the tractor operators manuals. Do not install or use without proper safety equipment, tools and instruction. Follow all recommended precautions and safe operating procedures.
Safety gear recommended:
1. Hard hat 2. Steel toe shoes
3. Gloves
4. Safety glasses
Lock-Out / Tag-Out Instructions: · Lower all equipment to the ground. · Stop engine & remove key. · Hang “DO NOT OPERATE” tag on steering wheel.
HARDWARE KIT COMPONENTS
Sl No Part Name
Canopy Box Contents
1
Aluminum Canopy with 48″x38″ heat/sound foam
2
Foam Strip
Brackets Box Contents
3
L-Bracket LH (Le hand)
4
L-Bracket RH (Right hand)
5
Installaon tool brackets
6
Cross Bracket
Hardware Box (Inside the Brackets Box) Contents
7
Carriage Bolt M8x20mm
8
Carriage Bolt M8x35mm
9
Flange Nylock Nut M8
10
Rubber Iso-mount Washer
11
Flat Washer
12
Set of M12 U bolt, washer and nylock nut
13
Hex Bolt M8x90mm (for Installaon tool asly.)
14
Hex Nut M8 (for Installaon tool asly.)
Quanty
1 2
1 1 2 2
4 4 8 4 4 4 3 3
15
Reinforcement Brackets – 3 inch
4
DO NOT USE IMPACT TOOLS
1 3
4
5
2 6
7
10
9
8
11
12
Tools needed:
– Hand Ratchet Tool
– Deep Sockets (13 mm & 3/4 Inch)
– Magnetic Level
“Use of Impact tools will void any warranty”
13
14 15
1
5
From the Brackets box, remove the installaon brackets(5) and
related hardware(13&14) from the hardware box. Prepare Installaon brackets as shown in pic. 1 above.
From the Canopy box, remove the Canopy(1) and place it facing inside up as shown above. Aach both cross brackets
Note: Ensure that the nuts you use are NOT the nyloc nuts.
to the Canopy using two M8 20 mm bolts(7) & nyloc nuts(9) as shown above.
Note: Foam strip should be touching the inside surface of canopy
2
Lower Installaon bracket assembly on le side of ROPS as shown. Use magnec level to ensure the vercal edge of
6
installaon bracket is perpendicular to ground.
Snug ght the nuts, you will be taking this assembly off soon.
Note: Installation bracket assembly allows for easy installation and ensures even height of both L-brackets. 2 sets of holes are provided, use the one that best fits your application.
Li the Canopy with the cross bracket already installed and place it over the L-brackets that are already secured to the ROPS.
Note: We recommend 2 people lifting the Canopy and placing over the L-brackets.
3
From the Brackets box, remove L-brackets (3&4)and U-bolts, washers, nuts (12) & Reinforcement brackets(15) from the hardware box. Install LH side L-bracket using the 2 sets of U-bolt hardware provided as shown.Use magnec level to ensure level as you ghten nuts over the washers and reinforcement brackets. Remove Installaon bracket assembly and repeat the same process for RH side L-bracket assembly to ROPS.
Note: Canopy is designed for front leaning and rear leaning 3″ ROPS as well as 2″ ROPS.
4
7
Ensure the Canopy is centered over the L-brackets. Adjust it front and back to your liking. Secure the Canopy cross bracket to the L-bracket slots using M8-30(8) carriage bolt, iso-mount washer(10), flat washer(11) and M8 nut(9) as shown above. DONOT Over-ghten to squeeze the rubber ISO-Mounts.
From the Canopy box, remove the two foam strips. Peel and aach adhesive back foam strip to each of the two cross brackets as shown.
Note: Stick foam between the inside slots of cross brackets.
Note: Cross brackets are slotted to fit various widths of Tractor ROPS. L-brackets are also slotted to allow for use of Canopy when riding a tractor or using a backhoe.
Note : (xx) refers to the part Sl. No. in the “Hardware Kit Components” table on front page
“Use of Impact tools will void any warranty”
