RSP220DT Bifacial 220 Watt 12 Volt Monocrystalline Solar Panel
Bifacial 220W Monocrystalline Solar Panel
The Renogy Bifacial 220W Monocrystalline Solar Panel is a
high-quality solar panel that offers more power and durability. It
features a corrosion-resistant aluminum frame and a larger cell
size, which results in higher conversion efficiency and more power
output per surface area.
Key Features:
- Corrosion-resistant aluminum frame
- Larger cell size for increased power output
- High module conversion efficiency
- Top-ranked PTC rating
- Quick and inexpensive mounting
- 100% EL testing on all Renogy modules
- No hot spots guaranteed
- 25 Years Power Output Warranty
- 5 Years Material and Workmanship Warranty
Potential Uses:
The Renogy Bifacial 220W Monocrystalline Solar Panel is suitable
for various off-grid power systems. It can be used in 12V and 24V
battery banks, water pumping systems, signaling systems, and other
off-grid applications.
Electrical Data:
- Maximum Power at STC*: 220 W
- Optimum Operating Voltage (Vmp): 18.78 V
- Optimum Operating Current (Imp): 12.24 A
- Open Circuit Voltage (Voc): 21.86 V
- Short Circuit Current (Isc): 13.41 A
- Module Efficiency: 18.6%
- Maximum System Voltage: 1000 VDC
- Maximum Series Fuse Rating: 20 A
Mechanical Data:
- Solar Cell Type: Monocrystalline (7.2 x 3.6 in)
- Number of Cells: 64 (4 x 16)
- Dimensions: 1547 x 763 x 30 mm / 60.9 x 30.0 x 1.2 in
- Weight: 12.7 kg / 28.0 lbs
- Front Glass: Tempered Glass 0.11 in (2.8 mm)
- Frame: Anodized Aluminum Alloy
- Connectors: MC4 Connectors
- Fire Rating: Class C
Thermal Characteristics:
- Operating Temperature Range: N/A
- Nominal Operating Cell Temperature (NOCT): N/A
- Temperature Coefficient of Pmax: N/A
- Temperature Coefficient of Voc: N/A
- Temperature Coefficient of Isc: N/A
Solar Connectors:
- Rated Current: 20 A
- Maximum Voltage: 1500 VDC
- Maximum AWG Size Range: N/A
- Temperature Range: N/A
- IP Rating: IP 68
Junction Box:
- IP Rating: IP 68
- Diode Type: MD2045S/MD3045S
- Number of Diodes: 2
- Output Cables: 12 AWG 800mm (31.5 in)
Certifications:
- EN IEC61730
- EN IEC61215
- ISO 9001: Quality Management System
*STC: Standard Test Conditions
RSP220DT
Bifacial 220W Monocrystalline Solar Panel
Key Features
The Bifacial 220W solar panels offer more power and durability. Corrosion-resistant aluminum frame. Larger cell size and conversion efficiency for more power output per surface area.
Potential Uses
The Renogy Bifacial 220W Monocrystalline Solar Panel has applications in off-grid power systems. That includes 12 and 24 volts battery banks, water pumping systems, signaling systems, and other off-grid applications.
High module conversion efficiency Top ranked PTC rating Quick and inexpensive mounting 100% EL testing on all Renogy modules No hot spots guaranteed
25 Years Power Output Warranty
5 Years Material and Workmanship Warranty
Renogy | www.renogy.com | [email protected] | T: 909-287-7111 5050 S. Archibald Ave, Ontario, CA 91762
RSP220DT
Bifacial 220W Monocrystalline Solar Panel
Electrical Data
Maximum Power at STC*
Optimum Operating Voltage (Vmp) Optimum Operating Current (Imp) Open Circuit Voltage (Voc) Short Circuit Current (Isc) Module Efficiency
Maximum System Voltage
Maximum Series Fuse Rating
220 W
18.78 V 12.24 A 21.86 V 13.41 A 18.6% 1000 VDC
20 A
Mechanical Data
Solar Cell Type
Monocrystalline (7.2 x 3.6 in)
Number of Cells
64 (4 x 16)
Dimensions 1547 x 763 x 30 mm / 60.9 x 30.0 x 1.2 in
Weight
12.7 kg / 28.0 lbs
Front Glass
Tempered Glass 0.11 in (2.8 mm)
Frame
Anodized Aluminum Alloy
Connectors
MC4 Connectors
Fire Rating
Class C
Thermal Characteristics
OperatingTemp. Range
-40ºC – 85ºC(-40°F – 185°F)
Nominal Operating Cell Temerature (NOCT)
47±2ºC
Temperature Coefficient of Pmax
-0.38%/ºC
Temperature Coefficient of Voc
-0.28%/ºC
Temperature Coefficient of Isc
0.06%/ºC
Solar Connectors
Rated Current Maximum Voltage Maximum AWG Size Range Temperature Range IP Rating
20 A 1500 VDC
12 AWG -40ºC -85ºC(-40°F – 185°F)
IP 68
Junction Box
IP Rating Diode Type Number of Diodes Output Cables
IP 68 MD2045S/MD3045S
2 Diode(s) 12 AWG 800mm (31.5 in)
Certifications
EN IEC61730 EN IEC61215
ISO 9001: Quality Management System
Module Diagram
IV-Curve
RSP220DT Characteristics Versus Voltage
1000 W/m² 13.41
220
current(A)
Voltage (V) Irradiance Dependent Output at 25°C
21.86
**All specifications and data described in this data sheet are tested under Standard Test Conditions (STC – Irradiance: 1000W/m2 , Temperature: 25OC, Air Mass: 1.5) and may deviate marginally from actual values. Renogy and any of its affiliates has reserved the right to make any modifications to the information on this data sheet without notice. It is our goal to supply our customers with the most recent information regarding our products. These data sheets can be found in the downloads section of our website, www.renogy.com
Renogy | www.renogy.com | [email protected] | T: 909-287-7111 5050 S. Archibald Ave, Ontario, CA 91762
