RNG-320D Monocrystalline Solar Panel
Product Information: RNG-320D 320W Monocrystalline Solar
Panel
The Renogy 320W Monocrystalline Solar Panel is an efficient and
reliable solar panel that can convert your residence into an
energy-producing home. It features a black frame and high power
output. The panel is designed for various off-grid systems,
including 12 and 24 volts arrays, water pumping systems, signaling
systems, and other off-grid applications.
Key Features:
- High module conversion efficiency
- Top-ranked PTC rating
- Quick and inexpensive mounting
- 100% EL testing on all Renogy modules
- No hot spots guaranteed
- 25 years power output warranty
- 10 years material and workmanship warranty
Electrical Data:
- Maximum Power at STC*: 320W
- Optimum Operating Voltage (Vmp): 37.1V
- Optimum Operating Current (Imp): 8.63A
- Open Circuit Voltage (Voc): 45.4V
- Short Circuit Voltage (Isc): 9.34A
- Module Efficiency: 18.35%
- Maximum System Voltage: 1000V DC
- Maximum Series Fuse Rating: 20A
Mechanical Data:
- Solar Cell Type: Monocrystalline (6.3 x 6.3 in)
- Number of Cells: 60 (6 x 10)
- Dimensions: 1665 x 1002 x 35 mm (65.6 x 39.4 x 1.4 in)
- Weight: 18 kg (39.7 lbs)
- Front Glass: Tempered Glass 0.13 in (3.2 mm)
- Frame: Anodized Aluminium Alloy
- Connectors: Solar Connectors
- Fire Rating: Class B
Thermal Characteristics:
- Operating Temperature Range: -40°C to 85°C (-40°F to
185°F) - Nominal Operating Cell Temperature (NOCT): 45±2°C
(113±3.6°F) - Temperature Coefficient of Pmax: -0.38%/°C
- Temperature Coefficient of Voc: -0.29%/°C
- Temperature Coefficient of Isc: 0.05%/°C
Junction Box:
- IP Rating: IP68
- Diode Type: THY2550
- Number of Diodes: 2
- Output Cables: 12 AWG 900mm (35.4 in)
Product Usage Instructions:
The Renogy 320W Monocrystalline Solar Panel is designed for use
in various off-grid systems.
Installation:
The panel can be mounted quickly and inexpensively. It is
recommended to install the panel in a location that receives
maximum sunlight exposure. Follow the installation instructions
provided with the panel.
Usage:
The panel can be used in 12 and 24 volts arrays, water pumping
systems, signaling systems, and other off-grid applications. Ensure
that the panel is connected to an appropriate charge controller to
regulate the power output and protect the battery from overcharging
or discharging. Refer to the charge controller manual for
instructions on connecting the panel.
Maintenance:
The panel requires minimal maintenance. Clean the panel
regularly with a damp cloth to remove any dirt or debris that may
accumulate on the surface. Do not use abrasive cleaners or
solvents. Check the panel connections periodically to ensure they
are secure.
For more information, visit www.renogy.com or contact Renogy customer
support at 909-287-7111.
RNG-320D
320W Monocrystalline Solar Panel
Key Features
The Renogy 320W Monocrystalline Solar Panel is the first step to convert your residence to an energy-producing home. The 320W solar panel features a black frame and substantial power output.
Potential Uses
The Renogy 320W monocrystalline solar panel has uses in various off-grid systems. That includes 12 and 24 volts arrays, water pumping systems, signaling systems, and other off-grid applications.
High module conversion efficiency Top ranked PTC rating Quick and inexpensive mounting 100% EL testing on all Renogy modules No hot spots guaranteed
25 Years
Power Output Warranty
10 Years Material and Workmanship Warranty
Renogy | www.renogy.com | [email protected] | 909-287-7111 5050 S. Archibald Ave, Ontario, CA 91762
RNG-320D
320W Monocrystalline Solar Panel
Electrical Data
Maximum Power at STC* Optimum Operating Voltage (Vmp) Optimum Operating Current (Imp) Open Circuit Voltage (Voc) Short Circuit Voltage (Isc) Module Efficiency Maximum System Voltage Maximum Series Fuse Rating
320 W 33.0 V 9.70 A 40.3 V±5% 10.23 A±5% 19.2 % 1500 VDC UL
20 A
Mechanical Data
Solar Cell Type
Monocrystalline (6.3 x 6.3 in)
Number of Cells
60 (6 x 10)
Dimensions 1665 x 1002 x 35 mm (65.6 x 39.4 x 1.4 in)
Weight
18 kg (39.7 lbs)
Front Glass
Tempered Glass 0.13 in (3.2 mm)
Frame
Anodized Aluminium Alloy
Connectors
Solar Connectors
Fire Rating
Class B
Thermal Characteristics
OperatingTemp.Range
-40ºC – 85ºC(-40°F-185°F)
Nominal Operating Cell Temerature (NOCT) Temperature Coefficient of Pmax
Temperature Coefficient of Voc Temperature Coefficient of Isc
47±2ºC -0.44%/°C -0.30%/°C 0.04%/°C
MC4 Connectors
Rated Current Maximum Voltage Maximum AWG Size Range Temperature Range IP Rating
30A 1000V DC
10 AWG -40ºC – 90ºC(-40°F-194°F)
IP 67
Junction Box
IP Rating Diode Type Number of Diodes Output Cables
IP 68 THY2550 2 Diode(s) 12 AWG 900mm (35.4 in)
Certifications
EN IEC61730 EN IEC61215
ISO 9001: Quality Management System
UL61730
Module Diagram
1.4 in [35 mm]
2.2 in [55 mm]
39.4 in [1002 mm] 0.24 in [6 mm] Grounding
0.57 x 0.26 in [14.5 x 6.5 mm]
0.5 in [13 mm]
1.4 in [35 mm]
IV-Curve
RNG-320D Characteristics Versus Voltage
35.4 in [900 mm]
65.6 in [1665 mm] 39.1 in [992 mm]
Current (A) Power (W)
37.7 in [958 mm]
Voltage (V)
*All specifications and data described in this data sheet are tested under Standard Test Conditions (STC – Irradiance: 1000W/m2 , Temperature: 25OC, Air Mass: 1.5) and may deviate marginally from actual values. Renogy and any of its affiliates has reserved the right to make any modifications to the information on this data sheet without notice. It is our goal to supply our customers with the most recent information regarding our products. These data sheets can be found in the downloads section of our website, www.renogy.com
Renogy | www.renogy.com | [email protected] | 909-287-7111 5050 S. Archibald Ave, Ontario, CA 91762
