ALFATRON ALF 12X-CAM Instructions
TECHNICAL SPECIFICATIONS
SPECIFICATION
| Sensor | 1⁄2.8-inch-high quality HD CMOS sensor |
| Effective Pixels | 16:9 2.07 megapixel |
| Video Format |
|
| Optical Zoom | 12X f= 3.9~46.1mm |
| View Angle | 16.3° (tele) 72.5°(wide) |
| AV | F1.8 – F2.4 |
| Digital Zoom | 10X |
| Minimum Illumination | 0.5Lux (F1.8, AGC ON) |
| DNR | 2D & 3D DNR |
| White Balance | Auto / Manual/ One Push/ 3000K/ 4000K/5000K/6500K |
| Focus | Auto/ Manual |
| Aperture | Auto / Manual |
| Electronic Shutter | Auto / Manual |
| BLC | ON/OFF |
| WDR | OFF/ Dynamic Level Adjustment |
| Video Adjustment | Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve |
| SNR | >55dB |
INPUT/OUTPUT INTERFACE
| Video Interfaces | USB2.0, USB3.0, HDMI, LAN, RS232 (input) |
| Image Code Stream | Double streams output simultaneously |
| Video Compression Format | H.264, H.265 |
| Control Signal Interface | RS-232 Ring through RS232 output, RS-485 |
| Control Protocol | VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps |
| HD IP Interface | 100M IP port(100BASE-TX); 5G WiFi (optional), support IP Visca control protocol |
| Network Protocol | RTSP/RTMP, ONVIF |
| Power Interface | HEC3800 outlet (DC12V) |
PTZ PARAMETER
| Pan Rotation | ±170° |
| Tilt Rotation | -30~+90° |
| Pan Control Speed | 0.1 – 180°/sec |
| Tilt Control Speed | 0.1 – 80°/sec |
| Preset Speed | Pan: 60°/sec, Tilt: 30°/sec |
| Preset Number | 255 presets (10 presets by the remote controller) |
OTHER PARAMETER
| Supply Adapter | AC110V-AC220V to DC12V/2A |
| Input Voltage | DC12V±10% |
| Input Current | 1A(Max) |
| Consumption | 12W (Max) |
| Store Temperature | -10°C to +60°C |
| Store Humidity | 20% – 95% |
| Working Temperature | -10°C to +50°C |
| Working Humidity | 20%–80% |
| Dimension | 150mmX150mmX167.5mm |
| Weight | 1.4KG |
| Working Environment | Indoor |
| Remote Operation (IP) | Remote Upgrade, Reboot, and Reset |
| Accessories | Power Supply, RS232 Control Cable, USB3.0 Cable, USB2.0 Cable, Remoter, Manual, Warranty card |
| Wall or Ceiling Bracket |
