T-led Tubo Led Surface Mounted Luminaire User Guide

TUBO LED Surface Mounted Luminaire

Product Information

• Product Name: TUBO
• Technical Specification: 8W, 220-240V
• Dimensions: 90mm x 90mm
• Model Number: TUB001
• Rated Lifetime: 25000 hours
• Color Rendering Index (CRI): Not specified
• Power Supply: 220-240V~ 50Hz
• Ingress Protection Rating: IP44
• Manufacturer: T-LED s.r.o.
• Country of Origin: The Czech Republic

Product Usage Instructions

1. Make sure the power supply is compatible with the product’s
   voltage rating (220-240V~ 50Hz).
2. Mount the TUBO light fixture in the desired location.
3. Connect the Live (L) and Neutral (N) wires of the power supply
   to the appropriate terminals of the TUBO fixture. Ensure proper
   electrical connections.
4. Turn on the TUBO light fixture by switching it to the “ON”
   position. The switch may be labeled as “ON/ZAPNOUT”.
5. To turn off the TUBO light fixture, switch it to the “OFF”
   position. The switch may be labeled as “OFF/VYPNOUT”.

Note: The TUBO light fixture has an IP44 ingress protection
rating, which means it is protected against solid objects larger
than 1mm and water splashes from any direction. For detailed
installation and safety instructions, please refer to the user
manual provided by the manufacturer or visit the website www.t-led.cz.

EN CZ

TUBO
LED SURFACE MOUNTED LUMINAIRE LED SVÍTIDLO PISAZENÉ

?

EN Technical specification

CZ Technické specifikace

Watts / Píkon Volts / Vstupní naptí Ingress protection / IP krytí Beam angle / Úhel svitu Colour temperature / Barevná teplota Luminous flux / Svtelný tok (lm)

8W 220-240V
IP44 60° CCT (3000K+4000K+6500K) 650lm / 700lm / 720lm

EN Dimensions CZ Rozmry
90mm

90mm

TUB001
Installation guide / Montázní návod
EN 1. All handling with the luminaire must be carried out only when the luminaire is disconnected from the mains. 2. Screw the bracket on the ceiling. 3. Connect the cable. 4. Insert the luminaire to the bracket. 5. Turn on the switch of the mains. 1. Veskerou manipulaci se svítidlem provádt pouze pi odpojeném napájení ze sít.
CZ 2. Pomocí sroub pipevnte drzák na strop.
3. Pipojte pívodní kabely ke svítidlu. 4. Pipevnte svítidlo k drzáku. 5. Zapnte pívod napájení.
1
OFF/VYPNOUT OFF
2

99,7mm

EN What is in the box CZ Obsah balení

3
L N
4

5

ON

ON/ZAPNOUT

! WARNING / UPOZORNNÍ
EN Installation can be carried out by a qualified person only DE Montage darf nur qualifizierte Person durchführen CZ Instalaci smí provádt pouze odborn zpsobilá osoba SK Montáz môze vykonáva iba kvalifikovaná osoba HU A szerelést megfelel szakképzettséggel rendelkez személynek kell végeznie PL Montau dokonywa moe tylko wykwalifikowana osoba

25000h

CRI

220-240V~ 50Hz

IP44

www.t-led.cz

T-LED s.r.o.

60°

Zitná 610/23, 110 00 Prague

The Czech Republic
