CC-1200R Balanced Phono Cable
Product Information
Product Name: CC-1200R
Manufacturer: Kyodo Denshi Engineering Co.,
Ltd.
Model: EA-1200EQ
Description: The CC-1200R is a high-quality MC
cartridge designed for audio playback. It features a balanced
transmission of the cartridge output and a special structure for
balanced transmission from the RCA output terminal. The RCA plugs
are rhodium-plated for enhanced sound quality. The cartridge is
made with PC TripleC material, ensuring durability and
performance.
Product Usage Instructions
RCA Connector and Earth Terminal:
- Connect the RCA output of the player to the RCA inputs of the
tone arm. - Connect the earth terminal to the pre-amplifier and
phono-amplifier. - Note: Some players with built-in phono amplifiers may generate
hum noises if the RCA outputs are not floating with earth.
XLR Connectors:
- The CC-1200R has XLR connectors for balanced transmission.
- Connect the XLR connectors to compatible devices, ensuring that
the right channel (Rch) and left channel (Lch) are connected
correctly. - Caution: Normal operation cannot be performed if both RCA and
XLR connectors are connected at the same time, and it may cause a
defection.
Earth Terminal (EA-1200EQ):
- Connect the earth terminal to either the CC-1200R or the
pre-amplifier/phono-amplifier. - Note: In some cases, there may be less noise if the earth
terminal is not connected. Please check before using.
Contact Information:
Kyodo Denshi Engineering Co., Ltd.
Address: 8-40-17 Shinyoshidahigashi, Kohoku-ku, Yokohama-shi,
Kanagawa 223-0058 Japan
Phone: +81-45-710-0975
Email: [email protected]
Website: https://www.phasemation.com
$$3
#”-“/$&%1)0/0$”#-&
Owner’s Manual
.BJO’FBUVSFT 1. A Balanced Transmission of the Cartridge Output
The power generation of the MC cartridge is by the coil. Since opposite phase (push-pull) signals are generated at both ends of the coil, it makes a balanced operation. Therefore, balanced transmission to the phono amplifier is the utmost way to minimize loss. The weak voltage of the cartridge is what makes it exert its strength.
2. A Balanced Transmit From the RCA Output Terminal
Although the RCA terminal is unbalanced, the record player’s RCA terminal is not grounded and therefore the CC-1200R has a special structure that allows it to send a balanced transmission.
3. PC TripleC Material
In order to bring out 100% of the cartridge’s performance, an ultra-thick PC Triple C wire of 1.25 Sq (mm²) was adopted. PC Triple C’s low distortion rate and high conductivity allow the weak signal from the cartridge to be transmitted to the phono amplifier without loss of signals.
4. Rhodium Plating
The RCA plug are rhodium-plated which has a reputation for high sound quality.
/BNFT
‘VODUJPOT
BOE$POOFDUJPOT
8IFODPOOFDUJOHUP5
RCA Connector and Earth Terminal Connect to the tone arm and to the RCA outputs of the player. The RCA output of the player are floating with earth, and therefore it is specially structured so that they can be connected in balance.
Caution
Some players, such as those with built-in phono amplifiers (RCA outputs not floating with earth) will generate hum noises.
8IFODPOOFDUJOHUP&”
Kyodo Denshi Engineering Co., Ltd. 8-40-17 Shinyoshidahigashi, Kohoku-ku, Yokohama-shi, Kanagawa 223-0058 Japan TEL: +81-45-710-0975 FAX: +81-45-710-0976 E-mail: [email protected] URL: https://www.phasemation.com
is the original audio brand of Kyodo Denshi Engineering Co., Ltd.
XLR Connector (Right) The one with the red ring is Rch
Normal operation cannot be performed if RCA and XLR are connected at the same time and can cause a defection.
PUSH
2
1
3
NEUTRIK
5
XLR Connector (Left) The one with the white ring is Lch
PUSH
2
1
3
NEUTRIK
MODEL EA-1200EQ
DC IN
Earth Terminal Connect the earth also to the pre-amplifier and phono-amplifier. However there are rare cases that there is less noise if not connected to earth. Therefore check before using.
XLR Connector (Right) The one with the red ring is Rch
Normal operation cannot be performed if RCA and XLR are connected at the same time and can cause a defection.
OUTPUT 1
2
GND
INPUT
GND
3
PUSH
2
1
3
NEUTRIK
2
PUSH
2
1
3
NEUTRIK
1
PUSH
2
1
3
NEUTRIK
XLR Connector (Left) The one with the white ring is Lch
INPUT
1
PUSH
2
1
3
NEUTRIK
2
PUSH
2
1
3
NEUTRIK
3
PUSH
2
1
3
NEUTRIK
GND GND
&”
OUTPUT 1
MODEL EA-1200EQ
DC IN
2
Earth Terminal For EA-1200, connect the earth to the terminal of either unit. However there are rare cases that there is less noise if not connected to earth. Therefore check before using.
