Ds18 Pro-ns8 8 Inch Mid Range Loudspeaker With Ultra Slim Neodymium Magnet Owner's Manual

DS18 PRO-NS8 8 Inch Mid Range Loudspeaker with Ultra Slim Neodymium Magnet

PRO-NS8

SPECIFICATIONS

• Nominal Diameter ………………………………………………………….4” / 102 mm
• Nominal Impedance ………………………………………………………………..4 OHMS
• AES Power Handling ……………………………………………………. 125 Watts
• Program Power Handling ……………………………….. 250 Watts
• Peak Power Handling……………………………………………… 500 Watts
• Sensitivity (1w/1m) ……………………………………………………………… 106 dB
• Frequency Response …………………………………………………..3K – 20KHz
• Recommended Hi Pass Crossover………………………………..3KHz

BODY | FEATURES

• Pair or Single ………………………………………………………………………….Single
• Body Material ………………………………………………………. Aluminum
• Body Color …………………………………………………………………………… Black
• Bullet Material…………………………………………………………. Aluminum

MOTOR

• Voice Coil Diameter…………………………………………… 1.5” / 38 mm
• Voice Coil Former Materia…………………………………….Kapton
• Winding Material……………………………………………………………………CCAW
• Diaphragm Material ………………………………………. Aluminum
• Magnet Material…………………………………………………………….. Ferrite
• Magnet Weight ……………………………………………………………………………………14 Oz

MEASUREMENTS

• Overall Diameter ……………………………………………………………………….4”/ 102 mm
• Overall Depth…………………………………………………………………. 2.58”/ 65.5 mm
• Front Mount Baffle Cutout …………………………………3.62” / 92 mm
• Mounting Depth ……………………………………………………….2.36” / 60 mm
• Motor Diameter……………………………………………………………….. 3.5” / 90 mm

FOR MORE INFORMATION
PLEASE VISIT: DS18.COM
