Tp-link 7106509844 Deco Router Installation Guide (+ PDF)

7106509844 Deco Router
Installation Guide

Contents hide

1 Getting Started

2 LED Status

3 Safety Information

4 GNU General Public License Notice

5 Documents / Resources

5.1 References

6 Related Posts

Getting Started

Please remain online (Wi-Fi or mobile data) throughout the app download and login steps.
Download the TP-Link Deco app for iOS or Android. The app will walk you through the setup.

http://www.tp-link.com/support

LED Status

Each Deco has an LED light that changes color according to its status. See the explanation below.

LED	DECO STATUS
Pulse Yellow	Deco is resetting.
Solid Yellow	Deco is starting up.
Pulse Blue	Deco is ready for setup.
Solid Blue	Deco is setting up.
Pulse Green/Pulse White	Deco is upgrading firmware.
Solid Green/Solid White	Deco is all set up and connected to internet.
Pulse Red	The satellite Deco is disconnected from main Deco.
Solid Red	Deco has an issue.

Safety Information

Adapter shall be installed near the equipment and shall be easily accessible.
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Do not use the device where wireless devices are not allowed.
Use only power supplies which are provided by manufacturer and in the original packing of this product. If you have any questions, please don’t hesitate to contact us.

Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk.

Unit	Restricted substances and its chemical symbols
Unit	Pb	Cd	Hg	Cr⁺⁶	PBB	PBDE
PCB
Shell
Power Supplier	—
Others and accessories	—

Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition.
Note 2: “ ” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.
Note 3: The “—” indicates that the restricted substance corresponds to the exemption.

TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/.
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca/.

For TP-Link Branded Products Only. For the information about warranty period, policy and procedures, please visit https://www.tp-link.com/en/support
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE (OR BY COUNTRY OR PROVINCE).
TO THE EXTENT ALLOWED BY LOCAL LAW, THIS WARRANTY AND THE REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS.
TP-Link warrants the TP-Link branded hardware product contained in the original packaging against defects in materials and workmanship when used normally in according with TP-Link’ s guidelines for some period which depends on the local service from the date of original retail purchase by the end-user purchaser.

Max output power

2400MHz ~ 2483.5MHz / 20dBm
5150MHz ~ 5250MHz (Indoor use only) /23dBm
5250MHz ~ 5350MHz (Indoor use only) /23dBm
5470MHz ~ 5725MHz /30dBm
5470MHz ~ 5725MHz /23dBm (For Network Adapater only)
For Telephony DSL only: 1880MHz ~ 1900MHz / 24dBm (conducted power)

AT	BE	BG	CH	CY	CZ	DE	DK
EE	EL	ES	Fl	FR	HR	HU	IE
IS	IT	LI	LT	LU	LV	MT	NL
NO	PL	PT	RO	SE	SI	SK	UK(NI)

Attention: In Great Britain, the operation in the frequency range 5150MHz – 5350MHz is only permitted indoors.

GNU General Public License Notice

This product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”). As applicable, TP-Link (“TP-Link” in this context referring to the TP-Link entity offering respective software for download or being responsible for distribution of products that contain respective code) provides, by itself or with the support of third parties (e.g. the TP-Link Corporation Limited), mail service of a machine readable copy of the corresponding GPL source code on CD-ROM upon request via email or traditional paper mail. TP-Link will charge for a nominal cost to cover shipping and media charges as allowed under the GPL. This offer will be valid for at least 3 years.
For GPL inquiries and the GPL CD-ROM information, please contact [email protected] or write to Suite 901, New East Ocean Centre, Tsim Sha Tsui, Hong Kong. Additionally, TP-Link provides for a GPL-Code-Centre under https://www.tp-link.com/en/support/gpl/ where machine readable copies of the GPL source codes used in TP-Link products are available for free download.
Please note, that the GPL-Code-Centre is only provided for as a courtesy to TP-Link’s customers but may neither offer a full setof source codes used in all products nor always provide for the latest or actual version of such source codes.
The GPL Code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For further information about GNU General Public License please refer to the following website: https://static.tp-link.com/resources/document/GPL%20License%20Terms.pdf

Need some help?
Visit https://www.tp-link.com/support/ for technical support, the user guide, FAQs, warranty & more
