F41824-BZ 30.91 Inch 4-Light Bronze Vanity Light
Product Information
- Product Name: [Product Name]
- Manufacturer: [Manufacturer]
- Model Number: [Model Number]
Product Usage Instructions
- Ensure safety precautions are followed, including wearing
safety glasses and using a ladder if necessary. - Gather the required tools:
- Ladder
- Safety glasses
- Electrical Phillips screwdriver
- Flat blade screwdriver
- Pliers
- Wire strippers
- Check the hardware included in the package:
- Fixture
- Glass shade
- Mounting Unit
- Ball Nuts
- Mounting Screws
- Wire Nuts
- Begin the installation process:
- Step 1: Unscrew the ball nuts from the mounting unit. Use the
mounting screws to attach the mounting unit to the junction box
(not included).
- Step 2: Make the electrical connection from the junction box
(not included) to the fixture. Connect the ground wire to the
mounting unit using the preinstalled green ground screw. Next,
connect the positive, negative, and ground wires with the supplied
wire nuts. Secure with electrical tape.
- Step 3: Attach the fixture to the mounting unit through screw
holes as shown, and secure it with ball nuts.
- Step 4: Remove the socket rings from the socket. Attach the
glass shade onto the fixture using socket rings.
- Step 5: Install bulbs (not included).
- Step 1: Unscrew the ball nuts from the mounting unit. Use the
ASSEMBLY INSTRUCTIONS
CAUTION
³Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation.
³Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by
removing the fuse at the fuse box.
@ If you need further assistance, please contact us by Email: [email protected] TOOLS REQUIRED
Ladder
Safety glasses
Electrical
Phillips
tape
screwdriver
Flat blade screwdriver
Pliers
Wire strippers
HARDWARE INCLUDED
Fixture
Glass shade
Mounting Unit
Ball Nuts Mounting Screws Wire Nuts
*PARTS SHOWN MAY DIFFER SLIGHTLY PER LIGHT FIXTURE
EXPLODED PARTS
INSTALLATION
Junction Box (not included) Wire Nuts Mounting Screws
Ball Nuts
Fixture
STEP 1
Unscrew the ball nuts from the mounting unit. Use the mounting screws to attach the mounting unit to the junction box (not included).
Mounting Unit
Glass shade Socket Ring
Bulbs (not included)
STEP 2
Make the electrical connection from the junction box (not included) to the fixture. Connect the ground wire to the mounting unit using the preinstalled green ground screw. Next, connect the positive, negative and ground wires with the supplied wire nuts. Secure with electrical tape.
Black or Red wire (hot) from the junction box
White wire (neutral) from the junction box
Bare or Green ground wire from the junction box
*Sealing tape (not included)
Black wire from the fixture
White wire from the fixture
Ground wire from the Fixture
*Green Ground Screw
ASSEMBLY INSTRUCTIONS INSTALLATION
STEP 3
Attach the fixture to the mounting unit through screw holes as shown, and secure it with ball nuts.
*junction box (not included)
STEP 4
Remove the socket rings from the socket. Attach the glass shade onto fixture using socket rings.
STEP 5
Install bulbs (not included).
