4468102-112 Alvin Vanity Light
Product Information: Alvin Wall
The Alvin Wall is a lighting fixture suitable for damp
locations. It is available in both incandescent and LED versions.
The incandescent version can be dimmed with a standard incandescent
dimmer, while the LED version can be dimmed with a LED dimmer. The
fixture should be installed using an NEC compliant junction box and
must be installed by a person familiar with the construction and
operation of the product and the hazards involved. The product has
a mounting plate, socket, shade collar nut spacer, shade tool, and
cap nut for easy installation.
Product Usage Instructions: Installation of Alvin Wall
- Secure the mounting plate to the junction box.
- Connect the fixture to a suitable ground in accordance with
local electrical codes. - Connect the white fixture wire to the neutral power line wire
with a wire nut. - Connect the black fixture wire to the hot power line wire with
a wire nut. - Neatly place the wires into the junction box, place the fixture
onto the mounting studs, and secure it in place by screwing the cap
nuts onto the studs. - Place the shade, then the spacer on to the socket and secure
them in place by screwing the shade collar nut onto the socket
using the shade tool. Do not over tighten. If necessary, repeat for
all the other shades. - Screw the lamp(s) into the socket(s). Refer to the label on the
socket for Max Wattage Information.
Note: Consult lamp manufacturer for additional information.
Installation Instructions for
Alvin Wall
ALVIN_WALL
4168101, 446810_ 1.0
WALL
GENERAL PRODUCT INFORMATION:
These fixtures are intended to be installed utilizing NEC compliant junction boxes. This product is safety listed for damp locations.
Incandescent version may be dimmed with a standard incandescent dimmer. LED version may be dimmed with a LED dimmer. Consult lamp manufacturer for additional information.
This instruction shows a typical installation.
CAUTION – RISK OF FIRE This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved.
Use minimum 90°c supply conductors.
SAVE THESE INSTRUCTIONS!
©2022 Visual Comfort & Co., L.L.C. All rights reserved. The Visual Comfort & Co. logo is a registered trademark of Visual Comfort & Co. Visual Comfort & Co. reserves the right to change specifications for product improvements without notification.
7400 Linder Ave., Skokie, IL 60077 T 847.410.4400 | F 847.410.4500
www.generationlighting.com
Install the Fixture
1A
LAMP
7
SHADE COLLAR NUT SPACER
6
SHADE TOOL
SHADE
JUNCTION BOX
MOUNTING PLATE
SOCKET
1 3
5 2
4
1
CAP
NUT
1 Secure the mounting plate to the junction box. 2 Connect the fixture to a suitable ground in accordance with local electrical codes. 3 Connect the white fixture wire to the neutral power line wire with a wire nut. 4 Connect the black fixture wire to the hot power line wire with a wire nut. 5 Neatly place the wires into the junction box, place the fixture onto the mounting studs, and secure it in place by screwing
the cap nuts onto the studs. 6 Place the shade, then the spacer on to the socket and secure them in place by screwing the shade collar nut onto the socket
using the shade tool. Do not over tighten. If necessary, repeat for all the other shades. 7 Screw the lamp(s) into the socket(s). Refer to the label on the socket for Max Wattage Information.
2
