Vevor Zipline Slacker Trolley Instruction Manual (+ PDF)

The frequency of inspection and maintenance will vary with the
type of equipment or materials used or other factors (e.g. heavy
use, levels of vandalism, coastal location, air pollution, age of
equipment). All parts of the product need to be checked regularly
by the user to minimize the risk of accidents. Special attention
should be paid to the cable tensioners, cable spanner, and
trolley.

Routine visual inspection (weekly to monthly):

Always check that the bolts and nuts are securely
fastened.
Check the shock-absorbing surface for objects that don’t belong
there.
Check for missing parts.
Check the equipment ground clearances.

Operational inspection (1 to 3 months):

Check the stability of the construction.
Check every part for excessive wear and remove when
necessary.

Annual inspection (1 up to 2 times per year):

Check for rust and corrosion.
Check every part for excessive wear and remove when
necessary.

Instructions for Cable Height

In order to assemble the zip wire correctly and safely, the
following height requirements need to be followed. One end of the
cable must be mounted at a higher level than the other end. These
heights are dependent on the height of the user and the distance
between the fixing points. In order to determine the right heights,
the following steps must be followed:

Measure the height of the user. If there is more than one user,
and the difference in height is less than 15 cm, use the height of
the tallest user. If the difference is more than 15 cm, the zip
wire needs to be adjusted every time the user’s height is outside
the specified range.
Add 75 cm to the measured height of the user and mark this
point on the tree or construction frame.
Measure the distance between the 2 fixing points. Determine the
corresponding height in the following table and mark this height on
the tree / construction at the other side.

Height User	Height Lowest Fixing Point (x)	Minimum Highest Right	Wrong
1.2m	1.4m	2.9m	2.75m
1.5m	1.7m	3.0m	2.9m
1.8m	2.0m	3.2m	3.0m
	2.1m	3.35m	3.2m
	2.3m	3.5m	3.35m

Product Usage Instructions

Step 1:

Wrap the cable sling around the tree. Pass the looped ends of
the cable sling through the turnbuckle. Use M13 wrench to fix one
end and use Y-type socket key M12 to tighten the turnbuckle’s
screws. Both ends are fixed in the same way.

Step 2:

Pass the main cable through the zipline trolley and spring
brake.

Step 3:

Follow the instructions for cable height to determine the
correct height for mounting the other end of the cable.

Step 4:

Repeat Step 1 to secure the other end of the cable.

Step 5:

Attach any optional accessories as desired.

Note: Always perform routine visual inspections and operational
inspections before each use to ensure safety and minimize
accidents.

View Fullscreen

(OUTDOOR USE)
INSTRUCTION MANUAL

Ver.1

Zipline Trolley

GUIDLINES FOR USE
1. Always start from a secure and stable platform. 2. Always hold the trolley firmly with both hands (or hold on tight to the rope of the monkey swing if applicable). 3. Release the trolley only when it has reached complete standstill, and feet can be placed onto the ground/platform. 4. Always use the product under supervision of an adult. 5. Always check the structure, fixings, trolley, cable tensioners, cable spanner and cable before using the zip wire. 6. Do not allow children under, next to or in the neighbourhood of the construction when it is in use. 7. Do not wear loose fitting clothing (ponchos, scarfs…) when using the zip wire. This can be dangerous because of entrapment risk. 8. Do not use the zip wire when the construction and the trolley are wet. 9. Only the KBT monkey seat with special D-shackle is permitted to be attached to the trolley of the zip wire. The use of any other seats, ropes…. is considered as inappropriate use and is deemed to be dangerous.
INSPECTION AND MAINTENANCE
The frequency of inspection and maintenance will vary with the type of equipement or materials used or other factors (e.g. heavy use, levels of vandalisme, coastal location, air pollution, age of equipment, …). All parts of the product need to be checked regularly by the user to minimise the risk of accidents. Special attention should be paid to the cable tensioners, cable spanner and trolley.
Routine visual inspection (weekly to monthly) – Always check that the bolts and nuts are securely fastened. – Check the shock absorbing surface for objects that don’t belong there. – Check for missing parts. – Check the equipment ground clearances.
Operational inspection (1 to 3 months) – Check the stability of the construction. – Check every part for excessive wair and remove when necessary.
Annual inspection (1 up to 2 times per year) – Check for rust and corrosion. – Check every part for excessive wair and remove when necessary.
01

INSTRUCTIONS FOR CABLE HEIGHT
In order to assemble the zip wire correctly and safely, the following height requirements need to be followed. One end of the cable must be mounted at a higher level than the other end. These heights are dependant on the height of the user and the distance between the fixing points. In order to determine the right heights, the following steps must be.
FOLLOWED:
01. Measure the height of the user. If there is more than one user, and the difference in height is less than 15 cm, use the height of the tallest user. If the difference is more than 15 cm, the zip wire needs to be adjusted every time the user’s height is outside the specified range.
02. Add 75 cm to the measured height of the user and mark this point on the tree or construction frame.
03. Measure the distance between the 2 fixing points. Determine the corresponding height in the following table and mark this height on the tree / construction at the other side.

Height user

Height lowest fixing point (x)

1,2m 1,4m 1,5m 1,7m 1,8m

2m 2,1m 2,3m 2,45m 2,6m

Height highest fixing point according to the following distances between the 2 fixing points (y)

24,5m

21,5m

18,5m

15,5m

12,5m

2,9m 3m 3,2m 3,35m 3,5m

2,75m 2,9m 3m 3,2m 3,35m

2,6m 2,75m 2,9m 3m 3,2m

2,45m 2,6m 2,75m 2,9m 3m

2,3m 2,45m 2,6m 2,75m 2,9m

MINIMUM HIGHEST

RIGHT WRONG
02

TOOLS REQUIRED

Y-TYPE SOCKET KEY

THICK GLOVES
Recommend to wear thick gloves when assembling (Not included).

HARDWARE

330 LBS CAPACITY (COMBINED)

2 PERSON ASSEMBLY

APPROXIMATELY 30 MIN.
ASSEMBLY

TURNBUCKLE ×1 PC
4

SWING ×1 PC
5

ZIPLINE TROLLEY ×1 PC

CABLE SLING ×1 PC

MAIN CABLE ×1 PC

OPTIONAL ACCESSORIES

L-TYPE SOCKET WRENCH M8/M10/M12
×1 PC

WRENCH M13 ×1 PC

U CLAMPS ×3 PCS

SPRING BRAKE ×1 PC

THE NEUTRAL MANUAL FOR THE ALL SPARE PARTS, IT DOESN’T MEAN THAT THE ITEM INCLUDES ALL THE ACCESSORIES. IT JUST DEPENDS ON WHICH SET YOU CHOOSE.
03

PRODUCT ASSEMBLY
1 Wrap the cable sling around the tree.Pass the looped ends of the cablesling through the turnbuckle.Use M13 wrenche to fix one end and use Y-type socket key M12 to tighten theturnbuckle’s screws.cBoth ends are fixed in the same way
1

M13 B

A M12

2 Pass the main cable through the zipline trolley and spring brake.

THE NEUTRAL MANUAL FOR THE ALL SPARE

PARTS, IT DOESN’T MEAN THAT THE ITEM

INCLUDES ALL THE ACCESSORIES. IT JUST

DEPENDS ON WHICH SET YOU CHOOSE.

PRODUCT ASSEMBLY
3 Wrap the main cable around the another tree.Fix the main cable with U-clamps.Tighten the screws of the U-clamps with Y-type socket key M8. At least three U-clamps(the more the better) are required for fixing the main cable. C
D

4 Open the lock under the zip line trolley and
install the swing on the lock.
3

A M8

2
5 Tighten the turnbuckle as shown in the figure to keep the main cable straight.
1
05

INSTRUCTIONS FOR USE
1. Please keep this instruction sheet safely for future reference, and ensure that you review it with all users. 2. Inappropriate use or faulty application of the product is explicitly forbidden and absolves the manufacturer of all liability. 3. The use of the item is allowed only under continuous supervision by an adult. The product is only intended for use as a zip wire between two points, for 1 user older than 8 years and with a maximum weight of up to 150 kg. 4. The zip wire should only be used after it has been properly installed according to the following guidelines. 5. The application of the item as part of a play frame or any other construction will have to be such that it excludes all risk of entrapment. 6. When mounting or assembling the product, attention should be given to the minimum required distance between the product and eventual obstacles: walls, fencing, … This distance should be a minimum of 2 metres. 7. In this safety area no hard, angular or pointed objects should be present. The surface underneath the product should be flat and shock absorbing. The product must not be placed on tarmac, concrete or any other hard surface. We advise the removal and storage of all accessories during winter because the characteristics of the soil (when frozen) are not suitable for safe play. 8. Please ensure that the tree, branch or construction to which the zip wire is attached, is able to support a weight of 300 kg.
WARNING
Adult assembly and supervision required. This product should be unpacked and assembled by an adult,including site and tree selection. In unassembled state, it contains potentially hazardous small objects, please keep out of children’s reach. Max User Weight 150kg User Age 3+ Make sure overhead can support 300kg
06
