EC18006, EC18007 Florence Screen Kit with Planter Box
Product Information
The Florence Screen Kit with Planter Box is a product from
EncloScreens. The approximate assembly time for one screen is 45
minutes. The kit comes in two colors: Cedar (EC18006) and Ash
(EC18007). The product dimensions and specifications are as
follows:
- Overall dimensions: 46 in x 44 in x 11 in
- Planter box dimensions: 44 in x 9 1/2 in x 7 3/4 in
- Floor board dimensions: 7/8 in x 7 1/4 in x 44 in
- Long board dimensions: 7/8 in x 11 in x 44 in
- Short board dimensions: 7/8 in x 11 in x 7 1/4 in
- Thin horizontal slat dimensions: 7/8 in x 1 1/2 in x 44 in
- Wide horizontal slat dimensions: 7/8 in x 3 in x 44 in
- Right and left post dimensions: 1 3/4 in x 1 3/4 in x 44
in - Short post dimensions: 1 3/4 in x 1 3/4 in x 11 in
- Long floor support dimensions: 7/8 in x 1 1/2 in x 29 1/2
in - Short floor support dimensions: 7/8 in x 1 1/2 in x 7 1/4
in - Spacer quantity: 24
- 1 1/2 in black self-drilling stainless steel screw quantity:
8 - 5/8 in black self-drilling stainless steel screw quantity:
18 - Corner post cap quantity: 2
The product comes with assembly instructions and a QR code to
access an assembly video. In case of missing or damaged parts,
customers can visit the EncloScreens website or contact customer
service.
Product Usage Instructions
Before assembling the Florence Screen Kit, customers should
ensure that they have all the necessary parts and tools. They
should also have a non-abrasive surface to assemble components on
and an area of approximately 5’x 8′ for unobstructed
assembling.
Customers should follow the assembly instructions carefully,
starting with laying out all the materials and identifying each
part. They should then proceed to assemble the boards, starting
with laying down one Long Board (A) with the cut grooves facing up.
They should place one Long Floor Support (D) at the bottom of the
long board, ensuring it rests in the middle of the board. They
should then drive four 1 1/2 in black self-drilling stainless steel
screws (L) into the predrilled holes in the long floor support.
Customers should continue following the assembly instructions,
assembling each component carefully and ensuring that they do not
use excessive force. If they experience any difficulties during
assembly or installation, they should contact EncloScreens customer
service for assistance.
Once assembled, the Florence Screen Kit with Planter Box can be
used as a decorative screen with a built-in planter box for plants
or flowers. It is recommended that customers refer to the product
user manual for maintenance instructions and tips on how to best
use the product.
www.encloscreens.com
Florence Screen Kit
W/ Planter Box
45 min
Approximate assembly time for 1 screen
Scan the QR code for an assembly video
ASSEMBLY INSTRUCTIONS
EC18006 (CEDAR COLOR) EC18007 (ASH COLOR)
VER. 022822
EC18006 / EC18007
ASSEMBLY INSTRUCTIONS
GENERAL INFORMATION
MISSING OR DAMAGED PARTS?
IMPORTANT
j Check the inside of the larger pieces in your box for other materials packed inside.
j When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching.
j We recommend an area approximately 5’x 8′ for unobstructed assembling.
j You should not need to use excessive force when assembling components.
VISIT OUR WEBSITE FIRST, SO WE CAN HELP YOU RIGHT AWAY! Although great care has been taken to ensure proper packaging and handling of this product, occasionally problems occur. If you discover any missing, damaged, or defective parts, please visit our website to order replacement parts. If you experience any further trouble with your product, please contact our customer service department.
parts.nychbrands.com [email protected] 704-892-5222 / 877-234-6196
Customer service agents are available to take calls weekdays from 9am-5pm EST. If you call outside of business hours, please leave a voicemail.
To help you quickly and accurately, please have reference item number EC18006/EC18007 and the specific part name which can be found on page 4. It is helpful if you can provide the batch lot which is a stamped number on the end of the box.
NEED ASSEMBLY HELP?
If you are having problems with the assembly or installation of this product, we are happy to assist you with the process, so please give us a call at 704-892-5222 / 877-234-6169
NEED TO RETURN?
If for some reason you need to return this product, please allow us to help resolve your issues first. If you still decide to return the product, you will need to initiate the return from the company you originally purchased from.
2
www.encloscreens.com
ASSEMBLY INSTRUCTIONS
EC18006 / EC18007
Detailed Product Dimensions & Specifications
46 in 44 in
9 1/2 in 7 31/4 in
46 in 42 1/2 in
3/4 in
44 in
42 3/4 in
11 in
www.encloscreens.com
3
EC18006 / EC18007
STEP 1: LAY OUT MATERIALS
A
B
ASSEMBLY INSTRUCTIONS
I
Long Board (2) 7/8″ x 11″ x 44″
C
Floor Board (1) 7/8″ x 7 1/4″ x 44″
E
Thin Horizontal Slat (8) 7/8″ x 1 1/2″ x 44″
G
Top view
Right Post (1) 1 3/4″ x 1 3/4″ x 44″
Short Board (2) 7/8″ x 11″ x 7 1/4″
D
Long Floor Support (2) 7/8″ x 1 1/2″ x 29 1/2″
F
Wide Horizontal Slat (4) 7/8″ x 3″ x 44″
H
Top view
Left Post (1) 1 3/4″ x 1 3/4″ x 44″
Spacer (24) J
Short Floor Support (3) 7/8″ x 1 1/2″ x 7 1/4″ K
Short Post (2) 1 3/4″ x 1 3/4″ x 11″ L
1 1/2″ Black Self-Drilling Stainless Steel Screw (8) M
5/8″ Black Self-Drilling Stainless Steel Screw (18) N
Corner Post Cap (2)
4
www.encloscreens.com
ASSEMBLY INSTRUCTIONS
EC18006 / EC18007
STEP 2: ASSEMBLING BOARDS
STEP 2.1
1. Lay down (1) Long Board (A) so that the cut grooves face up as shown.
2. Place (1) Long Floor Support (D) at the bottom of the long board.
3. Position the long floor support so it rests in the middle of the long board.
STEP 2.2
1. Drive (4) 11/2″ Black Self-Drilling Stainless Steel Screws (L) into the predrilled holes in the long floor support.
2. Repeat these steps for the second long board.
1
1
A
2
Ensure floor support is
placed on the grooved
edge face of the board.
Ensure that the bottom of the long board and long floor support are flush
L
D
2 3
7 ¼ in
7 ¼ in
www.encloscreens.com
5
EC18006 / EC18007
STEP 3: ASSEMBLING THE PLANTER BOX
STEP 3.1 b Orient (2) Short Posts (K) as
shown, with two post channels facing each other, and two channels facing front.
K
Top View
Tabs
Tabs
ASSEMBLY INSTRUCTIONS
1. (E)
STEP 3.2 1. Slide (1) long board into the post channels, ensuring that the tabs on the posts align with the grooves in the board. 2. Drive (4) 5/8″ black self-drilling stainless steel screws (M) into the predrilled holes in the posts, securing the long board. Note: Ensure the bottom of the board is flush to the bottom of the posts.
1
Preview
2
Note: Ensure tabs on posts and notches on
boards align.
6
www.encloscreens.com
ASSEMBLY INSTRUCTIONS
STEP 3.3
1. Slide (2) Short Boards (B) into the short post channels, ensuring that the board bottoms are flush.
2. Drive (4) 5/8″ black self-drilling stainless steel screws into the pre-drilled holes in the sides of the short posts.
1
2
EC18006 / EC18007 Preview
Ensure that boards are flush
STEP 4: INSTALLING REAR POSTS
STEP 4.1
1. Slide (1) Right Post (G) and (1) Left Post (H) over the short boards so that the partially covered channel on each post faces the front.
2. Drive (4) 5/8″ black self-drilling stainless steel screws into the pre-drilled holes in the sides of the posts.
Top View
Preview
H
G
www.encloscreens.com
7
EC18006 / EC18007
ASSEMBLY INSTRUCTIONS
STEP 5: COMPLETING PLANTER BOX
STEP 5.1
1. Slide the second long board into the post channels. Ensure that this board rests flush with the other boards.
2. Drive (4) 5/8″ black selfdrilling stainless steel screws into the predrilled holes in the posts.
Preview
STEP 5.2
1. Fit (3) Short Floor Supports (J) so that the notches fit over the inner walls of the long floor supports as shown.
2. Place (1) Floor Board (C) into the planter box, so it rests on the floor supports.
Preview
Note: For best plant growth, it is reccomended to drill (2) 3/4″ diameter drainage holes in the floor board roughly 12″ apart.
1
1
2
8
J
Align
2
Ensure that boards are flush
C www.encloscreens.com
ASSEMBLY INSTRUCTIONS
STEP 6: ASSEMBLE THE SCREEN
STEP 6.1
1. Insert (1) Spacer (I) into both the left and right post channel in the orientation shown below. This will create even spacing between the horizontal slats.
2. Slide (1) Thin Horizontal Slat (E) into the post channels.
1
I
Orient as shown
EC18006 / EC18007 Preview
2 E
www.encloscreens.com
9
EC18006 / EC18007
ASSEMBLY INSTRUCTIONS
STEP 6.2
1. Slide (7) additional thin horizontal slats, (4) Wide Horizontal Slats (F) and (11) aluminum spacers into the post channels in the pattern shown below. Spacers should be inserted between each horizontal slat.
2. Drive (2) 5/8″ black self-drilling stainless steel screws into the pre-drilled holes in the posts, securing the top horizontal slat.
Preview
1
2
F E E
F E E
F E E
F E
10
www.encloscreens.com
ASSEMBLY INSTRUCTIONS
STEP 7: INSTALL POST CAPS
STEP 6.1 b Insert the (2) Corner Post Caps (N) into the holes
in the top of the posts to finish the assembly.
EC18006 / EC18007
N
www.encloscreens.com
11
ASSEMBLY INSTRUCTIONS
EC18006 (CEDAR COLOR) EC18007 (ASH COLOR)
VER. 022822
www.encloscreens.com
[email protected] 704-892-5222 877-234-6196
6935 Reames Rd. Ste. K. Charlotte, NC 28216
