Hoto Qwsdt002 Flashlight User Manual (+ PDF)

Thank you for using HOTO FLASHLIGHT DUO. This product has a
tactical head, mode switching head, battery indicator, ON/OFF
button, sidelight, Type-C charging port, magnetic base, and
hook.

Tactical Head

The tactical head is used for long-distance illumination.

Mode Switching Head

The mode switching head is used to switch between the flashlight
mode, work light mode, and mood light mode. Rotate the head to
align the mode sign on the head with the indicator on the
casing.

Battery Indicator

The battery indicator shows the battery status when powered ON
and when connected to the charging cable.

ON/OFF Button

The ON/OFF button is used to turn ON/OFF the flashlight and
switch between different modes. In any of the modes, pressing and
holding ON/OFF for three seconds turns on a strobe light, following
short presses will turn on the SOS mode; a third press turns off
the flashlight.

Sidelight

The sidelight has four switchable light effects and is mainly
used as work lighting and emergency warning. In mood light mode, it
is used to create ambience.

Type-C Charging Port

The Type-C charging port is used to charge the product. When the
product is being charged, only low brightness is available for the
flashlight while the sidelight functions normally.

Magnetic Base

The magnetic base allows the whole product to attach to any
magnetic surface composed of iron or nickel.

Hook

The hook is used to hang the product on any place which fits in
the hook.

How to Use

This product has three modes: flashlight mode, work light mode,
and mood light mode. Follow the instructions below to use the
product:

Mode Switching Head

Rotate the mode switching head to switch between different
modes. There are three switchable modes: The flashlight mode, the
work light mode, and the mood light mode.

Flashlight Mode

Short pressing the ON/OFF button switches modes from low
brightness to medium brightness to high brightness and then to
power off.

Work Light Mode

Short pressing the ON/OFF button switches modes from low
brightness to high brightness to red flashing light to yellow
flashing light and then to power off.

Mood Light Mode

Short pressing the ON/OFF button switches modes from warm light
to breathing warm light to campfire to colorful light and then to
power off.

Battery Indicator Status

The battery indicator shows different colors for different
battery statuses. Flashing red light indicates 0-10%, red light
indicates 10%-30%, orange light indicates 30%-60%, and green light
indicates 60%-100%. When connected to the charging cable, charging
is indicated by a breathing red light, and charged is indicated by
a green light. In mood light mode, the indicator would turn off in
5 seconds if battery status is between 10%-100%.

Warning

Follow the instructions in this User Guide to correctly use the
tool. Do not disassemble this product. Only authorized repairmen
are allowed to repair this product.

View Fullscreen

01 Product Overview
Read this manual carefully before use, and retain it for future reference. Thank you for using HOTO FLASHLIGHT DUO.

1 Tactical head

2 Mode switching head

3 Battery indicator

4 ON/OFF

5 Sidelight

6 Type-C charging port

7 Magnetic base

8 Hook

02 How to Use
This product has three modes. Please rotate the mode switching head to switch the mode.
Flashlight mode : In this mode, the flashlight is on with three switchable brightness levels. This mode is mainly used for long-distance illumination. Work light mode : In this mode, the sidelight is on with four switchable light effects. This mode is mainly used as work lighting and emergency warning.
Mood light mode : In this mode, the sidelight is on with four switchable light effects. This mode is mainly used for create ambience.
Mode switching head
Rotate the head to align the mode sign on the head with the indicator on the casing. There are three switchable modes: The flashlight mode, the work light mode, and the mood light mode.
If you rotate the mode switching head to any mode in the “ON” status, the first gear of the corresponding mode is turned on: 1. Flashlight mode: Low white light 2. Work light mode: Low white light 3. Mood light mode: Warm light 3. Sidelight ambient mode: Continuous warm light
If you rotate the mode switching head to any mode in the “OFF” status, the flashlight remains off.
ON/OFF
In the flashlight mode: Short pressing the “ON/OFF” button switches modes from: Low brightnessMedium brightnessHigh brightnessPower Off

In the work light mode: Short pressing the “ON/OFF” button switches modes from: Low brightnessHigh brightnessRed flashing lightYellow flashing lightPower Off In the mood light mode: Short pressing the “ON/OFF” button switches modes from: Warm lightBreathing warm lightCampfireColorful light Power Off In any of the modes: Pressing and holding “ON/OFF” for three seconds turns on a strobe light, following short presses will turn on the “SOS” mode; a third press turns off the flashlight.
Charging
When the product is being charged: flashlight: Only low brightness is available; sidelight: Functions normally.
Plug the charging cable into the Type-C charging port to charge the product.
Note: This product is equipped with a Type-C charging cable.
Battery indicator status
When powered ON: Flashing red light: 0-10% Red light: 10%-30% Orange light: 30%-60% Green light: 60%-100%
When connected to the charging cable: Charging: Breathing red light Charged: Green light
In mood light mode, the indicator would turn off in 5 seconds if battery status between 10%-100%

Magnetic base The magnetic base allows the whole product to attach to any magnetic surface composed of iron or nickel.
Hook Pull out and rotate the hook, then hang on any place which fit in the hook. Rotate the hook back to the slot.

Band
When the band is wrapped around a cylindrical object such as the tarp stand, the flashlight can be attached to the object through its built-in magnet.
When the band is not used, it can be wrapped around the product for storage.

In use 14

Stored

03 Warning
Safety precautions
Proper use Please follow the instructions in this User Guide to correctly use the tool. Repair services Do not disassemble this product. In order to avoid safety hazards, only authorized repairmen are allowed to repair this product.
Charging instructions 1. This product can only be charged with a charger that meets its charging parameters. 2. If the battery indicator does not work properly during charging because this product has not been used for a long period of time, please charge it for 30 minutes for observation.
Precautions 1. This product can emit a strong light, please avoid directing the light at people’s or animals’ eyes and optical lenses; 2. Children are not allowed to use this product alone; 3. In order to reduce electric shock risks, do not place this product in water or other liquids; 4. Do not place or store this product in places where it may fall into a bathtub or sink; 5. In order to reduce burn risks, do not touch the head as its temperature may be high when the strobe lighting mode is turned on for a long time.

Warnings
1. Please charge this product with a charger that meets its charging parameters. Other types of chargers and accessories may violate the warranty and be dangerous. 2. When the high brightness mode is turned on for 15 minutes, the temperature of this product may rise by about 20°C. Therefore, users who are sensitive to temperature should take heat insulation precautions. (After 25 minutes, the temperature will gradually drop.) 3. If the detected battery temperature reaches 45°C, the charging protection function will be automatically triggered, and the charging will be discontinued. The recommended ambient temperature for charging is 0°C-30°C.
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the installer or local authorities for more information about the location as well as terms and conditions of such collection points.
We Shanghai HOTO Technology Co., Ltd., hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and amendments.

Federal Communications Commission Supplier’s Declaration of Conformity
This supplier’s declaration of conformity is hereby for Product: HOTO FLASHLIGHT DUO Model Number(s): QWSDT002 Brand/Trade: HOTO
We declare that the above mentioned device has been tested and found in compliance with CFR 47 Part 15 Regulation.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
Representative of Responsible Party for SDoC

Company: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No.50 Moganshan Road, Shanghai, China Country: China Telephone No.: 400-021-8696

Troubleshooting

Issues
The battery indicator shows a continuous red light when pressing the main switch.

Possible Causes
Low lithium battery power

Solutions Charging

The battery indicator shows no light while charging

1. The USB cable is not plugged in properly, or the charging cable is not the designated one; 2. The ambient temperature for charging is below 0°C or above 45°C

1. Use the designated charging cable and the 5V power adapter; 2. Charge this product in the 0-45°C environment

Automatic mode switching during use

There is strong magnetic Do not use the

interference near the mode product near a

switching ring

magnet or in a

strong magnetic

environment

04 Specifications

Model: QWSDT002 Item Dimensions: 35×35.9×197 mm Net Weight: Approx. 194 g Input: 5 V 2 A

Battery Type: Lithium-ion battery Battery Capacity: 3200 mAh Rated Voltage: 3.6 V Charging Time: Approx. 150 min

Flashlight parameters

Low

Medium High

Strobe SOS

brightness brightness brightness light

Brightness 50LM levels

300LM

1000LM 1000LM 30LM

Battery life 30H

65H

Distance 40M reached

120M

210M

210M 20M

Work light parameters
Low brightness
Brightness 30LM levels

High brightness
200LM

Flashing red light
/

Battery life 30H

48H

Distance 3M reached

10M

Flashing yellow light /
36H /

Mood light parameters

Warm light Breathing Campfire Colorful light

Brightness 120LM

levels

Battery life 10H

24H

12H

Distance 8M

reached

The light source of this product is not replaceable. When its lifespan comes to an end, please replace this product.

Manufacturer: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No. 50 Moganshan Rd, Putuo District,
Shanghai, PRC, 200060.
DECLARATION OF CONFORMITY
EU Declaration of Conformity We
Shanghai HOTO Technology Co., Ltd. Declare that the product:
HOTO FLASHLIGHT DUO / QWSDT002 Complies with the essential health and safety requirements of the
following directives: 2014/35/EU The Low Voltage Directive References to the following harmonized standard were made:
EN 60598-1:2008 EN 60598-2-4:2018 2014/30/EU Electromagnetic Compatibility directive References to the following harmonized standard were made:
EN 55015:2019 EN 61547: 2009 EN 62471:2008 2011/65/EU+ (EU) 2015/863 Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Authorised signatory and technical file holder: Shanghai HOTO Technology Co., Ltd. Building 45, No.50 Moganshan Road, Shanghai, China
