HARPER НВ-519 Bluetooth Stereo Headphones with Microphone
Thank you for choosing Harper products. Before starting use, read the operating instructions and save them in case of questions about the maintenance of the device.
PRECAUTIONARY MEASURES
- Do not disassemble device by yourselves. It may lead to malfunction of device.
- In case of any malfunction, please contact authorized service center.
- Do not lead device and accessories unattended. Please keep them out of reach of children and pets. Small parts can cause suffocation.
- The device is supposed for usage in normal climate conditions. Extreme climate conditions (temperature below OOC and above 45″C, too high level ol humidity) can cause malfunction of device and wreck electronic components of device.
- Protect device from water, do not touch it with wet hands.
Information about restrictions on the use of technical equipment, taking into account its purpose for work in residential, commercial or industrial areas.
The equipment is designed to work in residential and commercial areas, public places, industrial areas with small and medium power consumption, without exposure to harmful and dangerous production factors. The equipment is intended for operation without the constant presence of maintenance personnel.
REQUIREMENTS ТО TRANSPORTATION
Transportation of equipment should Ье carried out in the original packaging in covered vehicles Ьу any means of transport.
APPOINTMENT
These headphones are designed for moblle devices with Bluetooth functionality.
Тhеу are designed for wireless transmission of audio data: talking оп lhe phone, listening to music files.
ITEMS INCLUDED
- 1 х Bluetooth stereo headset НВ-519
- 1 х Туре-С charging саЫе
- 1 х User’s manual
- 1 х Guarantee сагd
- 2 х Pair of silicone ear pads
OVERVIEW
PAIRING
1. Ensure to give the earphones a full charge before use.
2. lake out both earpieces (lett and right), the LED on both earpieces will flash blue and red alternatively. They will automatically connect each other in around 10 seconds.
3. When the earpieces are connected, one side of the earpiece’s LED will flash blue.
4. Now you can start pairing with your device.
5. Switch on Bluetooth function on your device and find “HB-519” for pairing. The LED indication starts to flash blue when the earphones pair up with the device successfully.
OPERATION
| Function | Buttons |
| Switch on | UR button: long press 3 sec |
| Switch off | UR button: long press 6 sec |
| Play/ pause | UR button: short press |
| Volume up | R: twice press |
| Volume down | L: twice press |
| Next song | R: triple press |
| Previous song | L: triple press |
| Siri / google assistant | UR button: long press 3 sec |
| Accept a call | UR button: short press |
| End a call | UR button: short press |
| Reject a call | UR button: long press 2 sec |
LED INDICATION
| Function | Charging case | Buttons |
| Earpiece – ON | NIA | Red Blue LED light up for around 1 second |
| Earpiece – OFF | NIA | Red Blue LED light up for around 1 second |
| Pairing left and right earpiece | NIA | Both earpieces will flash blue and red LED alternatively |
| Paired left and right earpieces | NIA | One earpiece will flashes blue |
| Pairing to music device | NIA | Blue and Red LED flash alternatively |
| Paired to music device | NIA | Blue LED flashes every 5 seconds |
| Earpiece charging | Blue LED light up | Red LED light up |
| Earpiece charging complete | Blue LED off | Red LED off |
| Earpiece – low battery | NIA | Red LEO flashes |
| Charging case charging | Red LED light up | NIA |
| Charging case charging complete | Red LED off | NIA |
| Charging case low battery | Blue LED flashes | NIA |
REMARKS
- lake out the earpieces from the charging box and it will automatically switch on and automatically start pairing.
- Put the earpiece into the charging box and it will automatically switch off and automatically start charging.
- The earpiece will automatically power off if idle for around 5· 1 O minutes or if the battery capacity is too slow.
- If malfunction occur due to electrostatic discharge, unplug the charging cable and connect it again.
PRODUCT PARAMETERS
- Bluetooth version: 5.1
- Frequency response: 20Hz – 20 kHz
- Earphones charging time: 1 h
- Case charging time: up to 2h
- Work time: up to Sh
- Case battery capacity: 300mAh
- Earphones battery capacity: 2•3smAh
- Plug for charging: Type-C
- Sensitivity: 96dB±10%
- Impedance: 16 Ohm
- The maximum work range: 10m
DISPOSAL INFORMATION
This device is designed and made of high quality materials and components, which can be recycled and reused. The symbol means that electrical and electron.
Notes
In accordance with constant improvement, specifications and design are subject to change without notice. This product does not contain precious metals.
HARPER
Bluetooth stereo headset with microphone
HB-519
Information about certification
The products passed all the assessment procedures established in the technical regulations of the Customs Union and the Eurasian Eoonomic Union
Information about product certification, certificate number and date, validity period you can find on the website www.harper.ru or by calling technical support 8-800-600-7107
Production date is indicated on the gitt-box
- Life duration of product: 24 months
- Warranty period: 12 months
warranty service Is provided on the base of warranty card that goes together with the product. Warranty card and User manual are Integral parts of the product. For additional information about the product and authorized service centers you may find at www.harper.ru or by telephone S.800-600-7107.
Manufacturer: Harper International Trading Limited 1 SF, Radio City 505 Hennessy Road, Causeway Bay, Hong Kong
Made in China
Importer/claims organization: LLC «Progress-Ptyus», App.11, floor 2, Build.SO, k.1 , Udattsova Str., Moscow, Russia, 119607, tel.: +74951330210, email: [email protected]
