Endeavour Et1284 Oil Funnel Instruction Manual

ET1284 Oil Funnel

Product Information

Features

Different engines have different configurations below the oil
filler neck. Some engines might have parts that create a baffle,
making it difficult to stabilize conventional funnels on the oil
filler neck. This funnel solves these problems by providing a
seamless connection that prevents unsafe oil spills on the engine
or floor.

Specifications

Instructions

1. CAUTION: Remove the original oil cap on the
   engine.
2. Connect the oil funnel to the oil filler neck.
3. Ensure that the funnel is securely connected to the
   engine.
4. Pour engine oil into the funnel.
5. Disconnect the oil funnel from the oil filler neck.
6. Clean the residual oil inside the funnel and store it in a dry
   and well-ventilated place.

Applications

The table below provides a list of compatible car models and
their corresponding years for reference. Please note that there may
be more vehicle applications possible, and some car models may have
multiple suitable adapters due to variations in body style, engine
size/capacity, and engine numbers.

ET1284 OIL FUNNEL FOR FORD AND MA DA
1. FEATURES 2. SPECIFICATIONS 3. INSTRUCTIONS 4. APPLICATIONS

1. FEATURES
Funnel can be directly connected to oil filler necks, eliminating unsafe oil spills Engine oil bottles can be put up side down on funnel ­ hands-free and one-person operation Large oil passage allows oil to flow down more rapidly Lower transparent chamber shows oil flows down to engine

Different engines have different configurations below oil filler neck. Some engines might have parts that create a baffle (as the images shown on the right), and this can make conventional funnels hard to stabilize on oil filler neck, or one hand is needed to hold against the funnel when refilling engine oil.
However, this funnel is to solve these problems. A seamless connection can be created to prevent unsafe oil spills on engine or floor.

Oil Filler Neck Without Baffle One hand must
hold against funnel

Oil Filler Neck With Baffle Oil may spill on engine o oo

2. SPECIFICATIONS
1
2 A C
3B 4 5

No Description 1 Funnel opening 2 Overall height 3 Oil filler depth 4 Oil passage 5 Funnel connector

Specifications Ø125mm / Ø4.9″ 219.7mm / 8.6″ 23.7mm / 15/16″ Ø22.5mm / Ø0.88″ Ø33.5mm / 1-5/16″

A Transparent chamber shows oil flow B Large oil passage allows oil flow fast C Durable NBR seal

3. INSTRUCTIONS

CAUTION

· Always read the instructions carefully before using the tool · Ensure the working area has adequate lighting · Keep children and unauthorized persons away from the working area · Keep working area clean and tidy, dry and free from unrelated materials · DO NOT allow untrained persons to use this tool kit · Always wear eye protection that meets OSHA and ANSI Z87.1 standards · Always wear gloves when working with the tool · Always wear ear protection · Disposal: Customers should follow local regulations to handle used/waste parts

1 Remove original oil cap on engine. 2 Connect oil funnel to oil filler neck. 3 Make sure the funnel is securely connected on the engine 4 Pour engine oil (as the image on right). 5 Disconnect oil funnel from oil filler neck. 6 Clean the residual oil inside the funnel and store the funnel
in a dry and well-ventilated place.

4. APPLICATIONS
The application below is for reference only. More vehicle applications are possible. Some car models may have multiple suitable adapters due to variations in body style, engine size/capacity, and engine numbers.

Make Citroen Fiat Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford Ford

Model Relay Ducato Bronco Sport C-Max C-Max C-Max EcoSport Ecosport Edge Edge Escape Expedition Explorer F-150 Fiesta Fiesta Fiesta Focus Focus Fusion Fusion Galaxy KA KA Mondeo Mondeo Mondeo Mustang Puma Ranger Ranger S-Max

Year 2006-2023 2006-2023 2021-2023 2007-2010 2010-2020 2013-2017 2004-2012 2012-2023 2012-2018 2020-2023 2005-2023 2020-2020 2020-2020 2020-2020 2001-2010 2008-2017 2008-2023 2004-2012 2010-2023 2002-2012 2006-2019 2006-2015 1996-2008 2008-2016 2000-2007 2007-2015 2012-2023 2015-2022 1997-2002 2004-2011 2011-2023 2006-2014

Remarks 2.2 HDI 100 Multijet 2.2 D 1.5L 1.6, 1.8, 2.0 1.0, 1.5 EcoBoost, 1.6 LPG, 1.6 Ti 2.0L 2.0L 1.0 EcoBoost, 1.5 Ti, 2.0L 2.0L 2.0L, 2.7L 1.5, 1.6, 2.0, 2.3, 2.5 3.5L 2.3L, 3.0L 2.7L, 3.5L, 5.0L 1.25, 1.3, 1.4, 1.6 1.25, 1.4 1.0, 1.6 Ti 1.4, 1.6, 1.8, 2.0, 2.5 1.0, 1.5 EcoBoost, 1.6 LPG, 1.6 Ti 1.25, 1.4, 1.6 1.5, 1.6, 2.0, 2.3, 2.5 2.0, 2.3 1.3i, 1.6i 1.2 1.8 16V, 2.0 16V 1.6 Ti, 2.0, 2.3 1.0 EcoBoost 2.3L 1.6 16V 2.3L 2.2 TDCi, 3.2 TDCi 4×4 2.0, 2.3

Make Ford Ford Ford Lincoln Lincoln Mazda Mazda Mazda Mazda Mazda Mazda Mazda Mazda Mazda Mazda Mazda Mazda Peugeot

Model Taurus Transit Transit MKC MKZ 3 5 6 B2300 CX-3 CX-5 CX-7 CX-9 MX-5 MX-5 Miata RX-8 Tribute Boxer

Year 2013-2017 2000-2014 2013-2020 2015-2019 2013-2020 2004-2022 2006-2017 2004-2021 2004-2009 2016-2019 2013-2022 2009-2012 2016-2022 2006-2022 2006-2022 2009-2010 2005-2011 2006-2023

Remarks 2.0L 2.2 TDCi, 2.3, 2.4 TDCi, 3.2 TDCi 2.2 TDCi 2.0L, 2.3L 2.0L 2.0, 2.3, 2.5 2.3L, 2.5L 2.3L, 2.5L 2.3L 2.0L 2.0L, 2.5L 2.3L, 2.5L 2.5L 2.0L 2.0L 1.3L 2.3L, 2.5L 2.2 HDI
