Vevor 754194652858 Water Trampoline Instructions

754194652858 Water Trampoline

Water Trampoline

The water trampoline is an inflatable water toy designed for
healthy children or adults aged 5-45. It comes with a slide (some
models have no slide) and accessories for easy inflation. Please
read the following instructions carefully before using the
product.

Instructions:

  1. Open the product package, take out the water trampoline and
    accessories, and put them on the ground without impurities and
    sharp objects. Spread out the water trampoline and slide.
  2. Find the air intake valve of trampoline and slide, unscrew the
    outer cover of the valve, insert the air outlet pipe of proprietary
    electric inflation pump into the product air intake valve, and
    connect the power supply to inflate the trampoline and slide
    respectively.
  3. Users need to climb up the water trampoline along the
    staircase, and only one person can use the escalator at a time. The
    slide must be drenched water or added foam to increase
    lubricity.
  4. Users must take off their shoes when playing, it is forbidden
    to use this product with sharp objects or wear glasses to prevent
    injury caused by falling.
  5. Use age: healthy children or adults aged 5-45. Minors must be
    accompanied by adults. It is forbidden to use this product for
    people with skin diseases, cardiovascular and cerebrovascular
    diseases, pregnant women and people with bone diseases, and people
    with a single weight of more than 80kg.
  6. It is recommended that the water depth for the use of water
    trampoline should not be less than 1m. If it is used in water areas
    exceeding the safe depth of human body, professional life-saving
    personnel or operators with good water properties must be present
    for care. When using this product in deep water, users must wear
    life jackets (provided by the customer).
  7. If it is used in open water, heavy objects (provided by the
    customer) must be tied at the handles in both directions on the
    side of the trampoline airbag to fall to the bottom of the water to
    prevent the trampoline from floating away with the current.
  8. The water trampoline and slide shall not be used when the air
    pressure is insufficient. If the air bag is weak, it must be
    handled in time and replenished before continuing to use.

Thank you for using this product. If you have any other
questions in use, please consult your customer service
personnel!

Water Trampoline Instructions
1. Open the product package, take out the water trampoline and accessories, and put them on the ground without impurities and sharp objects.Spread out the water trampoline and slide (some models have no slide).
2. Find the air intake valve of trampoline and slide, unscrew the outer cover of the valve, insert the air outlet pipe of proprietary electric inflation pump into the product air intake valve, and connect the power supply to inflate the trampoline and slide respectively.
3. After inflation, screw on the outer cover of the valve, find the position of the metal D-ring at the upper part of the trampoline, and fasten the escalator and slide respectively. Use ropes on both sides of the escalator to tie the left and right D-rings respectively; the connection between the slide and the trampoline is D-ring to D-ring. The specific operation is: the customer provides two ropes to connect the D-ring at the lower part of the slide and the D-ring at the upper part of the trampoline. This product can only be used after completing the above operations and confirming that there is no air leakage.
4. Users need to climb up the water trampoline along the staircase, and only one person can use the escalator at a time. The slide must be drenched water or added foam to increase lubricity.
5. Users must take off their shoes when playing,it is forbidden to use this product with sharp objects or wear glasses to prevent injury caused by falling.
6. Use age: healthy children or adults aged 5-45. Minors must be accompanied by adults. It is forbidden to use this product for people with skin diseases, cardiovascular and cerebrovascular diseases, pregnant women and people with bone diseases, and people with a single weight of more than 80kg.
7. It is recommended that the water depth for the use of water trampoline should not be less than 1m. If it is used in water areas exceeding the safe depth of human body, professional life-saving personnel or operators with good water properties must be present for care. When using this product in deep water, users must wear life jackets (provided by the customer).

8. If it is used in open water, heavy objects (provided by the customer) must be tied at the handles in both directions on the side of the trampoline airbag to fall to the bottom of the water to prevent the trampoline from floating away with the current.
9. The water trampoline and slide shall not be used when the air pressure is insufficient. If the air bag is weak, it must be handled in time and replenished before continuing to use.
10. Repair method: if your toy is damaged, scratched, cracked and other air leakage, please repair it in time before use. Clean up the impurities and sludge at the air leakage position, apply PU resin glue (provided by the customer), cut a piece of material slightly larger than the air leakage position (in your product package), and also apply glue. When the applied glue is almost dry, paste it, knead it, press and scrape it flat. It is recommended to scrape the repair piece while heating with a hot air machine (provided by the customer) to achieve a more firm effect of hot adhesion.
11. Thank you for using this product. If you have any other questions in use, please consult your customer service personnel!
