Eridanus Eri-wb-101l-a Turner Bathroom Sink Installation Guide

ERI-WB-101L-A Turner Bathroom Sink

Product Information: Wall Mount Bathroom Sink

• Product Name: Wall Mount Bathroom Sink
• Manufacturer: Eridanus
• Included Hardware:
  1. Hanger Bolts (10mm) x2
  2. Washer x2
  3. Nuts x2
  4. Anchor x2
  5. Insulation Sleeve x2
• Recommended Usage: Solid walls only (not suitable for
  plasterboard or stud walls)
• Installation Difficulty: Moderate to High (professional and
  experienced installers recommended)

Product Usage Instructions: Wall Mount Bathroom Sink
Installation

1. Read the installation instructions carefully and ensure
   compliance with local plumbing and building codes.
2. Shut off the hot and cold water supplies. Inspect the drain and
   supply tubing, replacing if necessary.
3. Unpack the new sink and inspect it for damage. Keep the sink in
   its protective carton until installation begins.
4. If there are any specific instructions from contractors
   involved in the project, make sure to communicate and coordinate
   requirements.
5. For safety and proper installation, it is recommended to have
   at least two people install the sink.
6. Note that product design revisions may occur without
   notice.
7. As no template is provided for this model, follow the
   installation steps below:

Installation Steps:

1. Measure the distance between the center of each mounting hole
   on the back of the sink. Draw two marks on the wall at the desired
   mounting location, ensuring they are level with the floor.
2. Drill two holes using a 14mm masonry drill bit to a depth of
   75mm. Insert an anchor into each hole and screw in the hanger
   bolts.
3. Attach the drain assembly and faucet to the sink according to
   the manufacturer’s instructions.
4. Carefully place the sink against the wall, aligning the hanger
   bolts with the holes in the rear of the basin. Secure the sink
   using insulation sleeves, washers, and nuts respectively. Be
   careful not to over-tighten, as it may damage the ceramic
   sink.
5. Apply silicone caulk around the edges of the sink where it
   meets the wall to prevent water seepage. Allow 24 hours for the
   caulk to dry.
6. Attach the P-trap assembly to the sink drain and connect it to
   the plumbing below. Use a wrench to tighten the nuts and check for
   any leaks.

Congratulations! You have successfully installed a wall mount
bathroom sink.

Installation Guide
WALL MOUNT BATHROOM SINK

Installation Guide

Tools and Materials

Safety Glasses

Measureing Tape

Drill

Pencil

Wrench

Level

Silicone Caulk

Included Hardware(1)Hanger Bolts (10mm) x2(2)Washer x2
(3)Nuts x2 (4)Anchor x2 (5)Insulation Sleeve x2
Before You Begin
Read the following instructions carefully before you begin this installation:
1. Observe all local plumbing and building codes.
2. Shut off the hot and cold water supplies. Inspect the drain and supply tubing. Replace if necessary.
3. Unpack the new sink and inspect it for damage. Afterward, put the sink back to its protective carton until the installation begins.
4. In consideration of various installations possible with this sink, procedures other than those described in these instructions may be used.
5. It’s recommended to provide the actual sink to all contractors involved in the project. It’s critical that all contractors maintain communication and coordinate the requirements of the project.
6. It is recommended that the sink installation be performed by professional and experienced installers. For the sake of safety and a damage-free installation, the sink should be installed by at least two people.
7. All information in these instructions is based on the latest product information available at the time of publication. Eridanus reserves the right to make revisions to the design of products without notice.
8. Due to differing demands and purposes for usage possible, a template will not be provided for this model.
01

Installation Guide
Installation Steps
Wall Mount Installation NOTE These fixings are suitable for solid walls only. Plasterboard or stud walls may
require specialist fixings.
Step I. Measure the distance between
the center of each mounting hole on the back of the sink. Draw 2 marks on the wall in the desired mounting location. Ensure that the two marks are level with the floor.
Step II. Drill two holes accordingly using a 14 mm masonry drill bit to a depth of
75 mm. Push the anchor into each hole and screw in the hanger bolts.
Step III. Attach the drain assembly and faucet to the sink according to the
manufacturer’s instructions.
Step IV. Carefully place the sink in position against the wall. Locate the hanger
bolts through the holes in the rear of the basin. Secure the sink with insulation sleeves, washers and nuts respectively.
NOTE DO NOT over-tighten, as this may cause damage to the ceramic sink.
02

Installation Guide
Step V. Apply silicone caulk around the edges of the sink where it meets the wall
to prevent water from seeping behind the sink. Wait for 24 hours for it to dry.
Step VI. Attach the P-trap assembly to the drain on the sink and connect it to the
plumbing below. Install the water supply. Use a wrench to tighten the nuts and ensure there are no leaks.
Congratulations! You have successfully installed a wall mount bathroom sink.
03

Installation Guide
© COPYRIGHT 2023 ERIDANUS
