Product Information
| NO. | DESCRIPTION | SIZE | WEIGHT |
|---|---|---|---|
| 1 | HIDDEN END CAM (UNIVERSAL CLAMP) | A | 0.17 LBS |
Product Usage Instructions
- Slide the C clamp into the rail channel, ensuring it clears the
module frame. The C clamp requires a clearance of 6 inches from the
end of the rail. - Place the module on the rails (module cells not shown for
clarity). - Pull the C clamp towards the rail ends at a 45-degree angle so
that the bonding bolt contacts the module flange edge. - Rotate the handle upwards until the C clamp snaps into the rail
channel.
Module Compatibility and Certifications
The product conforms to STD UL 2703 (2015) requirements and is
compatible with modules that meet the following specifications:
- Frame Compatibility:
- X: 1.2 – 2.2 mm
- Y: 15 – 40 mm
Please refer to the IronRidge Flush, Tilt, or Ground Mount
Manuals for full ratings and a list of compatible modules.
CAMO
1 1.40
.98
.67
4.31
Bonding Pins (Module Frame Bonding)
Bonding Bolt (Rail Bonding)
DETAIL A
A
NO.
DESCRIPTION
1
HIDDEN END CAM (UNIVERSAL CLAMP)
HIDDEN END CAM (UNIVERSAL CLAMP)
SIZE
A
DO NOT SCALE DRAWING
SCALE:1:1
WEIGHT: 0.17 LBS
SHEET 1 OF 1
CAMO-01-MAN REV 1.20
Installation
1
2
Slide C into rail channel far enough to clear the module frame. C requires 6″ of clearance from end of rail.
3
Place module on rails (module cells not shown for clarity).
4
Pull C towards rail ends, at 45 deg angle, so the bonding bolt contacts the module flange edge.
Rotate handle with an upwards motion until C snaps into rail channel
Module Compatibility and Certifications
UL 2703
Conforms to STD UL 2703 (2015) requirements. See IronRidge Flush, Tilt, or Ground Mount Manuals for full ratings and list of compatible modules.
Frame Compatibility: X = 1.2 – 2.2 mm Y = 15 – 40 mm
CAMO-01-MAN REV 1.20
