1165 Computer Mouse Interface
Product Information
Product Name: Computer Mouse Interface
#1165
Manufacturer: Enabling Devices
Technical Support: Call our Technical Service
Department Monday through Friday, 9 a.m. to 5 p.m. (EST) at
1-800-832-8697 or email [email protected]
Address: 50 Broadway Hawthorne, NY 10532
Contact: Tel. 914.747.3070 / Fax 914.747.3480 /
Toll Free 800.832.8697
Website: www.enablingdevices.com
Product Usage Instructions
- Follow the original manufacturer’s instructions for downloading
the installation software and setting up your mouse here.
Please Note: If you do not download the software pack, the Computer
Mouse Interface will use your operating system’s standard mouse
drivers. It will work as a switch access device for mouse clicks
and cursor movements, but you will not be able to assign any
keystrokes to the switch plate or switch inputs. - Linux Users: You do not need to download the software. To make
any changes to the interface, look under your Mouse Preferences in
Linux. - The Computer Mouse Interface requires 2 AAA batteries to
operate (Not included). Use alkaline batteries only (e.g. Duracell
or Energizer brand). Do not use rechargeable batteries or any other
type of batteries because they supply lower voltage and the unit
will not perform properly. Never mix old and new batteries together
or different brands or types together. - Remove the battery cover and screw. Set the On/Off switch
located on the side of the switch to On. - Next, plug the USB dongle into your computer’s USB port. The
mouse should auto detect. Once detected, you should download the
software pack for the full use of features. Once you have your
mouse setup, plug your capability switch (Not included) into the
appropriate jack on the Mouse. - For easier conventional mouse use, we have added both a
removable T-handle and a joystick ball for additional ways to move
the interface. They can be changed by unscrewing the handle as
shown in photo No.1 on the back page of this guide. Please Note: On
the bottom of the Computer Mouse Interface, there is an opening as
pointed to in photo No.2 on the back of this guide. Do not cover or
block this opening, as it is for the optical sensor of the mouse to
detect cursor movement. Doing so will stop the cursor movement on
your computer’s desktop.
Troubleshooting
Problem: The Computer Mouse Interface fails to
operate, or operates incorrectly.
- Action #1: Check the AAA batteries in the
Computer Mouse Interface. The downloadable software monitors the
battery life and alerts you when it needs to be changed. - Action #2: Make sure that you have your mouse
USB Dongle plugged into your computer properly, and your capability
switch is plugged into the mouse all the way. There should be no
gaps in the connection. - Action #3: For additional troubleshooting
help, check the original manufacturer’s instructions.
Care of the Unit
The Computer Mouse Interface can be wiped clean with any
household multi-purpose, non-abrasive cleaner and disinfectant. Do
not use abrasive cleaners, as they will scratch the surface of the
unit. Do not submerge the unit, as it will damage the electrical
components.
Computer Mouse Interface #1165
Photo No.1
Photo No. 2
For Technical Support: Call our Technical Service Department Monday through Friday, 9 a.m. to 5 p.m. (EST)
1-800-832-8697 [email protected]
USER’S GUIDE
50 Broadway Hawthorne, NY 10532 Tel. 914.747.3070 / Fax 914.747.3480 Toll Free 800.832.8697 www.enablingdevices.com
Wireless! Our mouse interface works in two ways: as a conventional mouse for cursor movement or for computer switch access. It connects wirelessly to your computer so you can use either the 5″ diameter built-in switchplate or insert two of your capability switches into the device to mimic mouse clicks or keystrokes. For easier conventional mouse use, we have added both a removable T-handle and a joystick ball for additional ways to move the interface. Free downloadable software available for configuring each button to be any keystroke or mouse-click. PC, MAC and Linux compatible. Requires USB port. Size: 5″Diameter x 1¼”H. Requires 2 AAA Batteries. Weight: ¾ lb.
Operation: 1. Follow the original manufactures instructions for downloading the
installation software and setting up your mouse here: https://www.logitech.com/en-us/software/options.html Please Note: If you do not download the software pack the Computer Mouse Interface will use your operating system’s standard mouse drivers. It will work as a switch access device for mouse clicks and cursor movements, but you will not be able to assign any keystrokes to the switch plate or switch inputs.
2. Linux Users: You do not need to download the software. To make any changes to the interface look under your Mouse Preferences in Linux.
3. The Computer Mouse Interface requires 2 AAA batteries to operate (Not included). Use alkaline batteries only (e.g. Duracell or Energizer brand). Do not use rechargeable batteries or any other type of batteries because they supply lower voltage and the unit will not perform properly. Never mix old and new batteries together or different brands or types together.
4. Gently turn the unit over to face the black battery compartment cover. Carefully remove the small screw from the battery compartment cover using a Phillips head screwdriver, and lift the cover off, it may be necessary to use the end of the screwdriver to lift one edge of the cover. The USB Dongle is stored here for shipping purposes. You will need this later to plug into your computer. Observing proper (+) & (-) battery polarity, install 2 AAA size batteries into the holder. Replace the battery compartment
cover and screw. Set the On/Off switch located on the side of the switch to On.
5. Next plug the USB dongle into your computers USB port. The mouse should auto detect. Once detected you should download the software pack for the full use of features. Once you have your mouse setup, plug your capability switch (Not included) into the appropriate jack on the Mouse.
6. For easier conventional mouse use, we have added both a removable T-handle and a joystick ball for additional ways to move the interface. They can be changed by unscrewing the handle as shown in photo No.1 on the back page of this guide.
Please Note: On the bottom of the Computer Mouse Interface there is an opening as pointed to in photo No.2 on the back of this guide. Do not cover or block this opening, this for the optical sensor of the mouse to detect cursor movement. Doing so will stop the cursor movement on your computer’s desktop.
Troubleshooting: Problem: The Computer Mouse Interface fails to operate, or operates incorrectly.
Action #1: Check the AAA batteries in the Computer Mouse Interface. The downloadable software monitors the battery life, and alerts you when it needs to be changed.
Action #2: Make sure that you have your mouse USB Dongle plugged in to your computer properly, and your capability switch is plugged into the mouse all the way, there should be no gaps in the connection.
Action #3: For additional trouble shooting help check the original manufactures instructions.
Care of the Unit: The Computer Mouse Interface can be wiped clean with any household multi-purpose, non-abrasive cleaner and disinfectant. Do not use abrasive cleaners, as they will scratch the surface of the unit .Do not submerge the unit, as it will damage the electrical components.
