EEC67310L Dishwasher

Product Information: EEC67310L EN Dishwasher

The EEC67310L EN Dishwasher is a high-quality appliance from
Electrolux that has been designed with the user in mind. It is a
stylish and innovative product that brings with it decades of
professional experience. The dishwasher is equipped with various
features such as the Beam-on-Floor, ECOMETER, and Indicators that
make it easy to use and ensure great results every time.

Safety information
Safety instructions
Product description

Product Usage Instructions

1. Safety Information

Before installing and using the appliance, carefully read the
supplied instructions. The manufacturer is not responsible for any
injuries or damages caused by improper use of the product.

2. Safety Instructions

2.1 Installation

Only a qualified person must install this appliance. Refer to
the installation instructions provided in the manual or visit the
Electrolux website for a video tutorial on how to install your 60
cm Dishwasher Sliding Hinge.

2.2 Electrical Connection

Make sure to follow all electrical safety guidelines when
connecting the dishwasher to the power source. There is a risk of
fire and electric shock if not done properly.

2.3 Water Connection

Follow the water connection instructions provided in the manual
to ensure proper installation and avoid any leaks or damages.

2.4 Use

The dishwasher is easy to use and comes with various program
options, such as AUTO Sense program button. Refer to the product
manual for detailed instructions on how to use these programs.

2.5 Service

Always use original spare parts. When contacting our Authorised
Service Centre, ensure that you have the following data available:
Model, PNC, Serial Number. The information can be found on the
rating plate.

2.6 Disposal

Dispose of the dishwasher properly to avoid any risk of injury
or suffocation to children and pets. Follow the disposal
instructions provided in the manual.

3. Product Description

The dishwasher comes with various features such as:

Ceiling spray arm
Upper spray arm
Lower spray arm
Filters
Rating plate
Salt container
Air vent
Rinse aid dispenser
Detergent dispenser
ComfortLift basket
Trigger handle
Lower basket handle
Upper basket
Cutlery drawer
Beam-on-Floor
Control panel with MY TIME selection bar, EXTRAS buttons, AUTO
Sense program button, ECOMETER, and Indicators

3.1 Beam-on-Floor

The Beam-on-Floor is a light that is displayed on the floor
below the appliance door. It is off when the appliance is
deactivated.

4. Control Panel

The control panel comes with various buttons and indicators that
make it easy to use the dishwasher. These include:

On/Off button / Reset button
Delay Start button
MY TIME selection bar
EXTRAS buttons
AUTO Sense program button
ECOMETER
Indicators for Rinse aid and Salt

4.2 ECOMETER

The ECOMETER indicates how the programme selection impacts
energy and water consumption. The more bars are on, the lower the
consumption is. It indicates the most environmentally friendly
programme selection for a normally soiled dishwashing load.

4.3 Indicators

The dishwasher comes with two indicators:

Rinse aid indicator. It is on when the rinse aid dispenser
needs refilling. Refer to Before first use.
Salt indicator. It is on when the salt container needs
refilling. Refer to Before first use.

View Fullscreen

EEC67310L
EN Dishwasher

User Manual

2 www.electrolux.com
CONTENTS
1. SAFETY INFORMATION…………………………………………………………………………2 2. SAFETY INSTRUCTIONS……………………………………………………………………….4 3. PRODUCT DESCRIPTION…………………………………………………………………….. 6 4. CONTROL PANEL………………………………………………………………………………… 7 5. PROGRAMME SELECTION…………………………………………………………………… 8 6. BASIC SETTINGS ………………………………………………………………………………. 10 7. BEFORE FIRST USE…………………………………………………………………………… 14 8. DAILY USE…………………………………………………………………………………………. 15 9. HINTS AND TIPS………………………………………………………………………………… 18 10. CARE AND CLEANING……………………………………………………………………….20 11. TROUBLESHOOTING…………………………………………………………………………24 12. TECHNICAL INFORMATION………………………………………………………………. 28 13. ENVIRONMENTAL CONCERNS…………………………………………………………. 29
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. Welcome to Electrolux. Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support
Register your product for better service: www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance: www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.
Warning / Caution-Safety information General information and tips Environmental information
Subject to change without notice.
1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not

ENGLISH 3
responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety · This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. · Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. · Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. · Do not let children play with the appliance. · Keep detergents away from children. · Keep children and pets away from the appliance when the door is open. · Children shall not carry out cleaning and user maintenance of the appliance without supervision. 1.2 General Safety · This appliance is intended to be used in household and similar applications such as: farm houses; staff kitchen areas in shops, offices
and other working environments; by clients in hotels, motels, bed & breakfast and
other residential type environments. · Do not change the specification of this appliance. · The operating water pressure (minimum and
maximum) must be between 0.5 (0.05) / 10 (1.0) bar (MPa) · Follow the maximum number of 14 place settings.

4 www.electrolux.com

· If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.
· WARNING: Knives and other utensils with sharp points must be loaded in the basket with their points down or placed in a horizontal position.
· Do not leave the appliance with the open door unattended to avoid stepping accidentally onto it.
· Before any maintenance operation, deactivate the appliance and disconnect the mains plug from the socket.
· Do not use high pressure water sprays and/or steam to clean the appliance.
· If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet.
· The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation
WARNING! Only a qualified person must install this appliance.

www.youtube.com/electrolux www.youtube.com/aeg
How to install your 60 cm Dishwasher Sliding Hinge

· Remove all the packaging. · Do not install or use a damaged
appliance. · Do not use the appliance before
installing it in the built-in structure due to safety manner. · Follow the installation instructions supplied with the appliance. · Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear. · Do not install or use the appliance where the temperature is less than 0 °C. · Install the appliance in a safe and suitable place that meets installation requirements.

2.2 Electrical connection
WARNING! Risk of fire and electric shock.
· Warning: this appliance is designed to be installed / connected to a grounding connection in the building.
· Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.
· Always use a correctly installed shockproof socket.
· Do not use multi-plug adapters and extension cables.
· Make sure not to cause damage to the mains plug and to the mains

ENGLISH 5

cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre. · Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation. · Do not pull the mains cable to disconnect the appliance. Always pull the mains plug. · This appliance is fitted with a 13 A mains plug. If it is necessary to change the mains plug fuse, use only a 13 A ASTA (BS 1362) fuse (UK and Ireland only).
2.3 Water connection
· Do not cause damage to the water hoses.
· Before connection to new pipes, pipes not used for a long time, where repair work has been carried out or new devices fitted (water meters, etc.), let the water flow until it is clean and clear.
· Ensure that there are no visible water leaks during and after the first use of the appliance.
· The water inlet hose has a safety valve and a sheath with an inner mains cable.
WARNING! Dangerous voltage. · If the water inlet hose is damaged, immediately close the water tap and disconnect the mains plug from the mains socket. Contact the Authorised Service Centre to replace the water inlet hose.

2.4 Use
· Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
· Dishwasher detergents are dangerous. Follow the safety instructions on the detergent packaging.
· Do not drink and play with the water in the appliance.
· Do not remove the dishes from the appliance until the programme is complete. Some detergent may remain on the dishes.
· Do not store items or apply pressure on the open door of the appliance.
· The appliance can release hot steam if you open the door while a programme operates.
2.5 Service
· To repair the appliance contact the Authorised Service Centre. Use original spare parts only.
· Please note that self-repair or nonprofessional repair can have safety consequences and might void the guarantee.
· The following spare parts will be available for 7 years after the model has been discontinued: motor, circulation and drain pump, heaters and heating elements, including heat pumps, piping and related equipment including hoses, valves, filters and aquastops, structural and interior parts related to door assemblies, printed circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware including reset software. Please note that some of these spare parts are only available to professional repairers, and that not all spare parts are relevant for all models.
· The following spare parts will be available for 10 years after the model has been discontinued: door hinge and seals, other seals, spray arms, drain filters, interior racks and plastic peripherals such as baskets and lids.
· Concerning the lamp(s) inside this product and spare part lamps sold

6 www.electrolux.com
separately: These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, vibration, humidity, or are intended to signal information about the operational status of the appliance. They are not intended to be used in other applications and are not suitable for household room illumination.
3. PRODUCT DESCRIPTION

2.6 Disposal
WARNING! Risk of injury or suffocation.
· Disconnect the appliance from the mains supply.
· Cut off the mains cable and discard it. · Remove the door catch to prevent
children and pets to get closed in the appliance.

14
13 12 11 10

1 Ceiling spray arm 2 Upper spray arm 3 Lower spray arm 4 Filters 5 Rating plate 6 Salt container 7 Air vent 8 Rinse aid dispenser

98 76 5 4
9 Detergent dispenser 10 ComfortLift basket 11 Trigger handle 12 Lower basket handle 13 Upper basket 14 Cutlery drawer

3.1 Beam-on-Floor
The Beam-on-Floor is a light that is displayed on the floor below the appliance door.
· A red light comes on when a programme starts. It remains on for the duration of the programme.

· A green light comes on when the programme is complete.
· The red light flashes when the appliance has a malfunction.
The Beam-on-Floor is off when the appliance is deactivated.

4. CONTROL PANEL

ENGLISH 7

1 On/Off button / Reset button 2 Delay Start button 3 Display 4 MY TIME selection bar
4.1 Display
A

5 EXTRAS buttons 6 AUTO Sense program button
4.2 ECOMETER

The ECOMETER indicates how the programme selection impacts energy and water consumption. The more bars are on, the lower the consumption is.

indicates the most

A. ECOMETER B. Indicators C. Time indicator

environmentally friendly programme selection for a normally soiled dishwashing load.

4.3 Indicators

Indicator

Description
Rinse aid indicator. It is on when the rinse aid dispenser needs refill- ing. Refer to “Before first use”.
Salt indicator. It is on when the salt container needs refilling. Refer to “Before first use”.
Machine Care indicator. It is on when the appliance needs internal cleaning with the Machine Care programme. Refer to “Care and cleaning”.
Drying phase indicator. It is on when you select a programme with the drying phase. It flashes when the drying phase operates. Refer to “Programme selection”.

8 www.electrolux.com

5. PROGRAMME SELECTION

5.1 MY TIME
MY TIME selection bar allows to select a suitable dishwashing cycle based on programme duration.

5.2 AUTO Sense
The AUTO Sense programme automatically adjusts the dishwashing cycle to the type of load.
The appliance senses the degree of soil and the amount of dishes in the baskets. It adjusts the temperature and quantity of water as well as the wash duration.

ABCDE

5.3 EXTRAS
You can adjust the programme selection to your needs by activating EXTRAS.

A. · Quick is the shortest programme (30min) suitable for dishwashing a load with fresh and light soil.

Pre-rinse (15min) is a

programme for rinsing off food

remains from the dishes. It

prevents odours forming in the

appliance. Do not use detergent

with this programme.

B. 1h is a programme suitable for

dishwashing a load with fresh and

lightly dried-on soil.

C. 1h 30min is a programme suitable

for dishwashing and drying normally

soiled items.

D. 2h 40min is a programme suitable

for dishwashing and drying heavily

soiled items.

E. ECO is the longest programme

offering the most efficient use of

energy and water consumption for

crockery and cutlery with normal soil.

This is the standard programme for

test institutes. 1)

5.4 Programmes overview

ExtraHygiene
ExtraHygiene provides better hygiene results by keeping the temperature between 65 and 70 °C for at least 10 minutes during the last rinsing phase.
ExtraPower
ExtraPower improves the dishwashing results of the selected programme. The option increases the wash temperature and duration.
GlassCare
GlassCare prevents delicate load, glassware in particular, from damaging. The option prevents rapid changes in the dishwashing temperature of the selected programme and reduces it to 45 °C.

Programme Dishwasher Degree of

load

soil

Quick

Crockery, cutlery

Fresh

Programme phases EXTRAS

· Dishwashing 50 °C · ExtraPower

· Intermediate rinse · GlassCare

· Final rinse 45 °C · ExtraHy-

· AirDry

giene

1) This programme is used to assess compliance with the Ecodesign Comission Regulation (EU) 2019/2022.

ENGLISH 9

Programme Dishwasher Degree of

load

soil

Programme phases EXTRAS

All

Pre-rinse

· Prewash

Not applicable

Crockery, Fresh, lightly · Dishwashing 60 °C · ExtraPower

cutlery

dried-on

· Intermediate rinse · GlassCare

· Final rinse 50 °C · ExtraHy-

· AirDry

giene

1h 30min

Crockery, Normal, lightly · Dishwashing 60 °C · ExtraPower

cutlery, pots, dried-on

· Intermediate rinse · GlassCare

pans

· Final rinse 55 °C · ExtraHy-

· Drying

giene

· AirDry

2h 40min

Crockery, Normal to

cutlery, pots, heavy, dried-

pans

· Prewash

· ExtraPower

· Dishwashing 60 °C · GlassCare

· Intermediate rinse · ExtraHy-

· Final rinse 60 °C

giene

· Drying

· AirDry

ECO

Crockery, Normal, lightly · Prewash

· ExtraPower

cutlery, pots, dried-on

· Dishwashing 50 °C · GlassCare

pans

· Intermediate rinse · ExtraHy-

· Final rinse 55 °C

giene

· Drying

· AirDry

AUTO Sense

Crockery, All cutlery, pots, pans

· Prewash · Dishwashing 50 –
60 °C · Intermediate rinse · Final rinse 60 °C · Drying · AirDry

Not applicable

Machine Care

For cleaning the appliance interior. Refer to “Care and Cleaning”.

· Cleaning 70 °C · Intermediate rinse · Final rinse · AirDry

Not applicable

Consumption values

Programme 1) 2) Quick
Pre-rinse 1h
1h 30min

Water (l) 10.4 5.1 11.7 11.5

Energy (kWh) 0.600 0.040 0.845 1.000

Duration (min) 30 15 60 90

10 www.electrolux.com

Programme 1) 2)

Water (l)

Energy (kWh)

Duration (min)

2h 40min

12.0

1.009

160

ECO

0.848

240

AUTO Sense

11.9

0.964

170

Machine Care

9.9

0.636

1) The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. 2) The values for programmes other than ECO are indicative only.

Information for test institutes
To receive the necessary information for conducting performance tests (e.g. according to: EN60436 ), send an email to:
[email protected]

In your request, include the product number code (PNC) from the rating plate.
For any other questions regarding your dishwasher, refer to the service book provided with your appliance.

6. BASIC SETTINGS

You can configure the appliance by changing basic settings according to your needs.

Number Setting

Values

Description1)

Water hard- From level 1L Adjust the level of the water softener ac-

ness

to level 10L cording to the water hardness in your

(default: 5L) area.

Rinse aid level From level 0A Adjust the level of the rinse aid accord-

to level 6A (de- ing to the necessary dosage.

fault: 4A)

End sound

Activate or deactivate the acoustic signal

Off (default) for the end of a programme.

Auto door open On (default) Activate or deactivate the AirDry.

Off

Key tones

On (default) Activate or deactivate the sound of the

Off

buttons when pressed.

Latest pro-

Enable or disable the automatic selec-

gramme selec- Off (default) tion of the most recently used pro-

tion

gramme and options.

1) For more details, refer to the information provided in this chapter.

You can change the basic settings in setting mode.

When the appliance is in setting mode, the bars of the ECOMETER represent

available settings. For each setting, a dedicated bar of the ECOMETER flashes. The order of the basic settings presented in the table is also the order of the settings on the ECOMETER:
123456
6.1 Setting mode How to navigate in setting mode
You can navigate in setting mode using MY TIME selection bar.

ABC
A. Previous button B. OK button C. Next button Use Previous and Next to switch between the basic settings and to change their value. Use OK to enter the selected setting and to confirm changing its value.

How to enter setting mode

You can enter setting mode before starting a programme. You cannot enter setting mode while the programme is running.

To enter setting mode, press and hold

simultaneously

and

for

about 3 seconds.

ENGLISH 11
The lights related to the Previous, OK and Next are on.

How to change a setting

Make sure the appliance is in setting mode.

1. Use Previous or Next to select the bar of the ECOMETER dedicated to the desired setting. · The bar of the ECOMETER dedicated to the chosen setting flashes. · The display shows the current setting value.
2. Press OK to enter the setting. · The bar of the ECOMETER dedicated to the chosen setting is on. The other bars are off. · The current setting value flashes.
3. Press Previous or Next to change the value.
4. Press OK to confirm the setting. · The new setting is saved. · The appliance returns to the basic settings list.
5. Press and hold simultaneously

and

for about 3

seconds to exit setting mode.

The appliance returns to the programme

selection.

The saved settings remain valid until you

change them again.

6.2 The water softener
The water softener removes minerals from the water supply, which would have a negative effect on the washing results and on the appliance.
The higher the content of these minerals, the harder your water is. Water hardness is measured in equivalent scales.
The water softener should be adjusted according to the hardness of the water in your area. Your local water authority can advise you on the hardness of the water in your area. Set the right level of the water softener to assure good washing results.

12 www.electrolux.com

Water hardness German de- grees (°dH) 47 – 50 43 – 46 37 – 42 29 – 36 23 – 28 19 – 22

French de- grees (°fH)
84 – 90 76 – 83 65 – 75 51 – 64 40 – 50 33 – 39

15 – 18 11 – 14 4 – 10
<4

26 – 32 19 – 25 7 – 18
<7

1) Factory setting. 2) Do not use salt at this level.

mmol/l
8.4 – 9.0 7.6 – 8.3 6.5 – 7.5 5.1 – 6.4 4.0 – 5.0 3.3 – 3.9
2.6 – 3.2 1.9 – 2.5 0.7 – 1.8
<0.7

Clarke de- grees 58 – 63 53 – 57 46 – 52 36 – 45 28 – 35 23 – 27
18 – 22 13 – 17 5 – 12
< 5

Water softener level 10 9 8 7 6 5 1) 4 3 2 1 2)

Regardless of the type of detergent used, set the proper water hardness level to keep the salt refill indicator active.
Multi-tabs containing salt are not effective enough to soften hard water.
Regeneration process For the correct water softener operation, the resin of the softener device needs to be regenerated regularly. This process is automatic and is the part of the normal dishwasher operation.
When the prescribed quantity of water (see values in the table) has been used since the previous regeneration process, a new regeneration process will be initiated between the final rinse and the programme end.

Water softener level 1 2 3

Amount of water (l) 250 100 62

Water softener level 4 5 6 7 8 9 10

Amount of water (l) 47 25 17 10 5 3 3

In case of the high water softener setting, it may occur also in the middle of the programme, before the rinse (twice during a programme). Regeneration initiation has no impact on the cycle duration, unless it occurs in the middle of a programme or at the end of a programme with a short drying phase. In such cases, the regeneration prolongs the total duration of a programme by additional 5 minutes.
Subsequently, the rinsing of the water softener that lasts 5 minutes may begin in the same cycle or at the beginning of

ENGLISH 13

the next programme. This activity increases the total water consumption of a programme by additional 4 litres and the total energy consumption of a programme by additional 2 Wh. The rinsing of the softener ends with a complete drain.
Each performed softener rinse (possible more than one in the same cycle) may prolong the programme duration by another 5 minutes when it occurs at any point at the beginning or in the middle of a programme.
All the consumption values mentioned in this section are determined in line with the currently applicable standard in laboratory conditions with water hardness 2.5mmol/L (water softener: level 3) according to the regulation: 2019/2022 . The pressure and the temperature of water as well as the variations of the mains supply can change the values.
6.3 The rinse aid level
The rinse aid helps to dry the dishes without streaks and stains. It is automatically released during the hot rinse phase. It is possible to set the released quantity of rinse aid.
When rinse aid chamber is empty, the rinse aid indicator is on notifying to refill rinse aid. If the drying results are satisfactory while using multi-tablets only, it is possible to deactivate the dispenser and the indicator. However, for best drying performance, always use rinse aid and keep the rinse aid indicator active.
To deactivate the rinse aid dispenser and indicator, set the level of rinse aid to 0A.
6.4 End sound
You can activate an acoustic signal that sounds when the programme is completed.

Acoustic signals sound also when a malfunction of the appliance occurs. It is not possible to deactivate these signals.
6.5 AirDry
AirDry improves the drying results. The appliance door opens automatically during the drying phase and remains ajar.
AirDry is automatically activated with all programmes other than Pre-rinse. The duration of the drying phase and the door opening time vary depending on the selected programme and options. When AirDry opens the door, the display shows the remaining time of the running programme.
CAUTION! Do not try to close the appliance door within 2 minutes after automatic opening. This can cause damage to the appliance.
CAUTION! If children have access to the appliance, we advise to deactivate AirDry. The automatic opening of the door may pose a danger.
When AirDry opens the door, Beam-on-Floor might not be completely visible. To see if the programme is complete, look at the control panel.

14 www.electrolux.com
6.6 Key tones
The buttons on the control panel make a click sound when you press them. You can deactivate this sound.
6.7 Latest programme selection
You can set the automatic selection of the most recently used programme and options.
7. BEFORE FIRST USE
1. Make sure that the current level of the water softener agrees with the hardness of the water supply. If not, adjust the level of the water softener.
2. Fill the salt container. 3. Fill the rinse aid dispenser. 4. Open the water tap. 5. Start the programme Quick to
remove any residuals from the manufacturing process. Do not use detergent and do not put dishes in the baskets. After starting the programme, the appliance recharges the resin in the water softener for up to 5 minutes. The washing phase starts only after this procedure is complete. The procedure is repeated periodically.
7.1 The salt container
CAUTION! Use rough salt designed for dishwashers only. Fine salt increases the risk of corrosion.
The salt is used to recharge the resin in the water softener and to assure good washing results in daily use.
How to fill the salt container
Make sure that the ComfortLift basket is empty and locked in the raised position.
1. Turn the cap of the salt container counterclockwise and remove it.

The latest programme that was completed before the appliance deactivation is saved. It is then selected automatically after you activate the appliance. When the latest programme selection is disabled, the default programme is ECO.
2. Put 1 litre of water in the salt container (only for the first time).
3. Fill the salt container with dishwasher salt (until it is full).
4. Carefully shake the funnel by its handle to get the last granules inside.
5. Remove the salt around the opening of the salt container.
6. Turn the cap of the salt container clockwise to close the salt container. CAUTION! Water and salt can come out of the salt container when you fill it. After you fill the salt container, immediately start the shortest programme to prevent corrosion. Do not put dishes in the baskets.

7.2 How to fill the rinse aid dispenser

ENGLISH 15
CAUTION! Only use rinse aid designed specifically for dishwashers.
1. Open the lid (C). 2. Fill the dispenser (B) until the rinse
aid reaches the marking ”MAX”. 3. Remove the spilled rinse aid with an
absorbent cloth to prevent excessive foam formation. 4. Close the lid. Make sure that the lid locks into position.
Fill the rinse aid dispenser when the indicator (A) is clear.

CAUTION! The compartment (B) is for rinse aid only. Do not fill it with detergent.
8. DAILY USE
1. Open the water tap. 2. Press and hold until the appliance
is activated. 3. Fill the salt container if it is empty. 4. Fill the rinse aid dispenser if it is
empty. 5. Load the baskets. 6. Add the detergent. 7. Select and start a programme. 8. Close the water tap when the
programme is complete.
8.1 ComfortLift
CAUTION! Do not sit on the rack or put excessive pressure on the locked basket.
CAUTION! Do not exceed the max load capacity of 18 kg.

CAUTION! Make sure that items do not stick out of the basket frame as it can cause damage to the items and the ComfortLift mechanism.
The ComfortLift mechanism allows to lift the lower rack up (to the second rack level) and put it down to load and unload dishes easily.
To load or unload the lower basket:
1. Lift the basket by pulling the rack out of the dishwasher by the basket handle. The trigger handle should not be used.

16 www.electrolux.com
The basket is automatically locked on the upper level. 2. Carefully place items in the basket or
remove them (refer to the basket loading leaflet). 3. Lower the basket by connecting the trigger handle with the basket frame as shown below. Lift the trigger handle completely and the basket handle slightly until the basket is disengaged on both sides.

Once the basket is unlocked, push the rack down. The mechanism returns to its default position on the lower level. There are two ways of lowering the basket depending on the loading: · If there is a full load of plates,
slightly push the basket down. · If the basket is empty or half-
loaded, press the basket down.

8.2 Using the detergent

C
CAUTION! Only use detergent specifically designed for dishwashers.
1. Press the release button (A) to open the lid (C).

2. Put the detergent (gel, powder or tablets) in the compartment (B).
3. If the programme has a prewash phase, put a small quantity of detergent on the inner part of the appliance door.
4. Close the lid. Make sure that the lid locks into position.
For information about the detergent dosage, refer to the manufacturer’s instructions on the packaging of the product. Usually, 20 – 25 ml of gel detergent is adequate for washing a load with normal soil.

The upper ends of the two vertical ribs inside the compartment (B) indicate the maximum level for filling the dispenser with gel (max. 30ml).

8.3 How to select and start a programme using MY TIME selection bar
1. Slide your finger across MY TIME selection bar to choose a suitable programme. · The light related to the selected programme is on. · The ECOMETER indicates the level of energy and water consumption. · The display shows the programme duration.
2. Activate applicable EXTRAS if desired.
3. Close the appliance door to start the programme.

8.4 How to select and start the programme Pre-rinse

1. To select Pre-rinse, press and

hold

for 3 seconds.

· The light related to the button is

on.

· The ECOMETER is off.

· The display shows the programme duration.
2. Close the appliance door to start the programme.

8.5 How to activate EXTRAS
1. Select a programme using MY TIME selection bar.
2. Press the button dedicated to the option you want to activate. · The light related to the button is on. · The display shows the updated programme duration. · The ECOMETER indicates the updated level of energy and water consumption.
By default, options must be activated every time before you start a programme. If the latest programme selection is enabled, the saved options are activated automatically along with the programme.

It is not possible to activate or deactivate options while a programme is running.

Not all options are compatible with each other.

Activating options often increases the water and energy consumption as well as the programme duration.

8.6 How to start the AUTO Sense program

1. Press

· The light related to the button is

on.

· The display shows the longest

possible program duration.

2. Close the appliance door to start the

program.

The appliance senses the type of load

and adjusts a suitable wash cycle.

During the cycle, the sensors operate

several times and the initial program

duration can decrease.

ENGLISH 17
8.7 How to delay the start of a programme
1. Select a programme. 2. Press repeatedly until the display
shows the desired delay time (from 1 to 24 hours). The light related to the button is on. 3. Close the appliance door to start the countdown. During the countdown, you cannot change the delay time and the programme selection.
When the countdown is complete, the programme starts.
8.8 How to cancel the delay start while the countdown operates
Press and hold for about 3 seconds. The appliance returns to the programme selection.
If you cancel the delay start, you have to select the programme again.
8.9 How to cancel a running programme
Press and hold for about 3 seconds. The appliance returns to the programme selection.
Make sure that there is detergent in the detergent dispenser before you start a new programme.
8.10 Opening the door while the appliance operates
Opening the door while a programme is running pauses the wash cycle. The display shows the remaining duration of the programme. After closing the door, the wash cycle resumes from the point of interruption.
If you open the door during the delay start countdown, the countdown is paused. The display shows the current

18 www.electrolux.com
countdown status. After closing the door, the countdown resumes.
Opening the door while the appliance operates may affect the energy consumption and the programme duration.
If the door is opened for more than 30 seconds during the drying phase, the running programme ends. It does not happen if the door is opened by the AirDry function.
8.11 The Auto Off function
This function saves energy by switching the appliance off when it is not operating.
9. HINTS AND TIPS
9.1 General
Follow the hints below to ensure optimal cleaning and drying results in daily use and to protect the environment.
· Washing dishes in the dishwasher as instructed in the user manual usually consumes less water and energy than washing dishes by hand.
· Load the dishwasher to its full capacity to save water and energy. For best cleaning results, arrange items in the baskets as instructed in the user manual and do not overload the baskets.
· Do not pre-rinse dishes by hand. It increases the water and energy consumption. When needed, select a programme with a prewash phase.
· Remove larger residues of food from the dishes and empty cups and glasses before putting them inside the appliance.
· Soak or slightly scour cookware with firmly cooked-on or baked-on food before washing it in the appliance.
· Make sure that items in the baskets do not touch or cover each other. Only then can the water completely reach and wash the dishes.
· You can use dishwasher detergent, rinse aid and salt separately or you

The function comes into operation automatically: · When the programme is completed. · After 5 minutes if a programme was
not started.
8.12 End of the programme
When the programme is complete, the display shows 0:00. The Auto Off function switches the appliance off automatically.
All buttons are inactive except for the on/off button.
can use the multi-tablets (e.g. ”All in 1”). Follow the instructions on the packaging. · Select a programme according to the type of load and the degree of soil. ECO offers the most efficient use of water and energy consumption. · To prevent limescale buildup inside the appliance: Refill the salt container whenever
necessary. Use the recommended dosage of
the detergent and rinse aid. Make sure that the current level of
the water softener agrees with the hardness of the water supply. Follow the instructions in the chapter “Care and cleaning”.
9.2 Using salt, rinse aid and detergent
· Only use salt, rinse aid and detergent designed for dishwasher. Other products can cause damage to the appliance.
· In areas with hard and very hard water, we recommend to use basic dishwasher detergent (powder, gel, tablets containing no additional agents), rinse aid and salt separately

for optimal cleaning and drying results. · Detergent tablets do not fully dissolve with short programmes. To prevent detergent residues on the tableware, we recommend that you use tablets with long programmes. · Always use the correct quantity of detergent. Insufficient dosage of detergent can result in poor cleaning results and hard-water filming or spotting on the items. Using too much detergent with soft or softened water results in detergent residues on the dishes. Adjust the amount of detergent based on the water hardness. Refer to the instructions on the detergent packaging. · Always use the correct quantity of rinse aid. Insufficient dosage of rinse aid decreases the drying results. Using too much rinse aid results in bluish layers on the items. · Make sure that the water softener level is correct. If the level is too high, the increased quantity of salt in the water might result in rust on cutlery.
9.3 What to do if you want to stop using multi-tablets
Before you start using separately detergent, salt and rinse aid, complete the following steps:
1. Set the highest level of the water softener.
2. Make sure that the salt and rinse aid containers are full.
3. Start the Quick programme. Do not add detergent and do not put dishes in the baskets.
4. When the programme is completed, adjust the water softener according to the water hardness in your area.
5. Adjust the released quantity of rinse aid.
9.4 Before starting a programme
Before you start the selected programme, make sure that:
· The filters are clean and correctly installed.

ENGLISH 19
· The cap of the salt container is tight. · The spray arms are not clogged. · There is enough salt and rinse aid
(unless you use multi-tablets). · The arrangement of the items in the
baskets is correct. · The programme is suitable to the type
of load and the degree of soil. · The correct quantity of detergent is
used.
9.5 Loading the baskets
· Always use the whole space of the baskets.
· Use the appliance to wash dishwasher-safe items only.
· Do not wash in the appliance items made of wood, horn, aluminium, pewter and copper as they could crack, warp, get discoloured or pitted.
· Do not wash in the appliance items that can absorb water (sponges, household cloths).
· Put hollow items (cups, glasses and pans) with the opening facing downwards.
· Make sure that glass items do not touch each other.
· Put light items in the upper basket. Make sure that the items do not move freely.
· Put cutlery and small items in the cutlery drawer.
· Move the upper basket upwards to accommodate large items in the lower basket.
· Make sure that the spray arms can move freely before you start a programme.
9.6 Unloading the baskets
1. Let the tableware cool down before you remove it from the appliance. Hot items can be easily damaged.
2. First remove items from the lower basket, then from the upper basket.
After the programme is completed, water can still remain on the inside surfaces of the appliance.

20 www.electrolux.com
10. CARE AND CLEANING

WARNING! Before any maintenance other than running the programme Machine Care, deactivate the appliance and disconnect the mains plug from the main socket.
Make sure that the ComfortLift basket is empty and locked in the raised position.
Dirty filters and clogged spray arms negatively affect the washing results. Check these elements regularly and, if necessary, clean them.
10.1 Machine Care
Machine Care is a programme designed to clean the appliance interior with optimal results. It removes limescale and grease buildup.
When the appliance senses the need for
cleaning, the indicator is on. Start the Machine Care programme to clean the appliance interior.

How to start the Machine Care programme

Before starting the Machine Care programme, clean the filters and spray arms.

1. Use a descaler or a cleaning product designed specifically for dishwashers. Follow the instructions on the packaging. Do not put dishes in the baskets.

2. Press and hold simultaneously

and

for about 3 seconds.

The indicators and flash. The display shows the programme duration. 3. Close the appliance door to start the
programme.

When the programme is complete, the
indicator is off.
10.2 Internal cleaning
· Clean the appliance interior with a soft damp cloth.
· Do not use abrasive products, abrasive cleaning pads, sharp tools, strong chemicals, scourer or solvents.
· Wipe clean the door, including the rubber gasket, once a week.
· To maintain the performance of your appliance, use a cleaning product designed specifically for dishwashers at least once every two months. Carefully follow the instructions on the packaging of the product.
· For optimal cleaning results, start the programme Machine Care.
10.3 Removal of foreign objects
Check the filters and the sump after each use of the dishwasher. Foreign objects (e.g. pieces of glass, plastic, bones or toothpicks, etc) decrease the cleaning performance and can cause damage to the drain pump.
CAUTION! If unable to remove the foreign objects, contact an Authorised Service Centre.
1. Disassemble the filters system as instructed in this chapter.
2. Remove any foreign objects manually.
3. Reassemble the filters as instructed in this chapter.
10.4 External cleaning
· Clean the appliance with a moist soft cloth.
· Only use neutral detergents. · Do not use abrasive products,
abrasive cleaning pads or solvents.
10.5 Cleaning the filters
The filter system is made of 3 parts.

ENGLISH 21
C

1. Turn the filter (B) counterclockwise and remove it.

5. Make sure that there are no residues of food or soil in or around the edge of the sump.
6. Put back in place the flat filter (A). Make sure that it is correctly positioned under the 2 guides.

2. Remove the filter (C) out of filter (B). 3. Remove the flat filter (A).

7. Reassemble the filters (B) and (C). 8. Put back the filter (B) in the flat filter
(A). Turn it clockwise until it locks.

4. Wash the filters.

CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance.

22 www.electrolux.com
10.6 Cleaning the lower spray arm
We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results. 1. To remove the lower spray arm, pull
it upwards.

10.7 Cleaning the upper spray arm
We recommend to clean the upper spray arm regularly to prevent soil from clogging the holes.
Clogged holes can cause unsatisfactory washing results.
1. Pull out the upper basket. 2. To detach the spray arm from the
basket, press the spray arm upwards and simultaneously turn it clockwise.

2. Wash the spray arm under running water. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes.

3. Wash the spray arm under running water. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes.

3. To install the spray arm back, press it downwards.

4. To install the spray arm back, press the spray arm upwards and simultaneously turn it counterclockwise until it locks into place.

ENGLISH 23

10.8 Cleaning the ceiling spray arm
We recommend to clean the ceiling spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results.
The ceiling spray arm is placed on the ceiling of the appliance. The spray arm (C) is installed in the delivery tube (A) with the mounting element (B).

2. Move the upper basket to the lowest level to reach the spray arm more easily.
3. To detach the spray arm (C) from the delivery tube (A), turn the mounting element (B) counterclockwise and pull the spray arm downwards.
4. Wash the spray arm under running water. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes. Run the water through the holes to wash soil particles away from the inside.

5. To install the spray arm (C) back,

insert the mounting element (B) in

the spray arm and fix it in the delivery tube (A) by turning it clockwise. Make

sure that the mounting element locks

into place.

6. Install the cutlery drawer on the

sliding rails and block the stoppers.

1. Release the stoppers on the sides of the sliding rails of the cutlery drawer and pull the drawer out.

1 2

24 www.electrolux.com
11. TROUBLESHOOTING
WARNING! Improper repair of the appliance may pose a danger to the safety of the user. Any repairs must be performed by qualified personnel.
The majority of problems that may occur can be solved without the need

to contact an Authorised Service Centre.
Refer to the below table for information on possible problems.
With some problems, the display shows an alarm code.

Problem and alarm code Possible cause and solution

You cannot activate the appliance.

· Make sure that the mains plug is connected to the mains socket.
· Make sure that there is no damaged fuse in the fuse box.

The programme does not start.

· Make sure that the appliance door is closed. · If the delay start is set, cancel the setting or wait for
the end of the countdown. · The appliance recharges the resin inside the water
softener. The duration of the procedure is approxi- mately 5 minutes.

The appliance does not fill · Make sure that the water tap is open.

with water.

· Make sure that the pressure of the water supply is

The display shows i10 or

not too low. For this information, contact your local

i11.

water authority.

· Make sure that the water tap is not clogged.

· Make sure that the filter in the inlet hose is not clog-

ged.

· Make sure that the inlet hose has no kinks or bends.

The appliance does not drain the water. The display shows i20.

· Make sure that the sink spigot is not clogged. · Make sure that the interior filter system is not clog-
ged. · Make sure that the drain hose has no kinks or bends.

The anti-flood device is on. ·

The display shows i30.

Close the water tap. Make sure that the appliance is correctly installed. Make sure the baskets are loaded as instructed in the user manual.

Malfunction of the water level detection sensor. The display shows i41 i44.

· Make sure that the filters are clean. · Switch the appliance off and on.

Malfunction of the wash pump or the drain pump. The display shows i51 i59 or i5A – i5F.

· Switch the appliance off and on.

ENGLISH 25

Problem and alarm code Possible cause and solution

The temperature of the wa- · ter inside the appliance is too high or malfunction of · the temperature sensor oc- curred. The display shows i61 or i69.

Make sure that the temperature of the inlet water does not exceed 60°C. Switch the appliance off and on.

Technical malfunction of the appliance. The display shows iC0 or iC3.

· Switch the appliance off and on.

The level of water inside the appliance is too high. The display shows iF1.

· Switch the appliance off and on. · Make sure that the filters are clean. · Make sure that the outlet hose is installed at the right
height above the floor. Refer to the installation in- structions.

The appliance stops and starts more times during operation.

· It is normal. It provides optimal cleaning results and energy savings.

The programme lasts too long.

· If the delay start option is set, cancel the delay set- ting or wait for the end of the countdown.
· Activating options increases the programme dura- tion.

The displayed programme · Refer to the consumption values table in the chapter

duration is different than

“Programme selection”.

the duration in the con-

sumption values table.

The remaining time in the display increases and skips nearly to the end of the programme duration.

· This is not a defect. The appliance is working cor- rectly.

Small leak from the appli- ance door.

· The appliance is not levelled. Loosen or tighten the adjustable feet (if applicable).
· The appliance door is not centred on the tub. Adjust the rear foot (if applicable).

The appliance door is diffi- · The appliance is not levelled. Loosen or tighten the

cult to close.

adjustable feet (if applicable).

· Parts of the tableware are protruding from the bas-

kets.

The appliance door opens · The AirDry function is activated. You can deactivate

during the wash cycle.

the function. Refer to “Basic settings”.

Rattling or knocking sounds from the inside of the appliance.

· The tableware is not properly arranged in the bas- kets. Refer to basket loading leaflet.
· Make sure that the spray arms can rotate freely.

26 www.electrolux.com

Problem and alarm code Possible cause and solution

The appliance trips the cir- · The amperage is insufficient to supply simultaneous-

cuit-beaker.

ly all the appliances in use. Check the socket amper-

age and the capacity of the meter or turn off one of

the appliances in use.

· Internal electrical fault of the appliance. Contact an

Authorised Service Centre.

Once you have checked the appliance, deactivate and activate the appliance. If the problem occurs again, contact an Authorised Service Centre.
For alarm codes not described in the table, contact an Authorised Service Centre.
WARNING! We do not recommend using the appliance until the problem has been completely fixed. Unplug the appliance and do not plug it in again until you are certain that it operates correctly.

The PNC can be found on the rating plate on the appliance door. You can also check the PNC on the control panel.
Before checking the PNC, make sure the appliance is in the programme selection.

1. Press and hold simultaneously

and

for about 3 seconds.

The display shows the PNC of your

appliance.

2. To exit the PNC presentation, press

and hold simultaneously and for about 3 seconds. The appliance returns to the programme selection.

11.1 The product number code (PNC)
If you contact an Authorised Service Centre, you need to provide the product number code of your appliance.
11.2 The dishwashing and drying results are not satisfactory

Problem Poor washing results.

Possible cause and solution
· Refer to “Daily use”, “Hints and tips” and the basket loading leaflet.
· Use more intensive washing programme. · Activate the ExtraPower option to improve the
washing results of a selected programme. · Clean spray arm jets and filter. Refer to “Care and
Cleaning”.

ENGLISH 27

Problem

Possible cause and solution

Poor drying results.

· Tableware was left for too long inside the closed appliance. Activate the function AirDry to set the automatic opening of the door and to improve the drying performance.
· There is no rinse aid or the dosage of rinse aid is not sufficient. Fill the rinse aid dispenser or set the dosage of rinse aid to a higher level.
· The quality of the rinse aid can be the cause. · Always use rinse aid, even with multi-tablets. · Plastic items may need to be towel dried. · The programme does not have the drying phase.
Refer to “Programmes overview”.

There are whitish streaks or · The released quantity of rinse aid is too high. Ad-

bluish layers on glasses and just the rinse aid dosage to a lower level.

dishes.

· The quantity of detergent is too high.

There are stains and dry wa- · The released quantity of rinse aid is not sufficient.

ter drops on glasses and

Adjust the rinse aid dosage to a higher level.

dishes.

· The quality of the rinse aid can be the cause.

The interior of the appliance · This is not a defect of the appliance. Humidity con-

is wet.

densates on the appliance walls.

Unusual foam during wash- ing.

· Use the detergent designed specifically for dish- washers.
· Use a detergent from a different manufacturer. · Do not pre-rinse dishes under running water.

Traces of rust on cutlery.

· There is too much salt in the water used for wash- ing. Refer to “The water softener”.
· Silver and stainless steel cutlery were placed to- gether. Do not place silver and stainless steel items close together.

There are residues of deter- · The detergent tablet was stuck in the dispenser

gent in the dispenser at the

and was not washed away by water.

end of the programme.

· Water cannot wash away the detergent from the

dispenser. Make sure that the spray arms are not

blocked or clogged.

· Make sure that items in the baskets do not impede

the lid of the detergent dispenser from opening.

Odours inside the appliance. · Refer to “Internal cleaning”. · Start the Machine Care programme with a descaler or a cleaning product designed for dishwashers.

28 www.electrolux.com

Problem

Possible cause and solution

Limescale deposits on the · The level of salt is low, check the refill indicator.

tableware, on the tub and on · The cap of the salt container is loose.

the inside of the door.

· Your tap water is hard. Refer to “The water soft-

ener”.

· Use salt and set regeneration of the water softener

even when multi-functional tablets are used. Refer

to “The water softener”.

· Start the Machine Care programme with a descaler

designed for dishwashers.

· If limescale deposits persist, clean the appliance

with the suitable detergents.

· Try a different detergent.

· Contact the detergent manufacturer.

Dull, discoloured or chipped · Make sure that only dishwasher-safe items are

tableware.

washed in the appliance.

· Load and unload the basket carefully. Refer to the

basket loading leaflet.

· Place delicate items in the upper basket.

· Activate the GlassCare option to ensure special

care for glassware and delicate items.

Refer to “Before first use”, “Daily use”, or “Hints and tips” for other possible causes.

12. TECHNICAL INFORMATION

Dimensions

Width / height / depth (mm)

596 / 818 – 898 / 550

Electrical connection 1)

Voltage (V) Frequency (Hz)

220 – 240 50

Water supply pressure

bar (minimum and maximum) 0.5 – 10

MPa (minimum and maximum) 0.05 – 1.0

Water supply

Cold water or hot water 2)

max 60 °C

Capacity

Place settings

1) Refer to the rating plate for other values. 2) If the hot water comes from alternative source of energy (e.g. solar panels), use the hot water supply to decrease energy consumption.

12.1 Link to the EU EPREL database
The QR code on the energy label supplied with the appliance provides a web link to the registration of this

appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance.

ENGLISH 29

It is possible to find information related to the performance of the product in the EU EPREL database using the link https:// eprel.ec.europa.eu and the model name and product number that you can find on the rating plate of the appliance. Refer to the chapter “Product description”.

For more detailed information about the energy label, visit www.theenergylabel.eu.

13. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of

appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.

117853971-A-412021

www.electrolux.com/shop
