FF-CT80 Manual Curved Treadmill with Resistance

Product Information

The FF-CT80 French Fitness CT80 Manual Curve Treadmill with
Resistance is a commercial-grade treadmill suitable for fitness
clubs, bodybuilding training, sports training, and physical
education. It features a rotary knob for resistance adjustment and
comes with a warranty of 10 years for parts and 1 year for labor
(commercial use).

Product Usage Instructions

1. Please read all precautions and instructions in this manual
   before using the treadmill.
2. The treadmill is suitable for indoor use only. Do not use it
   outdoors or in high humidity situations. Avoid splashing water or
   any other liquid on the treadmill and do not place or insert any
   abnormal objects on it.
3. Make sure the treadmill is placed on a smooth surface with all
   four feet on the ground. Leave a safety space of 2000 mm * 1000 mm
   behind the treadmill.
4. When using the treadmill, wear appropriate sportswear and
   sports shoes. If you are a first-time user, seek professional
   guidance. Stop the machine immediately in case of an
   emergency.
5. Do not allow more than one person to stand on the treadmill at
   the same time, and the maximum load weight is 170 kg.
6. The heart rate sensor is not professional medical equipment,
   and its detection may be inaccurate. Use both hands to hold the
   handrail for several seconds to get a relatively accurate heart
   rate.
7. Action guidance:
   • A. Aerobic exercise: energy consumption, improving
     cardiopulmonary skills, accelerating blood circulation, enhancing
     physical fitness, and weight loss.
   • B. First-time users should hold the handrail for balance.
   • C. Only walk down the treadmill after ensuring safety.
8. Ensure that no part of the treadmill is loose and avoid
   touching any running parts with your fingers. Users with long hair
   should pay attention to hair safety.
9. If you feel uncomfortable while using the treadmill, stop
   immediately and consult a doctor.
10. Before every use, check and tighten all bolts and screws.
    Replace or fix any loose parts.
11. Follow the maintenance instructions and look for the “Stop”
    mark.
12. If there is any abnormal noise or situation, stop running and
    contact the after-sales department or seek professional help.

Technical Standards

The treadmill operates on a four-cell dry battery and offers
various measurements including time, distance, calories, heart
rate, rotating speed, and resistance adjustment level. The
technical specifications are as follows:

• Time: 0:00 — 99.59
• Distance: 0.00 — 99.99 km
• Calories: 0 — 999 kcal
• Heart rate: 60 — 300 beats/min
• Rotating speed: 0 — 90 km/h
• Resistance adjustment level: 1 — 8 (at level 1, the resistance
  is 0; at level 8, the resistance is maximum)

Machine Diagram

The treadmill consists of a console holder, console, handle,
stand column, running belt, foot pedal, and carry handle.

Installation: Assembly of Treadmill Body

To ensure easy assembly, follow the steps below:

1. Refer to the User Manual for detailed assembly
   instructions.
2. Follow the provided diagrams and guidelines to assemble the
   treadmill body.

FF-CT80 FRENCH FITNESS CT80 MANUAL CURVE
TREADMILL W/RESISTANCE
ASSEMBLY MANUAL
1

FEATURES

· Transport Wheels in front & Handles in rear for easy transportation
· Non- motorized Zero- energy · consumption · Pure green energy treadmill · Creative crawler belt without
running board design ensures that the running belt has no sideways deviation and waxing. · Fully shock- absorbing, safe and comfortable

· Creative precision bearing transmission system, smooth, zero drag and stick
· Lower noise, power consumption, failure rate and maintenance cost
· Eliminates the slippage of traditional running belts
· Accurate speed, no block or cover of running area, wider field of vision, easier for gait analysis

TECH SPECS

· 8 Resistance Levels · Run at no resistance · Jog at low resistance · Walk / Push at medium resistance · Sled Push at high resistance · Non- motorized · Power: Cordless (Self Generated);
Display uses batteries · Speed: Resistance adjustment by
a rotary knob

· Console Readouts: Time, Distance, Calories, and Speed
· Running belt size (L x W) 67 in x 18 in (1700 mm x 440 mm)
· Weight: 346 lb (157 kg)
· Dimensions (L x W x H): 78 in x 34 in 59.5 in (1981 mm x 864 mm x 1511 mm)

WARRANTY
10 Years Parts, 1 Year Labor (Commercial)

2

TABLE OF CONTENTS
SAFETY CAUTIONS ………………………………………………………………………………….. 4 TECHNICAL STANDARD…………………………………………………………………………….. 6 MACHINE DIAGRAM ……………………………………………………………………………….. 7 INSTALLATION, STEP 1: ASSEMBLY OF TREADMILL BODY ………………………………. 8 INSTALLATION, STEP 2: CALIBRATING RESISTANCE ……………………………………… 10 INSTALLATION, STEP 3: CONNECTING + INSTALLING CONSOLE ……………………… 11 OPERATION GUIDE ………………………………………………………………………………. 13 PACKING LIST ……………………………………………………………………………………….. 15 EXPLOSIVE VIEW …………………………………………………………………………………… 16 PARTS LIST …………………………………………………………………………………………… 17
3

SAFETY CAUTION
Please read all precautions and instructions in this manual before using this equipment.
1. This Curve treadmill is suitable for commercial fitness clubs, clubhouse fitness, bodybuilding training, sports training, physical education and so on.
2. This Curve treadmill is suitable for indoor use, do not use it outdoors or in high humidity situation. Do not splash water or any other liquid on the treadmill. Do not put or insert any abnormal things on the treadmill.
3. Please ensure its 4 feet on the ground when using it and placed it smoothly. There should retain 2000 mm * 1000 mm of safety space behind the treadmill.
4. When using the treadmill, please wear appropriate sportswear and sports shoes. For the exerciser who use the treadmill for the first time, professional guidance will be needed. In the event of an emergency, stop the machine immediately.
5. It is forbidden to let two or more people stand on the treadmill at the same time, the maximum load weight is 170 kg.
6. The heart rate sensor is not professional medical equipment, there are many reasons which can cause inaccurate detection, test results are for reference only.(Hold the heart of the handrail with both hands, several seconds later, to get a relatively accurate heart rate).
7. The action guidance: A. Aerobic exercise : energy consumption, improve cardiopulmonary skills, accelerate the blood circulation, enhance physical fitness, loss weight. B. When using this treadmill for the first time, exerciser needs to hold the handrail to keep the balance. C. People can only walk down the treadmill after after safety confirmation.
8. Any part of treadmill can not be in loose status. 9. Never touch any parts of running treadmill with your finger. 10. People with long hair should pay attention to the safety of hair when using this
treadmill.
4

11. When you feel uncomfortable when using this treadmill, please stop immediately and consult to the doctor.
12. Please check and make sure every bolt and screw was locked tight every time before you start to use the treadmill. If any of them is loose, please change or fixed it.
13. There must be the mark of “Stop” in maintenance. 14. If there is abnormal noise or other abnormal situation of the treadmill, please
stop running immediately and contact our after-sales department immediately, or seek professional help. 15. This treadmill is coincident to the type of SC in EN 957-6.
5

TECHNICAL STANDARDS
Input supply voltage: four-cell dry battery Time: 0:00 — 99.59 Distance: 0.00 — 99.99 (km) Calories: 0 — 999 (kcal) Heart rate: 60 — 300 (beats/min) Rotating speed: 0 — 90KM/H Resistance adjustment level: 1 — 8 (at1, the resistance is 0, at 8, the resistance is maximum)
6

MACHINE DIAGRAM

Console holder

Console

Handle

Stand column Running belt

Foot Pedal

Carry handle 7

INSTALLATION, STEP 1: ASSEMBLY OF TREADMILL BODY
Taking easy-assembly as the principle: User Manual of this section is designed to ensure that the treadmills can be assembled
correctly and easily. · Considering the big size of the treadmill, please select the location where the treadmill will be placed and ensure there is enough space around it. · Place all parts of the treadmill in the empty area and remove all packing materials. Do not discard the packing materials until the assembly work is completed. · All bolts must be tightened during the assembly process unless otherwise stated, and all bolts must be tightened when the assembly work is completed. · When assembling the treadmill, please make sure all parts are assembled according to the assembly drawing.
8

Assembly step one:
Connect the magnetic induction line and assemble the stand column. Assembly instructions: 1) Remove the packing materials on both sides of the stand column.
2) Fix the stand column to the corresponding position of the main frame as shown in the picture below. Note: Connect the magnetic line below.

Magnetic wire connecting (one wire only)

Connect up and down (one wire only)

9

INSTALLATION, STEP 2: CALIBRATING RESISTANCE
Connecting and Adjusting Resistance: Connecting please see steps 1 and 2 below.
Adjusting: The nut on the Side Handle cable can be either moved up or down on the thread. The 2 nuts must always sandwich the hook firmly otherwise the cable can move out of the adjustment and resistance will not be changed.

Step 1. Connect both cable by sandwiching the hook of the Bottom cable

Step 2. Connecting the ending of the Side Handle cable with the Bottom cable as illustrated in the image. The Side Handle cable has 2 nuts-they need to go snug on the Bottom cable section.

10

INSTALLATION, STEP 3: CONNECTING + INSTALLING CONSOLE
Assembly step two: Connect the magnetic induction lineassemble the console holder and handrail Assembly instructions: 1) Connect the magnetic induction line of the console holder to those in the stand column. 2) Fix the console holder tightly with the stand column as shown in the picture below, using 2 pcs of (27). 3Fix the handrail tightly with the stand column as shown in the picture below
Magnetic wire connecting (one wire only)
11

Assembly step three: Assembling the console; connecting the magnetic line 1) Connecting the magnetic line of the console with the line in the holder console holder.
2) After connected the magnetic line, place the console at the joint of console holder and fasten it (as shown), using 4pcs of (13) and 4pcs of (14).

3) Stepping on the running belt run it, and press the button

to start the treadmill,

check the machine is running normally or not, the console data display is comprehensive

and accurate or not.

4) If the machine runs normally, all bolts are tightened in place, then, the treadmill is

assembled;

Magnetic wire connecting (one wire only)

12

OPERATION GUIDE
Console Introduction:
This treadmill adopts console model, four dry battery power supply, low power consumption, no external power supply required;
This treadmill interface has only one main interface, with six buttons to achieve the purpose of use, the specific operation methods of the treadmill are as follows:
1. Home page

The main interface is used to display device name, time, distance, calories, speed, 2. Six button

(1)

Start/Stop button. In standby mode, all data will start counting only when

you click this button.Click this key while running, and all data will stop counting.

(2)

Numerical plus key: For numerical addition on numerical setting interface,

growing rate: +1

13

(3)

Numerical minus key: For numerical reduction on numerical setting

interface, reduction rate: -1

(4)

Program setting key: Click this key to start program setting, consist of

body fat test; time reciprocal, distance reciprocal, calories reciprocal and heart

rate monitoring five kinds of procedures;

(5)

Reset key: Touch this button (no more than 3s) to back step.; Long press

this key (more than or equal to 3s) to return to the initial interface, all data will be

reset.

(6) Confirm key: Confirm key for data and program selection. numerical modification confirmation;

Resistance knob operation instruction This treadmill uses a knob to adjust the resistance of the wire. As shown in the picture it is divided into 1-8 gears from left to right, and the resistance increases gradually

14

PACKING LIST

1. Main frame assembly 2. Right side stand column handrail 3. Left side stand column handrail 4. Console welding assembly 5. Console 6. Whole Screw

one piece one piece one piece one piece one piece one piece

15

EXPLOSIVE VIEW
16

PARTS LIST

Item

Description

1 TZ04-SP03-0402 Left side cover 2 TZ04-SP03-0403 Running belt rack 3 TZ04-SP03-0407 Right side support group 4 TZ04-SP03-0408 Carry handle 5 TZ04-SP03-0411 Right handle group 6 TZ04-SP03-0415 Left side support group 7 TZ04-SP03-0416 Left handle group 8 TZ04-SP03B-0417 Right side cover 9 TZ04-SP03-0410 Right side stand column welding part 10 TZ04-SP03-0414 Left side handle welding part 11 TZ04-SP03B-0420 Belt pulley rack 12 TZ04-SP03B-0421 handrail group 13 TZ04-SP03B-0422 handrail group 14 TZ04-SP03B-0423 condole welding group 15 TZ06-SP03-0603 Back axle 16 TZ03-SP03-0614 Footing 17 M16 Footing 18 TZ06-SP03-0612 Front wheel 19 TZ02-SP03-0236 bearing holder 20 TZ-5013-0211 Small round baffle 21 TZ03-SP03-0308 Small bearing spacer 22 TZ03-SP03-0311 Adjustable aluminum wheels 23 TZ03-SP03-0307 Big bearing spacer 24 Front wheel 25 Running belt unit 26 TZ02-SP03-0235 Running belt fixed sheet metal 27 601 Plastic part

17

QTY
1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 2 4 1 4 94 15 32 2 60 120 2

Item

Description

28 TZ03-SP03-0309 inside bearing spacer 29 Probe fixing piece 30 Probe 31 TZ02-SP03-0239 Counter fixing piece 32 608 Bearing 33 TZ10-SP03-1002 Foam tape 34 TZ03-7039-0324 Handle spacer (aluminum 35 TZ02-SP03B-0244 Ventilated aluminum pan 36 TZ02-SP03B-0246 Magnet fixed sheet metal 37 TZ02-SP03B-0247 Magnet fixed sheet metal 38 TZ02-SP03B-0250 Aluminum plate fixed sheet metal 39 TZ03-SP03B-0333 Set screw 40 TZ03-SP03B-0328 Small pulley 41 TZ03-SP03B-0327 Big pulley 42 TZ03-SP03B-0331 Support column 43 TZ03-SP03B-0332 Spacer nylon sleeve 44 TZ10-SP03B-1006 Strong magnetism 45 TZ02-SP03B-0251 Wire drawing sheet metal 46 TZ-7022-0123E 47 TZ-7022-0202 Flywheel shaft 48 TZ-7022-0123D 49 TZ03-SP03B-0008 Aluminum handle 50 039 Shock-absorbing positioning block 51 TZ03-SP03-0326 Reinforced casing 52 GT009 53 FL005 Bearing pedestal 54 6205 Bearing 55 TZ05-7037-0120 Tension spring

18

QTY
4 1 1 1 128 4 4 1 1 1 1 1 1 1 3 1 8 1 1 1 1 2 1 8 2 4 1 1

Item

Description

56 TZ10-SP03-1003 Foam tape 57 TZ17-SP03-1701 Running belt 58 5039 Soft spring 59 TZ10-SP03B-1004 Pull up Line 60 TZ10-SP03B-1005 Pull down line 61 30 62 8PJ420 Belt 63 M8X40L-N1 Hexagon socket cap screws 64 8 Gasket 65 M8X7t-S1 Lock nut 66 M10X20L-N2 Hexagon socket screw 67 8X25 Flat key 68 22X13X1.5t-C1 Washer 69 M12X30L-N1 Hexagon socket cap screws 70 M6X8L-J1 Set screw 71 M8X16L-N2 Hexagon round screw 72 M10X100L-N1 Hexagon socket cap screws 73 8X14 Flat key 74 M10X15L-N2 Hexagon round screw 75 M8X45L-N1 Hexagon socket cap screws 76 M5X10L-A1 Cross plate circular bolt 77 M4X12L-M1 Cruciform slotted screw 78 M8X50L-N1 Hexagon socket cap screws 79 M16X14.8 Nut 80 M5X12L-A1 Cross plate circular bolt 81 M5X20L-N3 Hexagon countersunk head screw 82 M10X60L-N1 Hexagon socket cap screws 83 M10X9t-S1 fasten the screw nut

19

QTY
2 2 1 1 1 2 1 94 169 136 22 4 2 2 12 8 2 2 4 14 32 6 2 2 240 20 8 8

Item

Description

84 M8X55 Carriage bolts 85 M8X25 Carriage bolts 86 M6X14L-N2 Hexagon round screw 87 M6 Nut 88 M5X8L-J1 Set screw 89 M10x8t-S2 Nut 90 20111.0t-C1 washer 91 M8X25L-N1 Hexagon socket cap screws 92 M4X10L-A1 Cross plate circular bolt 93 M4X15L-A1 Cross plate circular bolt 94 M6X16L-N3 Hexagon countersunk head screw 95 M8X16L-N1 Hexagon socket cap screws 96 M10X50 Set screw 97 8X20-N Set screw 98 126.61.0t-C1 Washer 99 M6X50L-N1Hexagon socket cap screws 100 M6X6t-S1 locknut 101 6001 Bearing 102 M8X16L-N3 Hexagon countersunk head screw 103 M6X15L-N1Hexagon socket cap screws 104 M12X35 Set screw 105 M8X35L-N1 Hexagon socket cap screws 106 M10 Hexagonal Ram 107 105.51.0t-C1 Washer 108 M8X40L-N3 Hexagon countersunk head screw 109 M6X10L-N2 Hexagon round screw 110 TZ06-SP03-0603 right front cover 111 TZ06-SP03-0604 right behind cover

20

QTY
2 6 1 1 8 3 32 16 1 2 8 7 1 1 8 1 1 2 1 5 1 1 6 240 2 1 1 1

Item

Description

112 TZ06-SP03-0605 Right side trim strip 113 TZ06-SP03-0606 Right side protecting case 114 TZ06-SP03-0611 Decorative ring 115 TZ06-SP03-0607 left front cover 116 TZ06-SP03-0608 left back cover 117 TZ06-SP03-0616 Console 118 TZ06-SP03-0609 Left side trim strip 119 TZ06-SP03-0610 Left side protecting case 120 40 rubber 121 Counter magnet

QTY
1 1 2 1 1 1 1 1 2 1

21
