FNDR-BRK-13 Harley-Davidson Custom Front Fender
Product Information
The Harley-Davidson Custom Front Fender is designed for Softail
Breakout FXBS, FXBR, and FXBRS models from 2013 to 2022. This front
fender is handmade using fiberglass and comes with a black gelcoat
finish. Please note that the gelcoat finish is not the final
coating and will require additional top-coating, such as paint, for
final use. Minor surface imperfections and scuffs may occur during
the manufacturing process and shipping, but these are considered
normal. The gelcoat finish will need to be scuffed for proper
preparation before applying the final top-coat.
This product is manufactured in Europe by Killer Custom. For any
questions regarding the installation of this product, please
contact the Killer Custom technical department at
[email protected]. It is important to mention that Killer
Custom assumes no responsibility or liability for any damage or
injury resulting from the use or misuse of their products.
Product Usage Instructions
- Before, during, and after installation, carefully check all
clearances. It is crucial to ensure that all parts fit properly
before painting. - Remove the original equipment manufacturer (OEM) fender from
your motorcycle. - Place the new front fender on your motorcycle. The front edge
of the fender has a rounded 2 mm radius. - Adjust the position of the fender using the included spacers
between the shock and the fender. Bolt it securely in place. - For 2013-2017 Breakout models, the front fender is offset. Use
the longer spacers and bolts on one side to accommodate this
offset. - The fender has predrilled holes, but in some cases, you may
need to adjust the shape or position of these holes to ensure
proper fitment. - Use thread locker glue (not included) on all threaded
connections during installation. - After completing the installation, perform a test drive to
ensure that everything is working perfectly.
Note: Installing this kit requires detailed
knowledge of the motorcycle model and mechanics. It is assumed that
the installer has access to the proper tools and a working
knowledge of them and factory service manuals. Before painting the
parts, ensure that they are properly adjusted and fitted on the
motorcycle. Killer Custom will not be responsible for any fitment
issues that arise after painting.
For more information, visit www.killercustom.com.
ASSEMBLY INSTRUCTIONS
HARLEY-DAVIDSON CUSTOM FRONT FENDER 2013-2022 FOR SOFTAIL BREAKOUT FXBS FXBR FXBRS
FNDR-BRK-13, FNDR-BRK-18
These parts are handmade of fiberglass come with a black gelcoat finish. This coating is not final use coating and will need to be top -coated (such as paint) for final use. Minor surface imperfections and scuffs are normal and may happen during taking parts out of the mold and shipping. This is allowable as the coating will need to be scuffed for final top-coat preparation.
For questions pertaining to the installation of this product, please contact our Killer Custom technical department at [email protected]. This product is manufactured in Europe by Killer Custom
NOTE: Killer Custom assumes no responsibility or liability for damage or injury of any kind arising out of the use or misuse of any products.
1. Check all clearances before, during and after installation. Warning: check the fitment of all parts before painting!
2. Remove the OEM fender from your motorcycle. 3. Put your new front fender on your motorcycle. The front edge of the fender is rounded to 2 mm radius.
Adjust its position with the included spacers between the shock and the fender and bolt it on. 4. On the 2013-2017 Breakouts the font fender is offset so you need to use the longer spacers and bolts
on one side. 5. There are predrilled holes on the fender, in some cases you may need to adjust the holes’ shape or
position. 6. Use the thread locker glue (not included) for all treaded connections on the motorcycle and the
installation is complete. 7. After the installation make a test drive to be sure everything is working perfectly.
NOTE: Installation of this kit requires detailed knowledge of the motorcycle model and mechanics. It is assumed that the installer has access to the proper tools and a working knowledge of them and factory service manuals. Before the painting the parts first you have to put those on the motorcycle and make sure that everything is adjusted and fits perfectly. Killer Custom will not be responsible for any fitment issues after paint.
WWW.KILLERCUSTOM.COM
