Standard Dualie Mudguards
Product Information: Rungu Rear Mudguard
The Rungu Rear Mudguard is an accessory designed to install onto
the Rungu Dualie Standard and Rungu Juggernaut bicycles. It
replaces the cargo rack and helps prevent mud and water from
splashing onto the rider’s back while riding in wet conditions. The
mudguard attaches to the seatpost and is adjustable to fit the
rider’s preferences.
Tools Required:
- 3 mm wrench
Preparing the Mudguard:
- Unlatch and open the grip to prepare the mudguard for
installation.
Adjusting Seatpost Grip:
- To ensure a tight grip on the seatpost, adjust the quick
release lever by rotating it clockwise to tighten and
counterclockwise to loosen. - Repeat the process until the mud flap grips the seatpost
securely.
Adjusting the Mudguard:
- Use a 3 mm wrench to loosen and re-tighten the pivot points to
adjust the attitude of the mudguard and height off the rear
wheel. - Rungu recommends tilting the mudguard toward the front
(clockwise) for better protection. - Experiment with adjustments to find what works best for
you.
V1.0
Rungu Rear Mudguard installation
rungu® rear mudguard installation
The Rungu Rear mudguard installs onto Rungu Dualie Standard and Rungu Juggernaut in lieu of a cargo rack to keep mud and water from striping your back while riding in wet conditions.
Copyright 2022 Standard Bearer Machines, LLC
Page 1 of 4
V1.0
Rungu Rear Mudguard installation
Contents
Tools required …………………………………………………………………………………………………………………………….. 2 Preparing the mudguard………………………………………………………………………………………………………………. 2 Adjusting seatpost grip ………………………………………………………………………………………………………………… 3 Adjusting the mudguard ………………………………………………………………………………………………………………. 4
Tools required
· 3 mm wrench (for adjustment)
Preparing the mudguard
The rear mudguard attaches to the seatpost. To prepare the mudguard, unlatch and open the grip.
Copyright 2022 Standard Bearer Machines, LLC
Page 2 of 4
V1.0
Rungu Rear Mudguard installation
Adjusting seatpost grip
The mudguard should have a tight grip on the seatpost so it doesn’t rotate side to side. To adjust the grip, open the grip and rotate the quick release lever clockwise to tighten and counterclockwise to loosen.
Repeat the process until you’re satisfied with how the mud flap grips the seatpost.
Copyright 2022 Standard Bearer Machines, LLC
Page 3 of 4
V1.0
Rungu Rear Mudguard installation
Adjusting the mudguard
Use a 3 mm wrench to loosen and re-tighten the pivot points to adjust the attitude (in the aeronautical sense) of the mudguard and height off the rear wheel so that it is 1″-2″ above the rear tire. Rungu recommends tilting the mudguard toward to the front (clockwise) for better protection. Experiment with adjustments to find what works best for you.
