Dongguan Pc369a Wireless Keyboard User Manual

Dongguan PC369A Wireless Keyboard

PACKING LIST

1. Keyboard xl

2. USB Receiver x 7
   (Stored in battery compartment)

3. User Manual xl


INSTRUCTIONS

Initial use

1. Put 2 x 15V AAA dry cell batteries into the keyboard according to the correct polarity and turn on the keyboard switch.
2. Take out the receiver from the battery compartment and plug it into the USB port of your laptop.
3. Wait for the computer to install the drive automatically. and you can use the product after that.

MODE SWITCH

BT1 ( Bluetooth) Mode

1. Short press BT1 mode switch button and its indicator will flash slowly showing that the keyboard is in BT1 mode.
2. Long press BT1mode switch button for 3s to 5s and its indicator will flash quickly showing that the keyboard enters pairing state. Turn on the Bluetooth of your laptop, if your computer system is Win 7 or earlier. please select to connect “813.0 Keyboard” lfyot.1r computer system is Win 8 or later, please select to connect “BTS.O KB”, You can start using it after successful connection.

BT2 Mode

Please refer to BT1 connection instructions.

DIAGRAM

1. Multi-mode Switch:: The product supports 2.4G, BT7 and BT2 connection. It can be connected with and control 3 devices User can switch modes via the corresponding mode switch button to control the corresponding device.
   a. Press the 2.4G mode button . the 2.4G mode indicator light turns on, indicating that the keyboard is 2.4G control mode at this time.
   b. Press the BT1 mode button  the BT7 mode indicator light turns on. indicating that the keyboard is switched to BT1 control mode.
   c. Press the BT2 mode button , the BT2 mode indicator light turns on, indicating that the keyboard is switched to BT2 control mode.
2. Dual system function compatibility: This product is automatically compatible with both Mac and Windows systems.
3. Full-size card slot (bracket) design: The full-size card slot on top easily holds a mobile device such as a phone or tablet and maintains the right angle for reading as you type.

Key combination function

FN+

Lock F1~12 function, after locking, press F1~F12 directly for the combination key function.

Press FN+ again

Unlock F1~F12 function, restore F1~F12 to normal function.

Solution to Keyboard’s 2.4Ci mode connection issue

1. Tum the keyboard switch off and then tum it back on and switch the keyboard to 24G mode.
2. Press the “ESC” + “=” button and re loose until the indicator of  2.4C mode flashes.
3. Plug the receiver into the computer. It is successfully connected when the indicator of 2.4G mode stops flashing. It can work then.

Solution to keyboard’s BT1 ( Bluetooth) mode connection issue

1. Clear the Bluetooth connection list of computer.
2. Tum on the power switch and switch it to BT1 mode
3. Long press the button of BT1 mode for over 3s and release until its indicator light flashes.
4. Turn on the Bluetooth of computer. If your computer system is Win 7 or earlier, please select to connect “BT3.0 Keyboard”. If your computer system is Win 8 or later, please select to connect “BT5.0 KB”. The keyboard’s BT1 mode can work after successful connection.
   BT2 (Bluetooth) Mode: refer to BT1 mode solutions.

The keyboard response is delayed and works abnormally, how to solve it?

1. May be the dry battery power is insufficient. please replace the battery for the keyboard.
2. May be caused by computer lag. please restart the computer and try it again.
3. The maximum use distance of this product is 10 M, please keep it within 10 M, and do not have metal obstacles between the keyboard and receiver.

FCC Warning

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the  interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

The device has been evaluated to meet general RF exposure requirement.
