Outbreak Double Swag 1550 Camping Tent

OUTBREAK USER MANUAL

Product Information

The OUTBREAK is a swag that can be set up with an optional
flysheet. It comes with body poles, a ridgepole, and anchor pegs.
The optional flysheet has an awning on one side and needs to be
purchased separately. The swag has gusseted windows on each side
that can be unzipped, and tensioned with guy ropes and
tensioners.

Product Usage Instructions

1. Lay out the OUTBREAK and peg out the corners indicated in the
   manual. Anchor the pegs halfway at this point.
2. Identify the body poles.
3. Insert one body pole over the pin and rings. Attach only the
   top two clips.
4. Repeat step 3 for the second body pole. Attach all pole clips
   and alternate from left to right to keep pole tension
   balanced.
5. Fit the ridgepole by inserting spigots into holes at the peak
   of the body poles. Tension using the trigger lock. Attach two pole
   clips.
6. Anchor the pegs completely, but ensure not to overhit the pegs
   as it may affect swag stitching holding pin/ring loops.
7. Unzip the external zips on each side of the gusseted windows
   and peg out. Tension guy ropes with tensioner and repeat for the
   other side.
8. If you have purchased the optional flysheet, orientate it to
   suit and place it over the swag. Attach four hook and loop straps
   on each corner to the OUTBREAK body poles and four shock cord hooks
   on each corner to the upper side pole clip.

Your OUTBREAK swag is now set up and ready to use.

TM
OUTBREAK USER MANUAL

TM
OUTBREAK SETUP MANUAL

1. Lay out OUTBREAK and peg out
corners indicated below. Only anchor
pegs half way at this point.

2. Identify poles

3. Insert 1 x body pole over pin & rings. Attach top 2 clips only.
1

OUTBREAK SETUP MANUAL
4. Repeat step 3 for second body pole.
Attach all pole clips. Alternate from left to right to keep pole tension balanced.
5. Fit Ridgepole by inserting spigots into holes at peak of body poles. Tension using
trigger lock. Attach 2 x pole clips.
6. Anchor pegs completely.
WARNING: Cease hitting peg once peg hook reaches swag ring. Overhitting will affect swag stitching holding pin/ring loops.
2

OUTBREAK SETUP MANUAL
7. Unzip external zips on each side of the gusseted windows and peg out. Tension guy
ropes with tensioner pictured below. Repeat for windopw other side.
8. Swag set up complete
3

OUTBREAK SETUP MANUAL
OPTIONAL FLYSHEET 1. The optional flysheet has an awning on one side. Orientate this to suit.

*awning poles sold seperatley

2. Place flysheet over swag and attach 4 x hook & loop straps on each corner to
OUTBREAK body poles (fig.1) Attach 4 x shock cord hooks on each corner to upper side pole clip (fig. 2)

fig. 1

fig. 2

4

OUTBREAK SETUP MANUAL
3. Swag set up complete
WARRANTY 23ZERO will replace or repair any product at its discretion that is subject to faulty manufacturing or workmanship including materials. Exclusions The above warranty is limited to manufacturing and materials defects. Not including damage caused by misuse or abuse, wear and tear, condensation, extreme weather, accidents, incorrect set up, damage caused by mould, insects, animals or children. This also excludes broken poles and damage caused by a jammed, snagged zipper or excessive force applied to zipper causing failure. Consumer rights Our goods come with guarantees that cannot be excluded under Australian law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if the goods fail to be of acceptable quality and failure does not amount to a major failure. * Due to our policy of continual product development, the specifications, colours and features may vary. Making a claim To make a claim in relation to the above manufacturers warranty please ensure you retain your sales receipt of purchase. Please email us at [email protected] with photos of the your claim, purchase reciept and contact details. If you require additional assistance, please phone 03 9547 4691 to discuss and arrange your claim. Product subject to warranty will be sent to 23ZERO Australia, 32b Eileen St Clayton South, Victoria 3169. All freight costs associated with return of product for assessment is payable by consumer.
5
