SCNAC-01 Sealing Cover

Product Information

The product is a set of rubber covers for power in and power out
connections. It includes four different covers: SCNAC-01 D-Size
Rubber Cover power in, SCNAC-02 D-Size Rubber Cover power out,
SCNAC-03 G-Size Rubber Cover power out, and SCNAC-04 Combination
Rubber Cover power in/power out. These covers are used to protect
the connectors from dust and damage.

The product is manufactured by Neutrik, a company that
specializes in audio and video connectors. Neutrik has offices in
different countries including the USA, UK, France, Japan, and Hong
Kong. The product is designed to be used with chassis connectors
and screws with a tightening torque of MA = 40 Ncm.

Product Usage Instructions

1. Choose the appropriate rubber cover based on your power in/out
   needs.
2. Assemble the rubber cover onto the chassis from the rear side
   as shown in the example of rubber cover assembly.
3. Put the chassis onto the front panel.
4. Tighten the screws using a torque of MA = 40 Ncm.
5. Repeat the process for the other end of the connection if
   needed.
6. For more details, visit www.neutrik.com.

R
ASSEMBLY INSTRUCTION

SCNAC-01 I D-Size Rubber Cover “power in” SCNAC-02 I D-Size Rubber Cover “power out” SCNAC-03 I G-Size Rubber Cover “power out” SCNAC-04 I Combination Rubber Cover “power in”/”power out”

EXAMPLE OF RUBBER COVER ASSEMBLY

SCNAC-01 D-Size Rubber Cover “power in”

A Assemble the rubber cover onto the chassis from the rear side as shown.
B Put the chassis onto the front panel. C Tighten the screws.

Rubber Cover SCNAC-*

Equipment / Panel

SCNAC-02 D-Size Rubber Cover “power out”

Chassis Connector

SCNAC-03 G-Size Rubber Cover “power out”

Screws
AT T E N T I O N : Tightening torque MA = 40 Ncm

SCNAC-04 Combination Rubber Cover “power in” / “power out”

Find more details on www.neutrik.com

Neutrik AG Neutrik Americas Inc. Neutrik (UK) Ltd. Neutrik Vertriebs GmbH

LI USA UK DE / NL / AT/DK

T: +423 / 237 24 24 T: +1 704 / 972 3050 T: +44 1983 / 811 441 T: +49 8131 / 280 890

F: +423 / 232 53 93 F: +1 704 / 438 9202 F: +44 1983 / 811 439 F: +49 8131 / 280 830

Neutrik France

FR

Neutrik Tokyo Ltd.

JP

Neutrik Hong Kong Ltd. HK

T: +33 1 / 4131 6750 T: +81 3 / 3663 4733 T: +852 / 2687 6055

F: +33 1 / 4131 0511 F: +81 3 / 3663 4796 F: +852 / 2687 6052

I I Draft. Nr.: BDA 643 V1 Update: 2022-04-08 Data subject to change without prior notice. © 2022 NEUTRIK®. NEUTRIK® are registered trademark of Neutrik AG. ALL RIGHTS RESERVED.

R
www.neutrik.com
