ONE Autonomous Robotic Field Painter for All Sports
Product Information: Turf Tank One
Turf Tank One is a robotic line painter that is designed to
paint perfect lines on a field while saving time and money. It
comes with a Turf Tank Tablet, Robot, and Base Station that are
powered by batteries. The product has various components such as
Indicator Light On/Off Switch, Emergency Stop, Rover Battery/Paint
Compartment Shields (Pair), Rear Wheel, Front Wheel, Front Bumper
Disc-Width Adjustment Knob, Sprayer-Height Adjustment Knob, Spray
Discs, Sprayer Assembly (Solenoid), Robot Antenna, Back Bumper,
Solenoid Power Wire, Paint Tube and Base Station Antenna.
Product Usage Instructions: Turf Tank One
Before using the Turf Tank One, follow the below
instructions:
- Verify the contents of the crate against the crate
checklist. - Charge up your Turf Tank Tablet, Robot, and Base Station
batteries for 8 to 10 hours. - Relax and wait for the Field Operations Engineer to schedule
your onsite installation and training.
To get familiar with the product, you can follow the below
instructions:
- Get to know the Rover and its components such as Rear Wheel,
Front Wheel, Front Bumper Disc-Width Adjustment Knob,
Sprayer-Height Adjustment Knob, Spray Discs, Sprayer Assembly
(Solenoid), Robot Antenna and Back Bumper. - Get to know the Paint System and its components such as
Disc-Width Adjustment Knob, Spray Shield Adjustment Knob, Spray
Shield, Sprayer Assembly, Quick Fan Cap Spray Nozzle and Spray
Discs. - Get to know the Base Station and its components such as Pole
Battery, Base Station Antenna, Power Cable, Prism Pole, Power
Indicator Lights, View Capacity Button, Power Port, LP-E6 Battery
in compartment lid, ComNav, Information Panel, Power Button, Serial
Number QR Code, Antenna Port, Battery Cover A and B and Charging
Port.
To place the Base Station, follow the below instructions:
- Determine where to place your Base Station. You will place the
Base Station in this spot every time you paint. - Install a Turf Tank Ground Spike (or other semi-permanent
marker) in the selected spot. - Place the Tripod so that the Prism Pole (center pole of Tripod)
rests in the installed Ground Spike. - Ensure the Tripod’s level bubble is centered. Make sure the
Tripod is level throughout operation. - Attach the large antenna (12 in) found in the accessory box to
the Base Station. - Holding the Base Station steady, attach the Prism Pole or Pole
Battery.
Important Note: Do not turn on the Base Station before attaching
it to Prism Pole.
If you face any issues or have questions, you can get help from
a Robot Expert by calling or texting at 770-818-6020. You can also
visit support.turftank.com for product manuals and more help.
WELCOME TO
THANK YOU FOR ADDING TURF TANK ONE TO YOUR STARTING LINEUP!
Get ready to paint perfect lines while saving money and time. Your Field Operations Engineer will schedule your onsite installation and training to provide all the tools you’ll need to get up and running. Right now, there are three things you can do to get ready:
1 Verify the contents of the crate against the crate checklist. 2 Charge up your Turf Tank Tablet, Robot, and Base Station
batteries.
3 Relax. We got you.
That’s it!
Questions? Get help from a Robot Expert. Call or text: 770-818-6020
GET TO KNOW
Indicator Light On/Off Switch
Emergency Stop
Rover Battery/Paint Compartment Shields (Pair)
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Rover
Rear Wheel Front Wheel
Front Bumper Disc-Width Adjustment Knob
Sprayer-Height Adjustment Knob Spray Discs Sprayer Assembly (Solenoid) Robot Antenna Back Bumper
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
GET TO KNOW
Solenoid Power Wire Paint Tube
Front Bumper
PAINT SYSTEM
Disc-Width Adjustment Knob
Spray Shield Adjustment Knob
Spray Shield Sprayer Assembly
Quick Fan Cap Spray Nozzle
Spray Discs
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
GET TO KNOW
Base Station
BASE STATION
Pole Battery
8 to 10 hours battery life.
Base Station Antenna
Power Cable
Prism Pole
Power Indicator
Lights
Pole Battery
View Capacity Button
Power Port
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
GET TO KNOW
LP-E6 Battery in compartment lid.
BASE STATION
LP-E6 Battery
1½ hours battery life each.
Match battery polarity to lid.
Battery Compartment B Battery Compartment A LP-E6 Batteries
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
GET TO KNOW
BASE STATION
ComNav
Information Panel Power Button Serial Number QR Code Antenna Port
Battery Cover B
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Position Button
Position Light
Key to Information Panel Symbols Serial Number and Product Number
Prism Pole/ Pole Battery Attachment Port
Battery Cover A
Charging Port
Match red dot on cable to red line on charging port.
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
BASE STATION PLACEMENT
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
1 Determine where to place your
Base Station. You will place the Base Station in this spot every time you paint.
2 Install a Turf Tank Ground Spike
(or other semi-permanent marker) in the selected spot.
3 Place the Tripod so that the Prism
Pole (center pole of Tripod) rests in the installed Ground Spike.
4 Ensure the Tripod’s level bubble is
centered. Make sure the Tripod is level throughout operation.
5 Attach the large antenna (12 in)
found in the accessory box to the Base Station.
6 Holding the Base Station steady,
attach the Prism Pole or Pole Battery.
DO NOT TURN ON BASE STATION BEFORE ATTACHING TO PRISM POLE!
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
USE AN EXISTING BASE STATION POSITION
1 Turn on the Base Station by
pressing the Power button.
2 On startup, the Base Station
automatically searches for Saved Position. The orange Position light flashes to indicate the search.
3 When the Base Station has
found a Saved Position, it will:
Show a solid orange Position Light. Show a flashing blue Transmission Light. Emit five beeping sounds.
4 If the Base Station does not
detect a Saved Position, it will:
Show no orange Position Light. Show no blue Transmission Light. Emit a five-second continuous error tone.
Pole Battery Height
Markings Prism Pole
Bubble Level
Tripod
8 to 12 ft
To search for a Saved Position at any time other than startup, press the Position button.
Ground Spike
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
CREATE A BASE STATION POSITION
LEAVE AT LEAST 30 YARDS BETWEEN MULTIPLE SAVED POSITIONS.
1 Turn on the Base Station by
pressing the Power button.
2 Press and hold the Position
Button until you hear a short beep from the Base Station.
3 Signs you have created a
Saved Position:
The orange Position Light is lit and steady. The blue Transmission Light is flashing. The Base Station emits five beeping sounds.
4 Once a Saved Position has
been successfully created, you must turn the Base Station power off and turn it on again. The Base Station is now ready to use.
You must power cycle the Base Station EVERY TIME you set a new position.
5 Raise the Base Station on the
Prism pole 10-12 feet to its operational height.
You are ready to create your field plans!
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
PAINT: CONCENTRATE
Best Practices for Mixing Robot Paint:
These are general guidelines. Contact Turf Tank Support or your Field Operations Engineer for brand-specific instructions.
1 Pour water into an empty 5.5
gallon jug:
For a mix ratio of 4:1 (bright) use four gallons of water.
For a mix ratio of 3:1 (brighter) use three gallons of water.
2 Pour one gallon of paint
concentrate into the jug.
3 Mix with drill bit for at least
90 seconds or up to two full minutes for even pigment dispersal.
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
PAINT: RTS
(READY TO SPRAY)
Instructions:
SHAKE AND GO!
Shake vigorously or use drill mixer bit for 30 seconds and you’re ready to paint!
Cone Nozzle
Flat Fan Nozzle
USE LESS PAINT!
Ideal for: General purpose sports, rounded edges
CUSTOM RESULTS!
Ideal for: Football hashes, logos, sharp edges
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
Something not right? Questions? Get help from a Robot Expert. Call or text: 770-818-6020
BASIC TROUBLESHOOTING
Robot, Tablet, or Base Station not working as they should? Check the following first:
1 Are the batteries in the Tablet, the Robot, and for the Base Station fully charged?
2 Is the Robot’s battery seated properly in its compartment? Is the compartment latch locked?
3 Are the antennas attached to the Base Station and the Robot?
4 Is the Emergency Stop button engaged? Are the Bumper stop mechanisms engaged?
5 Is the Tablet connected to the Robot’s WiFi? Is the Robot connected to the App (does the Robot appear in the App)? Is the WiFi blocked?
6 Is the Tablet receiving a cellular signal? Is Roaming Data turned on? Is the cellular signal strong? Do 4G and R appear above the cell signal indicator on the Tablet?
7 Reboot the Robot and the Tablet. Shut them down completely, then power up again.
Still having trouble?
Call or text 770-818-6020 for help.
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
IMPORTANT DAILY TASKS
Charge batteries EVERY DAY.
Charge Robot Batteries. Charge the Tablet. Charge the Base Station batteries (Pole Battery or LP-E6 batteries).
Monitor battery life on the Tablet, Robot, and Base Station.
If you paint multiple fields a day, consider upgrading to a Pole Battery or buying additional LP-E6 batteries. For best performance and to prevent damage, keep batteries on all components above 25% charge.
Check the field you are painting for obstacles or bad field condition. Clean Robot thoroughly after EVERY use.
Remove Quick Fan Cap, Spray Nozzle, Gasket, and Chamber Reducer. Wash them all with warm water. Run warm (not hot) water through the Paint System (hoses, pump, sprayer) until clear. Remove the Mesh Filter from the housing on the tube in the Paint System and wash it in warm water.
GO TO SUPPORT.TURFTANK.COM FOR PRODUCT MANUALS AND MORE HELP
