SHV88C73N 24 Inch Custom Panel Dishwasher
Product Information
The 24 Custom Panel Dishwasher with model number SHV88C73N from
Bosch comes with a PowerControlTM spray arm that ensures a deeper
clean for your dishes, even when loaded on the bottom rack. The
dishwasher features patented CrystalDryTM technology that
transforms moisture into heat, resulting in 60% drier dishes,
including plastics. It has a wash system with five-level wash and a
drying system with CrystalDryTM. The dishwasher has a third rack, a
Smart Load 3rd Rack, and is made of stainless steel. It has touch
controls and concealed water heating element. The dishwasher is
Wi-Fi enabled and has an anti-fingerprint finish. The appliance is
Tier 1 energy efficient and has a total annual energy consumption
of 239 kWh. It has a capacity of 16 place settings and uses 3.2
gallons of water per cycle.
Product Usage Instructions
Before using the dishwasher, ensure that you have read the
installation instructions carefully and have the required mounting
hardware in place. The dishwasher comes with a pre-connected drain
hose, toe-kick, and power cord (3-prong plug). The recommended
custom door panel thickness for the dishwasher is 3/4 inches (20
mm).
To use the dishwasher:
- Load the dishes according to the dishwasher manual. The
PowerControlTM spray arm ensures a deeper clean even when dishes
are loaded on the bottom rack. - Select the appropriate wash cycle and options using the touch
controls. - Start the dishwasher by pressing the start button.
- After the wash cycle is complete, unload the dishes
carefully.
For best results, it is recommended that you use Bosch
accessories, cleaners, and parts. Bosch accessories are available
on the Bosch website or by calling 1-800-944-2904 (Mon to Fri 5 am
to 6 pm PST, Sat 6 am to 3 pm PST).
24″ Custom Panel Dishwasher
800 Premium Custom Panel SHV88C73N
SHV88C73N Custom Panel
PowerControlTM spray
arm targets your dirtiest
dishes with a deeper
clean, no matter where
you load them on the
bottom rack.
Features & Benefits
Patented CrystalDryTM technology transforms moisture into heat to get dishes, including plastics, 60% drier.
The Smart Load 3rd rack has portable inserts with ample cutlery storage and capacity for deeper items like cereal bowls. Together with Rackmatic®, it’s the ultimate in flexibility.
Enhance your cleaning experience with Wi-Fi enabled Home Connect®. Access additional wash cycles and options or choose the right one for your needs using Smart Cycle.
So quiet at 40 dBA, TimeLight® shines time remaining on the floor so you know the dishwasher is running.
General Properties
Number of wash cycles 5 + 3 additional in Home Connect®
Number of options
4 + 2 additional in Home Connect®
dBA
40
Wash system
PowerControlTM with PrecisionWash®
Drying system
CrystalDryTM
Third rack
Smart Load 3rd Rack
Rack adjustability
Rackmatic®
Tub material
Stainless Steel
Control type
Touch Controls
Concealed water
Yes
heating element
Leak protection system 24/7 AquaStop®
Home Connect®
Yes
(WiFi enabled)
NSF®-certified** sanitize Yes option
Water softener
No
Five-level wash
Yes
Child Lock button
No
suspension
Anti-Fingerprint Finish N/A
Special features
CrystalDryTM Option, TimeLight®
Efficiency
Water usage per cycle 3.2
Energy efficiency class Tier 1
ENERGY STAR® qualified Yes
Total annual energy consumption
239 kWh
Capacity
Number of place settings 16
Technical Details
Watts
1440 W
Current
12 Amps
Volts
120 V
Frequency
60 Hz
Power cord full length 67″
Power cord install length Left 45″ from edge of unit when Right 56″ facing the door
Minimum water pressure 14 lb/sin
Length outlet hose
79″
Dimensions & Weight
Overall appliance dimensions (HxWxD)
33 7/8″ x 23 9/16″ x 23 1/16″
Required cutout size (HxWxD)
33 7/8″ x 24″ x 24″
Adjustable feet
Yes
Net weight
111 lbs
Accessories–Optional
Junction Box
SMZPCJB1UC
Junction Box + Supply SMZ3IN1UC Hose Kit
Bosch Dishwasher Water SMZSH002UC Supply Hose
Drain Hose Extension Kit SGZ1010UC
Dishwasher Accessory SMZ5000 Kit
Anti-Tarnish Silverware SMZ5002UC Cassette
Edge Protector + Power SMZEPCC1UC Cord Clip Install Kit
Based on aggregate average drying performance of Bosch Dishwashers with CrystalDryTM on combined household load including plastics, glass, steel, and porcelain as compared to Bosch Dishwashers with PureDry®. Drying performance may vary by dish type.
*Compared to a Bosch dishwasher with 2 racks. **Certification to NSF/ANSI Standard 184 for residential dishwashers.
Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).
Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Consult the product’s installation instructions for final dimensional data and other details prior to making cutout.
Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.
For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904
© BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH.
7/22
24″ Custom Panel Dishwasher
800 Premium Custom Panel SHV88C73N
Installation Details
Included:
Pre-connected drain hose
Toe-kick
Power cord (3-prong plug)
* measured from the bottom edge of the countertop panel thickness recommended 3/4″ (20 mm). This dishwasher can accept custom door panel weights ranging from 7 to 24 lbs; however, the dishwasher comes from the factory ready for custom panel door weights from 11 to 18 lbs. If you plan on using a door panel that is not 11 to 18 lbs. please contact customer service at (800) 944-2904.
Note: Refer to installation template for mounting hardware locations
(A)
67″ (1750) (B)
63″ (1600) (B)
45″ (1140) (C)
56″ (1422) (C)
(D) (E) (F)
A: Front view B: Drain hose C: Electrical Power Cord:
length shown according
to Installation Instructions
D: Inlet E: Drain F: Electrical
All connections are at the rear of the appliance.
Extension for drain hose available as accessory.
Junction Box for hard wired connection available
as an accessory.
Measurements in inches (mm)
Ø 2 1/2″ (63.5 mm)
7″ (178 mm)
Note: Cutout required on left or right cabinet wall, depending on location of water inlet, drain and electrical connection
2 1/2″ (63.5 mm)
Junction box accessory available for purchase SMZPCJB1UC (not included)
Example of Hardwire Installation
Ø 2 1/2″ (63.5 mm)
7″ (178 mm)
Note: Cutout required on left or right cabinet wall, depending on location of water inlet, drain and electrical connection
2 1/2″ (63.5 mm)
3-prong power cord
included
Example of an Electrical Receptacle Installation
Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).
Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Consult the product’s installation instructions for final dimensional data and other details prior to making cutout.
Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.
For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904
© BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH.
7/22
24″ Custom Panel Dishwasher
800 Premium Custom Panel SHV88C73N
Installation Details
Non-metallic tie
Non-metallic tie
Remove plug
Note: Plumbing installations will vary – refer to local codes. Drain hose included is 79″ (201 cm) and can be extended to a maximum of 155 3/4″ (396 cm).
Always use the approved drain hose extension kit (SGZ1010UC).
Ensure a portion of the drain hose is raised between min. 33″ (84 cm) and max. 43″ (110 cm) above the cabinet floor.
min 33″ (84 cm) max 43″ (110 cm) min 33″ (84 cm) max 43″ (110 cm)
