C350 Capacitance Meter

Product Information

The GME Test Instruments Model C350 Capacitance Meter is a
reliable and durable device designed for accurate capacitance
measurements. It features a large LCD screen with backlight,
allowing for clear and easy readings even in bright ambient light
conditions. The LSI-circuit ensures high reliability and
durability, while the input overload protection prevents damage to
the device.

The meter is lightweight and compact, making it easy to operate.
It has a range of 0.1pF to 20000uF, with single 9 position and
whole range value options. The device has manual zero adjustment
with a range of 20pF, and panel zero adjustment for
calibration.

The meter has a sampling time of 0-5 seconds, operates in
temperatures between 0 to 40 degrees Celsius, and can function
under humidity levels of up to 80% MAX.R.H. It is powered by a
single standard 9V battery (NEDA 1604IEC6F22) with a battery life
of approximately 200 hours (basicity type) or 100 hours
(zinc-carbon type). The device also comes with test alligator clips
(red & black) and an instruction manual as standard
accessories.

Product Usage Instructions

Insert a single standard 9V battery into the device.
Connect the test alligator clips (red & black) to the
device’s input terminals.
Turn on the device using the power button.
Select the desired range using the rotary switch.
For accurate measurements, adjust the zero level using the
manual zero adjustment or panel zero adjustment option.
Place the device near the object to be measured and press the
HOLD button to take a reading.
The LCD screen will display the capacitance measurement in the
selected unit (pF, nF, or uF).
After use, turn off the device using the power button to
conserve battery life.

View Fullscreen

GME
TEST INSTRUMENTS

Model C350
Capacitance Meter

FEATURES Large LCD screen with backlight High measuring accuracy Measurements possible even under a strong magnetic field LSI-circuit provides high reliability and durability Input overload protection LCD display for low power consumption and clear readout even in bright ambient light
conditions Light-weight and compact construction for easy operation Low battery indication

SPECIFICATIONS

Display:

LCD (Liquid Crystal Display) Max. Indication 1999.

Measurement: C (Capacitance)

Range:

Single 9 position, whole range value (from 0.1pF to 20000uF)

Zero Adjustment: Manual (range:20pF)

Calibrate Adjustment: Panel Zero adjustment

Over-input Display: Display shows “1”

Backlight Function: Automatically turns off after 8 seconds

Sampling Time:

0~5second
