HONDA SERIES NC 750 X ’21
H0NC714P
1
262600 x 1→
262601 x 1←
2
304053 x 4
M8x30 DIN 7380
3
303027 x 12
∅8
4
262963 x 1→
262964 x 1←
5
304081 x 4
M8x20 DIN 7380
6
303045 x 8
∅8
7
261072 x 4
∅20 ∅9 x 32
8
304169 x 4
M8x50 DIN 7380
9
262965 x1
10
304052 x2
M6x20 DIN 7380
11
303017 x 4
∅6
12
302021 x 2
M6
WARNING!
Do not fully tighten the screws until it is ensured that the KIT is correctly attached and aligned.
IMPORTANT: Based on European models.
For compatibility with models in other continents, check www.shad.es
TOP MASTER + 4P SYSTEM
REF. 500479 Edition 1a
