Lowell Lt2-810-72-bb Lay In Tile Ceiling Loudspeaker Instruction Manual

LT2-810-72-BB Lay in Tile Ceiling Loudspeaker

Product Information:

Model No: LT2-810-72-BB

Product Name: Lay-in Tile Ceiling Loudspeaker

Features:

• Quick installation in suspended lay-in tile ceilings
• Replaces a 2×2 ceiling tile
• 8-inch 15W dual cone driver
• 25V/70V dual voltage transformer
• 2×2 white grille with black subplate
• 0.147 cu.ft. enclosure
• Ideal for commercial paging and/or background music
• Dual voltage transformer with primary taps at 0.25, 0.5, 1, 2,
  and 5W
• Backbox is offset on the 2×2 grille assembly to accommodate
  plenum obstructions
• Metal clamp for fast connections

Product Usage Instructions:

1. Ensure that the suspended lay-in tile ceiling is suitable for
   installation.
2. Remove the existing 2×2 ceiling tile from the desired
   location.
3. Place the LT2-810-72-BB loudspeaker assembly in the empty
   space, aligning it with the surrounding tiles.
4. If there are any obstructions in the plenum, adjust the backbox
   offset to accommodate them.
5. Connect the wires to the driver leads of the loudspeaker. Use a
   screwdriver to bend the restraint tabs up for code compliance
   tie-offs.
6. Insert the connected wires inside the enclosure and tighten the
   metal clamp for secure connections.
7. If necessary, adjust the transformer settings by selecting the
   appropriate primary tap for the desired power output (0.25, 0.5, 1,
   2, or 5W).
8. Replace the 2×2 grille with the LT2-810-72-BB white grille with
   black subplate.
9. If further control is required, use the knob on
   LT2-810-72-BB-VC model to adjust the volume.

Note: For additional technical specifications and driver
information, refer to the product spec sheet.

Model No.
LT2-810-72-BB
Lay-in Tile Ceiling Loudspeaker
INCLUDES: · 8-inch 15W dual cone driver · 25V/70V dual-voltage transformer · 2×2 grille with subplate · 0.147 cu.ft. enclosure
LT SERIES SPEAKERS are pro systems made for quick installation in suspended lay-in tile ceilings. The 2×2 assembly replaces a 2×2 ceiling tile. This model features an 8-inch 15W dual cone driver, 25V/70V dual voltage transformer, 2×2 white grille with black subplate and 0.147 cu.ft. enclosure.

FEATURES
PERFORMANCE: This model is ideal for applications providing commercial paging and/or background music.
DRIVER (810): The 8-inch 15W dual cone driver with 10 oz. magnet provides a step up in full range performance from the commercial industry standard, delivering solid performance and value for paging and/or background music applications that require clear communications. ­ Driver magnet: 10 oz. ceramic, 3/4-inch hard fiber whizzer
cone, 1-inch voice coil, 20-gauge steel frame with zincplated finish ­ Driver weight: 2.0 lbs. ­ Driver depth: 2.84 in.
TRANSFORMER: Factory-wired dual voltage 25V/70V transformer with primary taps at 0.25, 0.5, 1, 2 and 5W.
ENCLOSURE (8XD4): Certified U.S. steel enclosure with black powder epoxy finish. ­ Volume: 0.147 cu.ft. ­ Polyurethane foam disc ­ Enclosure is offset on the 2×2 (23.75-in. x 23.75-in.) grille
assembly to accommodate above-ceiling obstructions.

INSTALLATION: ­ Assembly Dimensions: 23.75-in.L x 23.75-in.W x 4.5-in.H ­ Restraint Tabs: The assembly features four restraint tabs
for code compliance tie-offs. ­ Connections: Driver leads exit enclosure through a metal
clamp for fast connections — just splice connecting wires, push inside the enclosure, and tighten clamp.
COMPLIANCE & CERTIFICATIONS: ­ Made in the U.S.A. with certified U.S. steel and global
components.

Lowell strives to provide accurate information while reserving the right to change specifications and/or improve manufacturing methods without prior notification. ©2022 Lowell Manufacturing Co., 100 Integram Dr., Pacific MO 63069, USA / tel. 800.325.9660 / tel. 636-257-3400 / www.lowellmfg.com

Spec 1385
Model LT2-810-72-BB | Rev. 12.05.22 | pg. 1/3

FEATURES
Backbox is offset on the 2×2 grille assembly to accommodate plenum obstructions
Driver leads exit through a metal clamp for fast connections.
TECHNICAL DRAWINGS
Dimensions are provided in inches.

Mounted 8-inch 15W dual cone driver with 25V/70V transformer
Use the tip of a screwdriver to bend restraint tabs up for code compliance tie-offs.

DRIVER SPECIFICATIONS

Driver No.

Power Size Rating Type

Ceramic Magnet

Frequency Response

Dispersion @ 2000Hz(­6dB)

810

8 in. 15W dual

10 oz. 54Hz­11.6kHz (±6dB) 95 degrees

cone

50Hz­20kHz (±6.6dB)

conical

*Calculated value 1M @ driver power rating. See spec sheet for driver 810 for additional information.

Voice Coil Impedance
8 ohms

Voice Coil Diameter
1 in.

Sensitivity 1W/1M
97.9dB avg.

Max SPL*
109.7dB

Driver Depth
2.84 in.

Driver Weight
2.0 lbs.

TEST METHODOLOGIES: Lowell speaker systems are thoroughly tested to provide specifiers and contractors with accurate data. Test equipment includes the GoldLine TEF-20 analyzer.
– POWER HANDLING: specification is based on E.I.A. Standard RS-426B. – FREQUENCY RESPONSE: describes the usable response range defined by a ± 6dB window, which is useful in predictive engineering calculations. – SENSITIVITY: is a computer calculation of the log average sound pressure level (SPL) over the entire engineering bandwidth as given in the Frequency Response (±
6dB). – MAXIMUM SPL: is calculated based on the Power Handling and the measured log average Sensitivity where Maximum SPL = (Sensitivity @ 1W1M) + 10 log (Power
Handling). – DISPERSION ANGLE: is defined as the angle of coverage that is no more than 6dB down from the on-axis value averaged over the 2kHz octave band. Since
speech intelligibility is dependent upon the 2kHz octave, this specification is useful in designing voice reinforcement and music systems that provide even coverage and intelligibility. The polar plots illustrate how the system performs when hung in free space (360°) or half-space (180°) in the case of a recessed speaker.

Lowell strives to provide accurate information while reserving the right to change specifications and/or improve manufacturing methods without prior notification. ©2022 Lowell Manufacturing Co., 100 Integram Dr., Pacific MO 63069, USA / tel. 800.325.9660 / tel. 636-257-3400 / www.lowellmfg.com

Spec 1385
Model LT2-810-72-BB | Rev. 12.05.22 | pg. 2/3

A&E SPECIFICATIONS
The loudspeaker for suspended lay-in tile ceilings shall be Lowell Model LT2-810-72-BB. The 2×2 assembly shall directly replace a 2×2 ceiling tile. Each unit shall include a factory-mounted driver mounted to a subplate and fine perforation steel grille with white powder epoxy finish. The driver shall be 8-inch dual cone with 15W power rating. It shall have a magnet weight of 10 ozs., frequency response of 54Hz-11.6kHz (±6dB); 50Hz-20kHz (±6.6dB) and average sensitivity of 97.9dB measured 1W/1M. The system shall include a steel backbox (.147 cu.ft. volume) with leads exiting through a metal clamp. The 25V/70V dual voltage transformer shall feature primary taps at 0.25, 0.5, 1, 2 and 5W. The assembly shall be made in the U.S.A. with global components.

LT / LT2 SERIES OVERVIEW

Model No.

Driver

Volume

Driver Specs (measured half space)

Transformer

Taps

Enclosure Grille Control Listed Sensitivity* Frequency Response Dispersion**

LT-410-72-BB

67Hz­16kHz (±6dB) 4″ 15W single cone 25V / 70V .25, .5, 1, 2, 5W .147 cu.ft. 1 x 2 — — 90.8 dB 53Hz­20kHz (±8dB) 170°

LT-810

8″ 15W dual cone

—

54Hz­11.6kHz (±6dB)

—

—

1 x 2 — — 97.9 dB 50Hz­20kHz (±6.6dB) 95°

LT-810-72

8″ 15W dual cone 25V / 70V .25, .5, 1, 2, 5W —

54Hz­11.6kHz (±6dB) 1 x 2 — — 97.9 dB 50Hz­20kHz (±6.6dB) 95°

LT-810-BB

8″ 15W dual cone

—

54Hz­11.6kHz (±6dB)

—

.147 cu.ft. 1 x 2 — — 97.9 dB 50Hz­20kHz (±6.6dB) 95°

LT-810-72-BB

8″ 15W dual cone

25V / 70V .25, .5, 1, 2, 5W .147 cu.ft. 1 x 2 —

—

97.9 dB

54Hz­11.6kHz (±6dB) 50Hz­20kHz (±6.6dB)

95°

LT-810-72-BB-VC 8″ 15W dual cone

25V / 70V

.25, .5, 1, 2, 5W .147 cu.ft. 1 x 2 Knob —

97.9 dB

54Hz­11.6kHz (±6dB) 50Hz­20kHz (±6.6dB)

95°

LT2-810-BB

8″ 15W dual cone

T H I S LT2-810-72-BB 8″ 15W dual cone
SPEC
LT2-810-72-BB-VC 8″ 15W dual cone

–25V / 70V 25V / 70V

—

.147 cu.ft. 2 x 2 — —

.25, .5, 1, 2, 5W .147 cu.ft. 2 x 2 — —

.25, .5, 1, 2, 5W .147 cu.ft. 2 x 2 Knob —

97.9 dB 97.9 dB 97.9 dB

54Hz­11.6kHz (±6dB) 50Hz­20kHz (±6.6dB)

95°

54Hz­11.6kHz (±6dB) 50Hz­20kHz (±6.6dB) 95°

54Hz­11.6kHz (±6dB) 50Hz­20kHz (±6.6dB) 95°

LT-830-BB

8″ 20W coaxial

—

57Hz­14kHz (±6dB)

—

.147 cu.ft. 1 x 2 — — 97.0 dB 44Hz­20kHz (±7.6dB) 80°

LT-830-870-BB 8″ 20W coaxial

70V

1, 2, 4, 8W

.147 cu.ft. 1 x 2 —

—

97.0 dB

57Hz­14kHz (±6dB) 44Hz­20kHz (±7.6dB)

80°

LT2-830-T870-VB 8″ 20W coaxial

70V

1, 2, 4, 8W

.8 cu.ft.

2 x 2 —

—

97.0 dB

57Hz­14kHz (±6dB) 44Hz­20kHz (±7.6dB)

80°

LT2-830-TM16-VB 8″ 20W coaxial

70V

4, 8, 16W

.8 cu.ft.

2 x 2 —

—

97.0 dB

57Hz­14kHz (±6dB) 44Hz­20kHz (±7.6dB)

80°

LT-8A-VB

8″ 50W coaxial

—

—

.8 cu.ft.

1 x 2 —

UL

90.6 dB

40Hz­19.4kHz (±6dB) 40Hz­20kHz (±7.3dB)

90°

LT-8A-T870-VB 8″ 50W coaxial

40Hz­19.4kHz (±6dB)

70V

1.1, 2, 4, 8W .8 cu.ft. 1 x 2 — UL 90.6 dB 40Hz­20kHz (±7.3dB) 90°

LT2-8A-VB

8″ 50W coaxial

—

—

.8 cu.ft.

2 x 2 —

UL

90.6 dB

40Hz­19.4kHz (±6dB) 40Hz­20kHz (±7.3dB)

90°

LT2-8A-T870-VB 8″ 50W coaxial

70V

1.1, 2, 4, 8W

.8 cu.ft.

2 x 2 —

UL

90.6 dB

40Hz­19.4kHz (±6dB) 40Hz­20kHz (±7.3dB)

90°

LT2-8A-TM32-VB 8″ 50W coaxial

70V

8, 16, 32W

.8 cu.ft.

2 x 2 —

—

90.6 dB

40Hz­19.4kHz (±6dB) 40Hz­20kHz (±7.3dB)

90°

* Average SPL @ 1W/1M ** Conical @ 2kHz octave (­6dB)

Lowell strives to provide accurate information while reserving the right to change specifications and/or improve manufacturing methods without prior notification. ©2022 Lowell Manufacturing Co., 100 Integram Dr., Pacific MO 63069, USA / tel. 800.325.9660 / tel. 636-257-3400 / www.lowellmfg.com

Spec 1385
Model LT2-810-72-BB | Rev. 12.05.22 | pg. 3/3
