FT-AZ114-59 Freestanding Bathtub
Product Information
Product Name: Freestanding Bathtub
Model Number: FT-AZ114-59
Installation & Operation Manual Version:
V1.0 11/01/2022
Product Registration
To ensure your bathtub is covered under warranty, it is
important to register your product within 30 days of purchase. You
can register online at www.ANZZI.com/register or by
mailing in the completed registration card.
Online Registration:
- Visit www.ANZZI.com/register
- Fill out the required information, which includes the same
details as the registration card. - Submit the registration form online.
Mail-in Registration:
- Complete the registration card provided in the manual.
- Cut out the card along the dotted line.
- Fill in your name, address, city, state, zip code, phone
number, email address, date of purchase, order or purchase number,
SKU or model number, and installer’s name and phone number. - Sign and date the registration card.
- Mail the completed card to: 5701 NW 35 Avenue, Miami, FL
33142
Important Notes
- Read the Owner’s Manual carefully and ensure that any
installation, operation, or maintenance of the bathtub is done
strictly in accordance with the instructions and guidelines
provided. - Inspect and water test the product prior to installation to
ensure it is free of defects or damage. If any issues are found, do
not proceed with the installation and contact customer support
immediately. - This product must be installed by a licensed/certified
contractor. It is recommended to hire licensed plumbers and
electricians to ensure proper installation. - Only use accessories authorized by the manufacturer with this
product.
Contact Information
If you have any questions or need further assistance, you
can:
- Call us at [INSERT PHONE NUMBER]
- Visit our website at www.ANZZI.com
ITEM: FT-AZ114-59
Freestanding Bathtub INSTALLATION & OPERATION MANUAL
V1.0 11/01/2022
DON’T WAIT! REGISTER NOW!
Register your product within 30 days to ensure your bathtub is coverage. Mail in the completed registry card (Pg. 2) or register online at www.ANZZI.com/register.
PRODUCT REGISTRATION*
IMPORTANT: YOUR WARRANTY WILL NOT BE RECOGNIZED UNLESS THIS CARD IS FULLY COMPLETED AND RETURNED OR ONLINE REGISTRATION IS COMPLETED.
1. Register online at www.ANZZI.com/register. You will be asked to fill out the same information you would in the registration card. Registering online is fast, secure and ensures we receive your information.
2. Complete, cut out and mail the registration card below. By returning this registration card we confirm the date of purchase for your new product. This confirmation will allow us to process any warranty claims.
Mail the card to: 5701 NW 35 Avenue, Miami, FL 33142
Product Registration Card
CUT ALONG DOTTED LINE.
Name …………………………………………………………………………. Address ……………………………………………………………………………………………………………
City ……………………………………………………….. State………………………………………… Zip………………………………..
Phone …………………………………………………… Email ………………………………………………………………..
Date of Purchase……………………… Order or Purchase #…………………………………………….. SKU or Model #………………………………………………….
Installer’s Name …………………………………………………………… Phone ……………………………………………………………………..
I have read the Owner’s Manual carefully and understand and agree that any installation, operation or maintenance of the bathtub must be done strictly in accordance with instructions and guidelines contained in the owner’s manual and installation guide.
Signature____________________________________________________________Date______________________________________________
2
Have questions? Call us at
or visit us at www.ANZZI.com
FREESTANDING BATHTUB
BASIN LENGTH
DECK THICKNESS
Have questions? Call us at
DRAIN HOLE
or visit us at www.ANZZI.com
3
SAVE THIS MANUAL!
READ THESE INSTRUCTIONS COMPLETELY BEFORE INSTALLING THE PRODUCT. FAILURE TO DO SO COULD RESULT IN AN IMPROPER INSTALLATION AND COULD VOID THE WARRANTY.
RESPONSIBILITY OF THE INSTALLER! THE INSTALLER MUST INSPECT AND WATER TEST THE PRODUCT PRIOR TO INSTALLATION TO ENSURE THE UNIT IS FREE OF DEFECT OR DAMAGE. IN THE EVENT OF A PROBLEM, THE UNIT MUST NOT BE INSTALLED. IF THE CRATE OR THE PRODUCT HAS BEEN DAMAGED DURING SHIPPING, PLEASE CALL US IMMEDIATELY.
THIS PRODUCT MUST BE INSTALLED BY A LICENSED/CERTIFIED CONTRACTOR! LICENSED PLUMBERS AND ELECTRICIANS SHOULD BE EMPLOYED TO INSURE PROPER INSTALLATION. INSTALLERS ASSUME ALL LIABILITY FOR THE CORRECT INSTALLATION PROCEDURES. ONLY ACCESSORIES AUTHORIZED BY THE MANUFACTURER SHOULD BE USED WITH THIS PRODUCT.
REPORT DAMAGE RIGHT AWAY! REPORT ANY DAMAGE TO THE BATHTUB WITHIN 5 BUSINESS DAYS. ANY DAMAGE REPORTED AFTER 5 BUSINESS DAYS WILL BE ASSUMED TO HAVE HAPPEN ED DURING OR AFTER THE INSTALLATION.
TEST THE TUB BEFORE INSTALLATION! BEFORE PERMANENTLY INSTALLING THE BATHTUB, YOUR INSTALLER MUST TEST THE TUB. USING THE PROVIDED FLEX DRAIN, PLUG IN THE TUB AND POWER IT ON. FILL TUB AND INSPECT FOR ANY LEAKING. YOU SHOULD ONLY PROCEED TO PERMANENTLY INSTALL THE UNIT IF THERE ARE NO SIGNS OF MALFUNCTION OR LEAKAGE.
LEVEL THE TUB TO AVOID LEAKAGE! CHECK THE AREA PRIOR TO INSTALLATION. USE THE TUB’S LEVELING FEET TO ENSURE THE BATHTUB IS PERFECTLY LEVEL. IT IS ESSENTIAL THAT ALL THE FEET ARE TOUCHING THE FLOOR/SURFACE. AN UNLEVELED TUB WILL RESULT IN LEAKAGE.
SAFETY INSTRUCTIONS
READ THESE INSTRUCTIONS COMPLETELY BEFORE INSTALLING THE PRODUCT. FAILURE TO DO SO COULD RESULT IN AN IMPROPER INSTALLATION AND COULD VOID THE WARRANTY.
IMPORTANT SAFETY INSTRUCTIONS. INSTRUCTIONS IMPORTANTES RELATIVES A LA SECURITE. READ AND FOLLOW ALL INSTRUCTIONS. LIRE ET SUIVRE TOUTES LES INSTRUCTIONS. SAVE THESE INSTRUCTIONS. CONSERVER CES INSTRUCTIONS.
4
Have questions? Call us at
or visit us at www.ANZZI.com
IMPORTANT
A) A freestanding bathtub is not designed to support weight on its rim. Therefore, do not sit or stand on the bathtub’s rim.
B) Please retain this manual aer installaon for future reference and maintenance. C) Installaon of tub is a two-person job.
DELIVERY OF YOUR TUB
Unpack and check for damage. Unpack the bathtub and inspect for damage or missing parts right away. Do not wait to do this. Damage reported aer installaon will not be covered by warranty. Repack the tub and keep it safely stored unl installaon begins. Protect your tub. Before commencing installaon, ensure the tub is wholly protected and leave the covering in place unl the bathroom is complete. The warranty does not cover scratches and damage incurred during installaon.
TESTING THE TUB
1. Place the tub on a completely flat surface where the water may drain it aer tesng. 2. Close the drain and fill the tub about halfway. 3. Allow the water to stand for 30 minutes. Then inspect the drain and plumbing for any leaks.
TEST THE BATHTUB WHILE YOU HAVE ACCESS TO THE BOTTOM AND BEFORE PERMANENT INSTALLATION.
Have questions? Call us at
or visit us at www.ANZZI.com
5
SPARE PARTS LIST
VANITY COVERS (this set is completely optional, see page 9)
Vanity covers have been provided to conceal the faucet’s hoses for a more finished look. This step is enrely oponal and not required for the operaon of the unit and it’s faucet.
Note: Make sure to leave ample space between each cover to prevent obstrucng, kinking or damaging the faucet’s hoses.
TOOLS REQUIRED
LEVELER RULER
ADJUSTABLE WRENCH
CAULK
TEFLON TAPE
FLEXIBLE DRAIN included
MARKING PENCIL
CAULK GUN
CAULK
SCREW DRIVER
ELECTRIC DRILL
NOTE: THE INCLUDED FLEXIBLE DRAIN IS TO BE USED ONLY TO TEST THE BATHTUB BEFORE PERMANENT INSTALLATION. IT IS THE RESPONSIBILITY OF THE INSTALLER TO PROVIDE THE PERMANENT DRAIN ASSEMBLY.
6
Have questions? Call us at
or visit us at www.ANZZI.com
INSTALL THE BATHTUB
Step 1 Move the tub to the selected installaon locaon, (Make sure that the floor surface can support the load capacity), and place it in the proper (or desired) posion. Step 2 Loosen the nuts on the tub’s leveling feet and adjust the feet unl the tub base is 3mm above the floor, but do not ghten the nuts. The skirt cannot take the weight. See figure 1 Step 3 Use a level to ensure the tub surface is level. Aer adjusng the leveling feet to a suitable posion, ghten the securing nuts. See figure 2
Figure 1
Figure 2
Have questions? Call us at
or visit us at www.ANZZI.com
7
INSTALL THE FLEXIBLE DRAIN
a. Install the FLEXIBLE DRAIN to the drain hole under the bathtub. Make sure there is a RUBBER WASHER between the drain hole and the FLEXIBLE DRAIN. The flat surface of the RUBBER WASHER should face upward towards the drain hole. (fig 1)
b. Adjust the FLEXIBLE DRAIN so that it points to the locaon of the drain pipe in the floor. Tighten the Nuts to secure the FLEXIBLE DRAIN. DO NOT OVER TIGHTEN. (fig 2)
c. Block the outlet of the FLEXIBLE DRAIN and water test the connecons by filling the tub with water to the overflow opening. Check for water leakage at areas indicated by arrows. (fig 2)
fig 1
Must be tightened to prevent water leakage
fig 2
8
Have questions? Call us at
or visit us at www.ANZZI.com
SEAL TUB
ADD A LINE OF SILICONE CAULK AROUND THE BASE OF THE BATHTUB AND ALLOW 24 HOURS TO PASS BEFORE USE TO ENSURE THE CAULK HAS SET.
CLE I G D M I TE CE
1. To preserve the polished surface, aer using your tub, clean with so cloth and warm soapy water to wash away any body oils or soap residue that forms a ring mark.
2. Do not use powders, pastes, cream cleaners, thinners, window cleaning sprays or dry cleaning liquid, etc., to clean the tub.
3. To clean the overflow plate and pop up drain, we do NOT recommend you use any household cleaners. Strong chemical cleaners can damage the finish and affect the funcon of this product. The product should only be cleaned with soapy water and rinsed with clean water and dried with a so colth.
4. When colored essenals oils are used, first test that the color won’t stain your tub. Always add oils into a tub full of water. Never pour them directly into an empty tub.
