Vario Coffee Grinder Electric White

Product Information

The product is a coffee grinder manufactured by Baratza. It
consists of several primary components and main body assembly, as
well as a grind motor assembly.

Primary Components

Item #1: Part #1010** (1 unit) – Frequently needed service
part
Item #2: Part #1012** (1 unit) – Frequently needed service
part
Item #3: Part #NA (1 unit)
Item #4: Part #8037-BLK (1 unit)
Item #5: Part #8037-WHT (1 unit)
Item #6: Part #F8029* (2 units) – Occasionally needed service
part
Item #7: Part #F8235* (2 units) – Occasionally needed service
part
Item #8: Part #6049* (4 units) – Occasionally needed service
part
Item #9: Part #8078-BLK* (1 unit) – Occasionally needed service
part
Item #10: Part #8078-WHT* (1 unit) – Occasionally needed
service part
Item #11: Part #8057 (2 units)
Item #12: Part #8055 (2 units)
Item #13: Part #F8275* (1 unit) – Occasionally needed service
part
Item #14: Part #F8214* (2 units) – Occasionally needed service
part
Item #15: Part #8160* (1 unit) – Occasionally needed service
part
Item #16: Part #1050* (1 unit) – Occasionally needed service
part
Item #17: Part #NA (2 units)
Item #18: Part #F8093 (2 units) – Frequently needed service
part
Item #19: Part #F8029* (6 units) – Occasionally needed service
part

Main Body Assembly

Item #1: Part #8330-BLK (1 unit)
Item #2: Part #8330-WHT (1 unit)
Item #3: Part #6032* (1 unit) – Occasionally needed service
part
Item #4: Part #8032* (1 unit) – Occasionally needed service
part
Item #5: Part #NA (1 unit)
Item #6: Part #F8093 (6 units) – Frequently needed service
part
Item #7: Part #F8029* (6 units) – Occasionally needed service
part
Item #8: Part #FS714* (4 units) – Occasionally needed service
part
Item #9: Part #8060** (1 unit) – Frequently needed service
part
Item #10: Part #8061** (1 unit) – Frequently needed service
part
Item #11: Part #F8223 (2 units)
Item #12: Part #8020 (1 unit)
Item #13: Part #8321 (1 unit)
Item #14: Part #8321-WHT (1 unit)
Item #15: Part #1022 (1 unit)
Item #16: Part #1022-WHT (1 unit)
Item #17: Part #1369 (2 units)
Item #18: Part #8094 (1 unit)
Item #19: Part #8023 (1 unit)
Item #20: Part #8023-WHT (1 unit)
Item #21: Part #8028 (1 unit)
Item #22: Part #8127 (1 unit)
Item #23: Part #8128 (1 unit)
Item #24: Part #F6122 (1 unit)
Item #25: Part #F6121 (1 unit)
Item #26: Part #6028 (2 units)

Grind Motor Assembly

Item #1: Part #8067 (1 unit)
Item #2: Part #F8175* (6 units) – Occasionally needed service
part
Item #3: Part #8174* (2 units) – Occasionally needed service
part
Item #4: Part #8070 (1 unit)
Item #5: Part #8224 (1 unit)
Item #6: Part #1024 (1 unit)
Item #7: Part #8087 (1 unit)
Item #8: Part #8088 (1 unit)
Item #9: Part #8089 (1 unit)
Item #10: Part #F8096* (1 unit) – Occasionally needed service
part
Item #11: Part #F8093 (5 units) – Frequently needed service
part
Item #12: Part #F8302* (4 units) – Occasionally needed service
part
Item #13: Part #8053 (1 unit)
Item #14: Part #8051 (1 unit)
Item #15: Part #8052 (1 unit)
Item #16: Part #8046 (1 unit)
Item #17: Part #8045 (1 unit)
Item #18: Part #8056* (1 unit) – Occasionally needed service
part
Item #19: Part #8077 (1 unit)
Item #20: Part #F6189* (2 units) – Occasionally needed service
part
Item #21: Part #8091* (1 unit) – Occasionally needed service
part
Item #22: Part #8078 (1 unit)
Item #23: Part #8099 (1 unit)
Item #24: Part #F8296* (1 unit) – Occasionally needed service
part
Item #25: Part #1036* (1 unit) – Occasionally needed service
part
Item #26: Part #1037* (1 unit) – Occasionally needed service
part
Item #27: Part #F8095* (1 unit) – Occasionally needed service
part
Item #NS: Part #6394** (1 unit) – Frequently needed service
part
Item #NS: Part #8097 (1 unit)
Item #NS: Part #8098 (1 unit)
Item #NS: Part #6022 (1 unit)
Item #NS: Part #8054 (1 unit)

Product Usage Instructions

Refer to the parts list and exploded view in the user manual
for a comprehensive understanding of the product’s components.
Ensure that all primary components, main body assembly, and
grind motor assembly are present and in good condition.
When assembling the main body, follow the instructions provided
in the user manual and refer to the exploded view for
guidance.
Install the grind motor assembly according to the
specifications outlined in the user manual.
For any required maintenance or servicing, refer to the
frequently needed service parts and occasionally needed service
parts mentioned in the parts list.
If any parts need replacement, ensure to stock the appropriate
parts with asterisks.
Contact Baratza at [email protected] or visit their website at
www.baratza.com for any inquiries or further assistance.

View Fullscreen

1 2
3 4 5
6 7 www.baratza.com

Parts List & Exploded View
PRIMARY COMPONENTS

8
9 10 11 12
13 14
15 16 17

[email protected]

Page 1/6

04/12/2022 (v1)

PRIMARY COMPONENTS

Item # 1 2 3 4 4 5 6 7 8 8 9 10 11 12 13 14 15 16 17

Part # 1010** 1012** NA 8037-BLK 8037-WHT F8029* F8235* 6049* 8078-BLK* 8078-WHT* 8057 8055 F8275* F8214* 8160* 1050* NA F8093 F8029*

Part Description Hopper Lid Clear Shut off Hopper (rev. 1.2) with spring ball Grind Chamber Top Casting (Assembly) Black Plastic Rear Housing (Baratza Logo) (Vario+, Vario W+) White Plastic Rear Housing (Baratza Logo) (Vario+, Vario W+) M3x12 machine screw M3x18 Self-Tapping Screw Rubber Foot Black Vario+ Display Assembly White Vario+ Display Assembly Knob Mount (Black) (Vario+, Vario W+) Knob (Metal) (Vario+, Vario W+) M3x5 Countersunk Self-Tapping Screw M3x4 Countersunk Machine Screw Grounds Bin (Vario) Metal Porta-Holder (Complete Assembly) Main Structure (Assembly) M3 External Tooth Star Lock Washer M3x12 Machine Screw

Total Used 1 1 1 1 1 2 2 4 1 1 2 2 1 2 1 1 1 2 2

** Frequently needed service parts * Occasionally needed service parts NOTE: No need to stock parts without asterisks

www.baratza.com

[email protected]

Page 2/6

04/12/2022 (v1)

1 2 3 4 5 6
7 89 10
11 12 13
www.baratza.com

Parts List & Exploded View
MAIN BODY ASSEMBLY

14 15 16

17 18 19
20

[email protected]

Page 3/6

21 04/12/2022 (v1)

MAIN BODY ASSEMBLY

Item # 1 1 2 3 4 5 6 7 8 9 10 11 12 12 13 13 14 15 16 16 17 18 19 20 21 NS

Part # 8330-BLK 8330-WHT 6032* 8032* NA F8093 F8029* FS714* 8060** 8061** F8223 8020 8321 8321-WHT 1022 1022-WHT 1369 8094 8023 8023-WHT 8028 8127 8128 F6122 F6121 6028

Part Description Black Top Casting with nickel plating and pad printing (Vario+) White Top Casting with painting and pad printing (Vario+) Micro Switch L-Bracket for Microswitch Grinding Chamber Assembly M3 external tooth star lock washer M3x12 Machine Screw M3x8 Self Tapping Screw 110v Power Board (Vario) 230v Power Board (Vario) Tinnerman Clip Ballast for Vario/W/Forte Black Plastic Base White Plastic Base (Vario(+), Vario W(+)) Black Plastic Cord Cover (Vario(+), Vario-W(+), Forte) White Plastic Cord Cover (Vario+, Vario W+) LED into Grounds Bin Calibration Grommet Chassis (Vario/W/Forte) White Chassis (Vario+, Vario W+) Vario Belt Casting PortaHolder Ball PortaHolder Ball Spring M6-1.25×8 Machine Screw M3.5×11 plastic thread cutting screw Motor Ground Wire

Total Used 1 1 1 1 1 6 6 4 1 1 2 1 1 1 1 1 2 1 1 1 1 1 1 2 5 1

** Frequently needed service parts * Occasionally needed service parts NOTE: No need to stock parts without asterisks

www.baratza.com

[email protected]

Page 4/6

04/12/2022 (v1)

1 2 3 3 4
5 6 7
8
9
10 11 12 13 14 15 16 17 11
www.baratza.com

Parts List & Exploded View
GRIND MOTOR ASSEMBLY

18 19 20
21 22 12 23 24
25 26

[email protected]

Page 5/6

29 04/12/2022 (v1)

GRIND MOTOR ASSEMBLY

Item # 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 NS NS NS NS NS

Part # 8067 F8175* 8174* 8070 8224 1024 8087 8088 8089 F8096* F8093 F8302* 8053 8051 8052 8046 8045 8056* 8077 F6189* 8091* 8078 8099 F8296* 1036* 1037* F8095* 6394** 8097 8098 6022 8054

Part Description Upper Burr Carrier (rev. 1.2) (Vario/Vario-W) M4x8 Cheese Head Machine Screw for Ceramic Burr Ceramic Burrs (each) (with 3 screws (F8175)) Vario Rotating Burr Carrier Grind Chamber Gasket Metal Threaded Grind Chamber (With Bushing) Anti-Static Flapper Discharge Chute Ground Chute Gasket (Vario/W/Forte) M4x6.5 Set Screw with Custom Tip M3 External Tooth Star Lock Washer M3.5×16 Plastic Thread Cutting Screw Plastic Micro Adjustment Arm Micro Cam Plastic Macro Adjustment Arm Grind Adjustment Spline Adjustment Rocker Vario/Vario-W Main Drive Gear w/ metal sleeve HTD Belt 112mxl (Not Sold Seperately) M5x12 Machine Screw Motor Plate (W/4 Grommet Sleeve Assemblies And Bushing) Belt Tensioning Bracket w/ screw for Vario Series Vario/W D-Shaft Motor Drive Pulley w/ Set Screw (F8296) M4x5 Point Tip Hardened Set Screw 120V Motor D-Shaft (Vario/W, Forte) (use w/6394) 230V Motor D-Shaft (Vario/W, Forte) (use w/6394) M3x8 Machine Screw Vario/Vario-W D-shaft Pulley w/ Set Screw & BELT (only compatible w/1036 or 1037) Jumper Wire: Power Board to Display Board (Vario/W/Sette) Jumper Wire: Power Board to Microswitch (Vario/W/Forte) Motor Cable Red & Black Adjustment Arm Shim

Total Used 1 6 2 1 1 1 1 1 1 1 5 4 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 2

** Frequently needed service parts * Occasionally needed service parts NOTE: No need to stock parts without asterisks

www.baratza.com

[email protected]

Page 6/6

04/12/2022 (v1)
