BREATHER HEATER KITS
Generators
Introduction
Honda generators are designed to operate in cold weather.
However, there are some cold-weather conditions where it is possible for condensation to collect and freeze inside the crankcase breather tube between the air cleaner and the
engine. When this happens, ice can block the air flow and restrict crankcase ventilation, which may cause the generator to run poorly or oil to leak from the engine.
A breather heater will keep the tube warm enough to prevent ice from forming. The breather heater fits inside the tube. The heating coil gets its power from the generator by connecting to the back terminal of a receptacle. After the breather heater kit is installed, it may remain on the generator and operate year-round.
Breather Heater Kits
The following kits are available from your local, authorized Honda Power Equipment dealer. To find a dealer near you, visit powerequipment.honda.com.
If your model is not listed below, a breather heater kit is currently not available.
| Series | Model | Part No. |
| EB | EB2200iT (A type) | 06390-Z44-A30 |
| EB2200iT (AG, AN types) | 06390-Z44-F30 | |
| EB2800i (A type) | 06390-Z43-B30 | |
| EB2800i (AG, AN types) | 06390-Z43-C30 | |
| EB3000cK1 , EB3000cK2 | 06390-Z04-E21 | |
| EB3800X • EB5000XK2 • EB6500X (AN type) | 06390-Z22-T20 | |
| EB5000XK3 • EB6500X1 (AG, AN types) | 06390-Z22-C30 | |
| EB10000 (AH, AH1, AG types) | 06390-Z26-F30 | |
| EG | EG2800i (A type) | 06390-Z43-A31 |
| EG2800i (AG, AN types) | 06390-Z43-D30 | |
| EG4000CL (AT, AT1 , AG, AN Types) | 06390-Z33-V20 | |
| EM | EM5000is (AN type) | 06390-Z12-R10 |
| EM5000isl (A, AT types) | 06390-Z25-V40 | |
| EM3800SX • EM5000SXK2 • EM6500SXK1 (AN type) | 06390-Z22-S20 | |
| EM5000SXK3 • EM6500SXK2 (AG, AN types) | 06390-Z22-C30 | |
| EU | EU1000i, EU1000iK1 (AN type) | 06390-ZT3-S 10 |
| EU2000iK1 (A1, A2, A4 types), EU2000iT1 (A1, A4 types) | 06390-Z39-C30 | |
| EU2000iK1 (A3 type), EU2000iT1 (A3 type) | 06390-Z39-R80 | |
| EU2200iT (A, A2, A3 types) | 06390-Z44-A30 | |
| EU2200iT (Al type) | 06390-Z44-C31 | |
| EU2200iT (AG, AN types) EU2200iT Camo (AG3, AN3 types) | 06390-Z44-F30 | |
| EU2200iT Companion (AG1, AN1 types) | 06390-Z44-G30 | |
| EU3000i Handi (AC, AN, AN8 types), EU3000iK1 Handi | 06150-Z28-C32 | |
| EU3000iS (AN type), EU3000is1 (A, A/A types) | 06390-ZS9-T21 | |
| EU3000iS1 (AG, AN types) | 06390-ZS9-W30 | |
| EU3200i (AC, AN types) | 06390-Z45-A30 | |
| EU6500is (AN type) | 06390-Z25-R00 | |
| EU6500is1 (A, AT types) | 06390-Z25-V40 | |
| EU7000iS (AT, AT1 types) | 06390-Z37-A42 | |
| EU7000isN (AG, AN types) | 06390-Z37-R50 |
© 2017-2023 American Honda Motor Co., Inc.—All rights reserved
First Issue Date: August 2017
