BPH SA192R-16 Battery Pack for VFI
PowerWalker BPH SA192R-16
The PowerWalker BPH SA192R-16 is a power backup system designed
to provide uninterrupted power supply during outages or
fluctuations in the main power source. It consists of a unit that
houses 16 batteries and two 15A 250V fuses. This product ensures
the safety of your electronic devices and allows for a smooth
transition to backup power.
Important Safety Warnings
It is crucial to follow all safety warnings and operating
instructions provided in this user manual. Carefully read and
understand these instructions before installing and operating the
unit. Failure to comply with these instructions may result in
damage to the unit or harm to individuals.
Installation and Setup
Prior to installation, inspect the unit and ensure that there is
no damage to any components. Keep the original packaging in a safe
place for future use. Follow the step-by-step instructions provided
in the user manual for proper installation and setup of the
PowerWalker BPH SA192R-16.
Storage and Maintenance
When disposing of depleted batteries, it is recommended to
either deliver them to a recycling facility or ship them back to
your dealer in the package that contained the replacement
batteries. This ensures proper disposal and environmental
protection.
Storage Guidelines:
- Before storing, charge the unit for 4 hours.
- Store the unit covered and upright in a cool, dry
location. - During storage, recharge the battery according to the following
schedule:
| Storage Temperature | Recharge Frequency | Charging Duration |
|---|---|---|
| Every 3 Months | 1-2 hours | |
| Every 2 Months | 1-2 hours |
Assembly Instructions
Follow these assembly instructions to properly configure the 16
batteries:
Remark:
2x Fuse 15A 250V
16x Battery 12V 7-9 Ah
Ensure that the two 15A 250V fuses are properly inserted into
their designated slots within the unit. Then, arrange and connect
the 16 batteries in the following configuration:
Battery Configuration:
– Connect the positive terminal of one battery to the negative
terminal of the next battery in a series until all 16 batteries are
connected.
– Finally, connect the positive terminal of the first battery
and the negative terminal of the last battery to the corresponding
terminals in the unit.
Following these instructions will result in a correctly
assembled PowerWalker BPH SA192R-16 unit, ready to provide reliable
backup power when needed.
PowerWalker How to assemble a
BPH SA192R-16
Important Safety Warnings
Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully.
· Do not try to assemble or repair the unit yourself, contact your local supplier, seek for a qualified technician for professional assistance.
· To eliminate any overheating of the battery box, keep all ventilation openings free from obstruction and do not place any foreign objects on top of the battery bank. Keep the battery box 20 cm away from the wall.
· Make sure the battery box is installed within the proper environment as specified. (040°C and 30-90% non-condensing humidity)
· Do not install the battery box under direct sunlight. Your warranty will be void if the batteries fail due to overheating.
· This battery box is not designed for use in dusty, corrosive and salty environment.
· The warranty for this battery bank will be void if water or other liquid is spilled or poured directly onto the battery box. Similarly we do not warrant any damage to the battery box if foreign objects are deliberately or accidentally inserted into the battery box enclosure.
· The battery will discharge naturally if the system is unused for a period of time.
· It should be recharged every 2-3 months if unused. If this is not done, then the warranty will be null and void. During normal operation, the batteries will be automatically remained in charged condition.
· Servicing of batteries should be performed or supervised by trained personnel with knowledge of batteries and the required precautions.
· When replacing batteries, it is necessary to replace ALL batteries with the same quantity, type & capacity.
· CAUTION Do not dispose of battery or batteries in a fire. The battery may explode.
· CAUTION Do not open or mutilate the batteries. The electrolyte from the batteries is toxic and harmful to the skin and eyes.
· CAUTION Risk of Electric Shock Hazardous voltage may exist between battery terminals and ground. Test before touching with bare hands.
· CAUTION A battery can present a risk of electrical shock and high short circuit current.
The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3. Wear rubber gloves and boots. 4. Do not lay tools or metal parts on top of batteries. 5. Disconnect charging source prior to connecting or disconnecting battery terminals. · Do not plug or unplug the battery connector if UPS works in DC (discharging) mode.
Installation and Setup
NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use.
Storage and Maintenance
The unit contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer.
Be sure to deliver the depleted batteries to a recycling facility or ship it to your dealer in the package that contained the replacement batteries.
Storage
Before storing, charge the unit 4 hours. Store the unit covered and upright in a cool, dry location. During storage, recharge the battery in accordance with the following table:
Storage Temperature
Recharge Frequency
Charging Duration
-25°C 40°C
Every 3 Months
1-2 hours
40°C 45°C
Every 2 Months
1-2 hours
SOP How to assemble BPH SA192R-16
Please assemble the 16 batteries with the following configuration
Remark:
2x Fuse 15A 250V 16x Battery 12V 7-9 Ah
