Edvivi Ew2625bk Arlo 13 Inch 2 Lights Black And Antique Brass Vanity Light Instruction Manual

EW2625BK Arlo 13 Inch 2 Lights Black and Antique Brass Vanity Light

Product Information:

• Model: EW2625BK/ EW2634BKAB/ EW2641BN/ EW2725BK/ EW2734BKAB/
  EW2741BN/ EW2825BK/ EW2834BKAB/ EW2841BN
• Customer Service Number: (832) 478-8866
• Customer Service Email: [email protected]
• Manufacturer’s Warning: Improper installation may cause
  electrical shock, fire, or equipment damage. The person performing
  the installation must be familiar with the construction and
  operation of the product and associated hazards.
• Important Safety Instructions:
  • Please read through all the instructions carefully and
    completely before beginning assembly and installation.
  • This product must be installed in accordance with installation
    instructions and all safety and building codes.
  • It is strongly suggested that all direct wired fixtures be
    installed by a licensed electrician.
  • Be sure the electricity to the wires you are working on is shut
    off; either the fuse is removed or the circuit breaker is turned
    off. Turning the power off using the light switch is not sufficient
    to prevent electrical shock.
  • This product can expose you to chemicals including lead, which
    is known to the State of California to cause cancer or birth
    defects or other reproductive harm. For more information, go to
    www.P65Warnings.ca.gov

Product Usage Instructions:

1. Wire Connection Diagram:
   • A. Existing Electrical Box
   • B. Crossbar
   • C. Crossbar Screws
   • D. Ground Wire
   • E. Canopy
   • F. Wire
   • G. Junction Caps
2. Attach the crossbar (B) to the existing electrical box (A)
   using the two crossbar screws (C) which are not supplied and should
   already be in your box.
3. Pass the main wire (F) and ground wire (D) through the canopy
   (E) and the crossbar (B) until the end of the main wire (F) reaches
   the electrical box (A) where you can wire using electrician
   connections. Be sure to use electrician approved junction caps (G)
   when connecting the wires.
4. Stow the excess wire in the electrical box (A).
5. Raise the canopy (E), attach it to the ceiling, and hold it in
   place.

Note: Some parts may be pre-installed or pre-assembled.

Part List and Assembly Illustration:

• 1 Light Bulb (Not included)
• 3 E26
• (1)*4PC
• (2)*4PC
• (3)*2PC
• (4)*1PC
• (5)*1PC

MOUNTING AND WIRING
WARNING:
Improper installation may cause electrical shock, fire, or equipment damage. The person performing the installation must be familiar with the construction and operation of the product and associated hazards
G

lnstallation lnstructions
Model:EW2625BK/ EW2634BKAB/ EW2641BN/ EW2725BK/ EW2734BKAB/ EW2741BN/ EW2825BK/ EW2834BKAB/ EW2841BN
Customer Service Number: (832) 478-8866 Customer Service Email: [email protected] Please include your name, contact methods, product name, and model number in the email.
IMPORTANT SAFETY INSTRUCTIONS: . Please read through all the instructions carefully and completely before
beginning assembly and installation . This product must be installed in accordance with installation instructions
and all safety and building codes. It is strongly suggested that all direct wired fixtures be installed by a licensed electrician . Be sure the electricity to the wires you are working on is shut off; either the fuse is removed or the circuit breaker is turned off. Turning the power off using the light switch is not sufficient to prevent electrical shock

GND

BCD F A

Wire Connection Diagram:

Please proceed in an alphabetical order:
. A.Existing EIextricaI BOX B.Crossbar C.Crossbar Screws D.Ground Wire E.Canopy F.Wire G.Junction Caps
. attach the crossbar(B)to the existing eIectricaI box(A) using the two crossbar screws(C)which are not suppIied and shouId aIready in your box.
. Pass the main wire(F)and ground wire(D)through the canopy(E)and the crossbar(B)untiI the end of the main wire(F)reaches the eIectricaI box (A)where you can wire use eIectrician connections.Be sure when connecting the wire use eIectrician approved junction caps(G).stow the excess wire in the eIectricaI box(A).raise the canopy(E),attach canopy(E)to ceiIing,and hoId the canopy(E).

EW2625BK/ EW2634BKAB/ EW2641BN
EW2725BK/ EW2734BKAB/ EW2741BN
EW2825BK/ EW2834BKAB/ EW2841BN
WARNING: This product can expose you
to chemicals including lead,which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more infomation go to www.P65Warnings.ca.gov

PART LIST AND ASSEMBLY ILLUSTRATION

ASSEMBLING, INSTALLATION, AND MOUNTING

Note: Some parts may be pre-installed or pre-assembled.

1

Light Bulb (Not included)

3

(1)*4PC

E26

(2)*4PC

(3)*2PC (4)*1PC
(5)*1PC

EW2625BK/ EW2634BKAB/ EW2641BN

1: Lock together

2
EW2725BK/ EW2734BKAB/ EW2741BN

EW2825BK/ EW2834BKAB/ EW2841BN
