Blind Mating Mobile Charging Connector

Product Information

The Blind Mating Mobile Charging Connector by TE Connectivity is
designed for use with smaller mobile robots and autonomous vehicles
in warehouse environments. These connectors are commonly used in
warehouse automation for material handling tasks such as picking,
movement, storage, and sorting. The charging connector is available
in two and three power contact options, and it also offers up to
eight signal contacts to simplify installation and rework cycle
times.

Product Usage Instructions

Ensure that the mobile robot or autonomous vehicle is powered
off before attempting to connect or disconnect the charging
connector.
Locate the charging port on the robot or vehicle. It is
typically labeled and can be found in a visible and accessible
location.
Align the blind mating mobile charging connector with the
charging port.
Gently insert the connector into the port, ensuring a secure
fit. Do not force the connector if it does not go in smoothly.
Once the connector is fully inserted, you may hear a click
indicating that it is locked in place. Verify that the connector is
securely connected.
To disconnect the charging connector, press any release
mechanisms (if present) and gently pull the connector out of the
port.
When not in use, keep the charging connector in a safe and dry
location to prevent damage.

For further information and detailed specifications about the
Blind Mating Mobile Charging Connector, please refer to the product
manual or visit the TE Connectivity website.

View Fullscreen

INTRODUCING
BLIND MATING MOBILE CHARGING CONNECTOR
· High mating cycle life
· Modular solution that will support different configurations, data, sensing

TE Connectivity (TE)’s blind mating mobile charging connector is intended for smaller mobile robots and autonomous vehicles typically used in warehouse environments. Autonomous Mobile Robots (AMR) are currently used mostly for material handling (picking, movement, storage, sorting) in the warehouse automation space. The charging connector is available in 2 and 3 power contact options with up to 8 signal contacts to ease installation and rework cycle times.

APPLICATIONS
· Charging for Autonomous Mobile Robots / Automated Guided Vehicles (AMR/AGV)
· Blind mate battery charging · Industrial, hospitality, retail, medical
BENEFITS
· High mating cycle life · Modular solution that will support different configurations,
data, sensing · First make last break power contact (3P only) · Floating panel mount design maximizes misalignment
tolerance capability · UL recognized to UL 1977
SPECIFICATIONS
· Product spec 108-160493 · Application spec 114-160271
LEARN MORE
· Blind mating mobile charging connector product flyer · 2P plug docking charging kit · 2P receptacle docking bot kit · 3P plug docking charging kit · 3P receptacle docking bot kit · Rectangular connectors · Standard rectangular connectors · Blind mating mobile charging connector
customer presentation

FEATURES
Robust design for high cycle life · Designed for a minimum of 12,000 mating cycles
· Low insertion force power contacts · Spring probe signal contacts · Blind mate capability · Allows for misalignment of at least +/-15mm for x and
+/- 10 for y direction · +/- approx. 5° for z direction (mating) Connection flexibility · 2 & 3 power contact options · Up to 50A and up to 125V · Up to 40A per line at up to 100V · Terminates to 10 or 8 AWG stranded copper wire · First make, last break contact for use in grounding, system
enabling or applications that require charging two battery strings independently · Touch safe contacts for extra safety if rework is needed · Up to 8 signal contacts · Up to 0.5A per line · Terminates to 22-30 AWG stranded wire · Rear pluggable interface to ease installation and rework cycle times · Spring probe contacts for high cycle life · Utilizes Mini Universal MATE-N-LOKII Connector interface for signal contact mating
