S5120PN-WHT-CG Marie Flanigan Sydney LED Pendant Ceiling Light
Product Information:
Product Name: Sydney Narrow Pendant
Item Number: S 5120
Product Usage Instructions:
- Carefully remove all parts from the box. Place on a clean, soft
surface. - Remove mounting plate (B) from collar loop (D) by
unscrewing. - Determine desired overall length and amount of chain (G)
needed. Shorten chain (G) using chain pliers (Keep extra
chain). - Thread glass shade (J) to socket (I), then carefully slide
metal shade (H) down chain (G) and place on top of glass shade
(J). - Thread fixture wire and ground wire through chain (G). NOTE:
When you reach the collar loop (D), ensure there is no tension on
the wires. Cut excess wires, being sure to leave about 12″ to reach
the junction box. - Separate two sides of molded wire and strip insulation on each
5/8″. - Twist all fixture wires together. Slip through the center hole
of collar loop (D). NOTE: Untwist wires and separate to prepare for
connection. - Add collar ring (F) and canopy (E) to chain (G) and slip down
carefully. - Secure collar loop (D) to mounting plate (B) using pliers to
tighten locknut. - Install mounting plate (B) to the junction box and secure with
mounting screws (C). - Wrap fixture ground wire (bare copper) around the green
grounding screw. Tighten. - Continue fixture ground wire and connect to supply ground wire
(usually green or bare copper) using wire nut (A). NOTE: It is
imperative that the fixture is grounded. - Connect fixture neutral wire (ribbed) to the supply neutral
wire (usually white) using wire nut (A). - Connect fixture hot wire (smooth with markings) to the supply
hot wire (usually black) using wire nut (A). CAUTION: Do not
reverse the hot and neutral connections. - Make sure all wire connections are tight, then carefully tuck
into the junction box. - Install canopy (E) to collar loop (D) by securing with collar
ring (F). - Install the light bulb into the socket.
Care Instructions:
Clean only with a soft dry cloth or feather duster. Do not use
abrasive or chemical agents.
ASSEMBLY INSTRUCTIONS
Diagram 1
A B
D C E F
G
H
I
J
Bulb not included
Sydney Narrow Pendant
Item # S 5120
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Slip Joint Pliers
Wire Strippers
Wire Cutters
Chain Pliers Measuring Tape
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (B) from collar loop (D) by unscrewing. 3. Determine desired overall length, and amount of chain (G) needed.
Shorten chain (G) using chain pliers (Keep extra chain). 4. Thread glass shade (J) to socket (I), then carefully slide metal
shade (H) down chain (G) and place on top of glass shade (J). 5. Thread fixture wire and ground wire through chain (G).
NOTE: When you reach the collar loop (D), ensure there is no tension on the wires. Cut excess wires, being sure to leave about 12″ to reach the junction box. 6. Separate two sides of molded wire, and strip insulation on each 5/8″. 7. Twist all fixture wires together. Slip through center hole of collar loop (D). NOTE: Untwist wires and separate to prepare for connection. 8. Add collar ring (F) and canopy (E) to chain (G) and slip down carefully.
ASSEMBLY INSTRUCTIONS
Diagram 1
A B
D C E F
G
H
I
J
Bulb not included
Sydney Narrow Pendant Item # S 5120
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
9. Secure collar loop (D) to mounting plate (B) using pliers to tighten locknut.
10. Install mounting plate (B) to the junction box and secure with mounting screws (C).
11. Wrap fixture ground wire (bare copper) around the green grounding screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded.
12. Connect fixture neutral wire (ribbed) to the supply neutral wire (usually white) using wire nut (A).
13. Connect fixture hot wire (smooth with markings) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
14. Make sure all wire connections are tight, then carefully tuck into the junction box.
15. Install canopy (E) to collar loop (D) by securing with collar ring (F). 16. Install light bulb into the socket.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
