MA 272 SL Plus One-Piece Firebox with Vertical Sliding Door

Product Information: MA 272 SL PLUS by Piazzetta

The MA 272 SL PLUS by Piazzetta is a one-piece firebox designed
for wood fireboxes. It comes with a vertically sliding door and
natural convection that ensures low consumption, high efficiency,
and easy installation. This product is perfect for those who want
to enjoy the warmth of a wood fire without the hassle of
traditional fireplaces.

General Features:

• One-piece firebox design
• Vertically sliding door
• Natural convection for low consumption and high efficiency
• Easy installation

Technical Details:

• Model: MA 272 SL PLUS
• Designed for: Wood fireboxes
• Door Type: Vertically sliding door
• Convection Type: Natural convection

Product Usage Instructions:

Here are some instructions on how to use the MA 272 SL PLUS:

1. Make sure that the firebox is installed correctly and that all
   connections are secure.
2. Place the wood logs inside the firebox, making sure not to
   overload it.
3. Open the vertically sliding door and light the wood logs using
   a lighter or matches.
4. Close the door and adjust the airflow using the air vents to
   control the intensity of the fire.
5. Enjoy the warmth and ambiance of your new firebox!

Note: Always use caution when handling fire and follow all
safety precautions when using the MA 272 SL PLUS.

MA 272 SL PLUS

The MA 272 SL PLUS by Piazzetta is the One-piece Firebox with Verticallysliding Door and Natural Convection for Wood Fireboxes that will ensure you low consumption, high efficiency and easy installation. Find out further information

GENERAL FEATURES
·Heating: natural convection and radiation ·Structure: coated steel with closed firebox ·Firebox: Aluker® ·Hearth: cast iron ·Hood: steel ·Opening: door in coated steel with self-cleaning ceramic glass resistant to 750°C. With vertically-sliding opening and door for cleaning ·Door profile: coated steel ·Handle: coated steel ·Primary air: manually adjustable ·Secondary air: pre-determined ·Flue gas adjustment: with manually adjustable valve ·Standard flue outlet position: top ·Fuel: wood

TECHNICAL DETAILS
·Energy efficiency class A ·Rated output max kW 13,0 ·Rated efficiency power % 78,3 ·Rated consumption max kg/h 3,9 ·Vertically sliding opening cm 38 ·Firebox opening (W) – Dimensions for the passage of wood cm 47 ·Firebox opening (H) – Dimensions for the passage of wood cm 30,5 ·Mouth of firebox (W) – Minimum dimensions of mouth of cladding cm 60 ·Mouth of firebox (D) – Minimum dimensions of mouth of cladding cm 53,5 ·Mouth of firebox (H) – Minimum dimensions of mouth of cladding cm 51,5 ·Weight kg 340 ·Model MA 272 SL PLUS
