Akko Acr Pro Alice Plus Mechanical Keyboard User Manual

Akko Acr Pro Alice Plus Mechanical Keyboard User Manual

akko logoALICE Plus Mechanical Keyboard
User Manual

AKKO ACR Pro ALICE Plus Mechanical Keyboard -

HotKeys (Windows)

Note: The following features are realized by the combination of “Fn” + corresponding ke

1F19F9Esc~
2F20F10CCalculator
3F3F11MMute
4F4+F12<Decrease Volume
5F5PgUpHome>Increase Volume
6F6PgDnEndWSwap W  A  S   D
7F7IInsertwith  ↑↓ ←  →
8F8PPrtSc

Mac

Note: The following features are realized by the combination of “Fn” + the corresponding key.

1Decrease display brightnessDecrease VolumeMMute
2Increases display brightness+Increase Volume<Decrease Volume
3Open mission controlPgUpHome>Increase Volume
4Activate SiriPgDnEndWSwap W  A  S   D
7Skip back (Audio)IInsertWwith  ↑↓ ←  →
8Pause/Play (Audio)PPrtScLeft WinOption
9Skip forward (audio)Esc~Left AltCommand
0MuteCCalculatorRight AltCommand

System Commands

Lock Windows KeyPress Fn and left Win key
Restore Factory SettingsHold down Fn and press the Backspace key for 5S
Enter Windows systemHold down Fn and press the Q key for 3S
Enter Mac systemHold down Fn and press the O key for 3S

Backlight Settings

Note: The following features are realized by the combination of “Fn” + corresponding key

LLight On / Off
Bright
Dim
Set animation direction to left
Set animation direction to right
;Slower Animation
Faster Animation
ZAcrylic Case Light Brightness Change
XAcrylic Case Light Animation Speed Change
left CtrlAcrylic Case Light Effect Change
DeleteEffect1 – Effect20
\In all multi-color RGB lighting effects, this
SpacebarSet the acrylic case to backlight to 7 single

Key/Lighting Effects Customization Instruction

  1. The key/lighting effects customization must be with the Akko driver.
  2. In wired mode, the lighting effects can also achieve music rhythm effects with the Akko driver.
  3. Please download the Akko Cloud driver on our website.
  4. Users can download the driver via en.akkogear.com
AKKO ACR Pro ALICE Plus Mechanical Keyboard - Qr codeAKKO ACR Pro ALICE Plus Mechanical Keyboard - Qr code1
http://weixin.qq.com/r/aDtOVoXE6tiVrcE19256http://qr.weibo.cn/g/49ssmq

akko logowww.akkogear.com
AKKO ACR Pro ALICE Plus Mechanical Keyboard - Fig
@akkogear
