My Green Lighting 21509103 Tin Maxi Light Sensor
INSTRUCTIONS
Please read these instructions carefully before attempting to install this fitting. It is advisable to keep these instructions in a safe place for future reference. If this fitting is installed by a contractor, the contractor should ensure that the customer has a copy of these instructions.
Sensor specifications
- Voltage: 230 volts AC
- Max load: I 00 watt maximum
- Angle of detection: 110 degrees
- Lux operation: I 0-20000LUX
- Time on:5 seconds-5 min. (approx.) from initial triggering.
NOTE! If triggered within this period, another triggered timeN is added to time already run. - Max. detection range: Up to 8 meters approx. depending on weather conditions and mounting height.
NOTE! The 8111 detection range applies when a person is walking across the detection area, not walking towards the sensor. If a person is walking towards the sensor and I .Sm to the left or right of it, the detection range is typically between 4m and 6m - Mounting height: 1.5 to 2.5 meters approx.
- Ambient operating temp. range: -10° to +50° Celsius
Operation
Time: regulate triggered time 5 seconds-Smin Distance: regulate detection range up to 8 metres approx Lux: regulate lux I 0-20000
Note
We do not recommend using low energy-saving lamps in this fixture.
Troubleshooting
When replacing the lamp or servicing the fitting, turn the power off at the mains and allow the lantern to cool.
| FAULT | POSS.IBLE CAUSE | SOLU. | TION | |
| Unit will not work at all | . No power Lamp not fitted correctly or broken . Incorrect wiring | . . | Check power and fuse Check lamp Check wiring | |
| Unit will not work when in normal operation | . | Area too light, e.g. lighting nearby | . | Re-position lantern if required |
| Sensing range too short | Unit is fixed too high, or angle of approach into . detection bands is incorrect Other lighting interfering with the sensitivity of the PIR sensor | Move the unit to a lower height and/or change the angle of . approach Move lantern away from other lighting .. | ||
| Lamp on all the time | Wrongly wired | Check wiring | ||
| If Normal Mode lamp stays on for more than 5 minutes | PIR (sensor) has been triggered again within the 5 minutes time period (sec specification) | .. | Light will automatically switch off approximately 5 minutes after the last signal the PIR receives | |
| Lamp false triggers | Lantern badly positioned High winds | Reposition lantern Temporary situation. If annoying, switch lantern off | ||
